Fortinet AP400 Series Installation Manual page 63

Figure 28:
Attach the square bracket to the underside of the main support bar using the screws pro-
4.
vided, as shown in
Figure 29:
Brace your hand against the back of the main support bar and press the AP433i against
5.
the square bracket in a similar manner to that indicated in
Twist until the AP433i clicks into place. If desired, you can now lock the AP using the lock-
6.
ing key.
Attach the two legs of the mounting bracket to the T-bars on which the AP is to be
7.
mounted by sliding the clips onto the bars.
Installing AP433i
Ports for the AP433i
RESET
Figure 29 on
AP433i Mounted Above a Suspended Ceiling Face Down
Mounting Bar
Reset USB Console
USB
CONSOLE
page 49.
Mounting Brace
Clips attach to T-bar
Ethernet
G1
Figure 26 on page 47.
49
