Summary of Contents for Fortinet FortiAP U231F
- Page 1 FortiAP U231F Quick Start Guide...
- Page 2 FAP-U231F Box Includes Screws (16) FAP-U231F QuickStart Guide Wall/Ceiling Mount & Standard Tile T-rail Bracket (2 Sizes)
- Page 3 About FAP-U231F IMPORTANT: Supported only from FortiWLC 8.6.1 and FortiGate with FOS version 6.4.3 and later. The FortiAP-U231F access points are 802.11ax, 2x2 MIMO, tri-radio, dual band indoor access points and are compliant with the IEEE 802.3at PoE specifications. The FAP-U231F is compatible with FortiWLC enterprise wireless LAN controllers, integrated FortiGate enterprise firewall LAN controllers, and FortiAPCloud management platform.
- Page 4 Installing FAP-U231F Follow this procedure to attach the unit to a wall or ceiling using the supplied mounting bracket. 1. Slide and attach the ceiling mount bracket to the bottom cover of the FortiAP unit. If extra space is required to accommodate drop ceiling tiles, use the taller ceiling mount bracket. 2.
- Page 5 Notes: • One standard ceiling mount bracket is included in sizes: 1.43cm (9/16in) and 2.38cm (15/16in). • Mounting above the ceiling: FAP-U231F is UL2043 plenum rating certified. However, mounting it above the ceiling is restricted to the FortiAP either facing up or facing down; mounting FAP- U231F vertically is not allowed.
- Page 6 Console Port (RJ-45) Optional management Ports computer connection Provides access to the Command-Line Interface (CLI) Serial Baud Rate 115200 USB Port Reset Power LAN1 1G PoE & LAN2 1G 12V, 2.5A Ethernet Port (RJ-45) Gigabit Ethernet port with Power over Ethernet (PoE) Powered Device (PD) support...
- Page 7 LED Status...
- Page 8 5 - Bluetooth, Zigbee and Radio 3 No light: Radio 3, BLE, and Zigbee are powered off Green: Radio 3, BLE, and Zigbee are enabled Blinking Green: Data Tx/Rx on Radio 3, BLE, and Zigbee Orange: Radio 3 is up. Blinking Orange: Data Tx/Rx on Radio 3 Blue: BLE is enabled Blinking Blue: Data Tx/Rx on BLE...
- Page 9 Adequate grounding must be provided to the FortiAP unit in Connecting compliance with the local electrical code. Caution: Do not use any PoE injectors that are not IEEE 802.3at compliant, as they may damage your device. 1. Connect one end of the Ethernet cable into the LAN1 port of the FortiAP unit.
- Page 11 FAP-U231F is compatible with FortiWLC enterprise wireless Supported LAN controllers, integrated FortiGate enterprise firewall LAN controllers, and FortiAPCloud management platform. Controller Types • If FortiWLC controller is discovered, the unit continues booting up with the default FortiWLC image. • If the FortiGate controller or the FortiAPCloud management platform is discovered, the unit reboots with the FortiAP image.
- Page 12 Follow these steps to complete the FortiAPCloud discovery. FortiAPCloud Visit https://login.fortiapcloud.com and sign in or Deployment create a new account. Click Inventory > Import AP Key and enter the unique FortiAPCloud key, then click Submit. Note: The FortiAPCloud key is located on the back of your FortiAP unit. Deploy the FortiAP to an existing AP network, or create a new AP network, then click Submit.
- Page 13 Follow the prompts to associate the FortiAP device to an SSID. Connect your FortiAP to an Internet connection. This can be a modem or another source of Internet connectivity. Configure the discovered FortiAP.
- Page 14 To complete the FortiGate controller discovery process, you need to authorize the FortiAP on FortiGate. FortiGate Deployment 192.168.1.2 is the default FortiAP IP address when it boots up with the FortiAP image managed by FortiGate.
