Figure 9:

Mount AP433e Below a Suspended Ceiling

The brackets on the bottom of the AP433e allow it to be mounted directly to a ceiling T-bar
(see
(provided in the box) into the unlock hole on the side of the AP shown in
in order to clip the AP in place.
Figure 10:
To mount an AP433e below a suspended ceiling:
Determine the location on the ceiling rail where the AP will be mounted and remove the
1.
ceiling tiles.
Install the AP433e
Ports for the AP433e
RESET
Figure 10 on page 29). Note that the AP lock must be disabled by sliding the locking key
Mounting AP433e to a Suspended Ceiling Rail
USB Console Ethernet
port port port
USB
G1
CONSOLE
T-bar
(in ceiling)
Figure 9 on page 29
29