- Page 15 The FortiAP unit is designed to require no configuration in most networks. Zero configuration mode works if the unit is on the same Zero layer-2 network and subnet as the FortiWLC, or if the unit is on the same layer-3 network and subnet as the FortiGate controller or Configuration FortiAPCloud management platform.
- Page 16 To enable the FortiAP using Zero Configuration: 1. After connecting the FortiAP unit as described in the previous Zero chapter, the unit goes through its boot procedure and requests an IP address from the DHCP server. Configuration If the IP address is retrieved successfully, the FortiAP enters discovery mode to locate a Controller.
- Page 17 The discovery mode for FortiAPCloud management platform is: • DNS (for an FQDN pointing to the FortiAPCloud) Zero 3. Verify that the FortiAP has successfully connected to the controller in the FortiWLC/FortiAPCloud/FortiGate WebUI. Configuration...
- Page 18 To enable the FortiAP with a static IP address: 1. Connect the FortiAP device to a separate private switch or hub. Manual IP 2. Access the AP console through the serial port. Configuration 3. To configure FortiAP’s own IP address, type ip config net static address <ip-address>...
- Page 19 Cautions and Warnings This equipment has been tested and found to comply with the This Class B digital apparatus complies with Canadian ICES-003. limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection Cet appareil numérique de la classe B est conforme à...
- Page 20 L’émetteur/récepteur exempt de licence contenu dans le présent usage intérieur afin de réduire l’interférence nuisible potentielle aux maximum permissible gain and required antenna impedance for appareil est conforme aux CNR d’Innovation, Sciences et Dével- systèmes mobiles par satellite co-canal. each antenna type indicated. Antenna types not included in this oppement économique Canada applicables aux appareils radio list, having a gain greater than the maximum gain indicated for that exempts de licence.
- Page 21 Agência Nacional de Telecomunicações Internal antenna Model: (ANATEL) – Brazil Antenna Antenna Connector Gain (dBi) Type 2.4GHz 5GHz Este produto não é apropriado para uso em ambientes domésticos, pois poderá causar interferências eletromagnéticas que obrigam 2.4/5 PIFA IPEX 3.97 5.44 o usuário a tomar medidas necessárias para minimizar estas GHz Wi-Fi interferências.
- Page 22 5150 to 5350 MHz frequency range in the following countries: Simplified EU Declaration of Conformity Latviski This declaration is only valid for Fortinet products (including, Questo prodotto è conforme alla Direttiva 2014/53/EU. combinations of software, firmware and hardware) provided by Fortinet or Fortinet’s authorized partners to the end Lietuvių...
- Page 23 1 (“License © 2016 Fortinet, Inc., All Rights reserved. Contents and terms are of your failure to comply with these terms or in the event Fortinet Grant”) above. You expressly agree and acknowledge that Fortinet subject to change by Fortinet without prior notice.
- Page 24 Software or Hardware, there shall be no warranty on such Software. the contrary, distributors, resellers and other Fortinet partners need not be new or of an identical make, model, or part; Fortinet 7. Disclaimer of Other Warranties and Restrictions. (a) are not agents of Fortinet and (b) are not authorized to bind...
- Page 25 SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE the United States Government shall be governed solely by the authorized to be used (a) has been altered, except by Fortinet LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE...
- Page 26 In no event will the copyright stating that you changed the files and the date of any change. amendment or other agreement to be binding on Fortinet, such holder for the open source software be liable to you for damages, b) You must cause any work that you distribute or publish, that in amendment or other agreement must be signed by Fortinet’s...
- Page 27 one of the following: the Program), the recipient automatically receives a license from a version number of this License which applies to it and “any later a) Accompany it with the complete corresponding machine- the original licensor to copy, distribute or modify the Program version”, you have the option of following the terms and conditions readable source code, which must be distributed under the terms subject to these terms and conditions.
- Page 28 A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER of it, thus forming a work based on the Library, and copy and form under the terms of Sections 1 and 2 above provided that you PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN distribute such modifications or work under the terms of Section 1 accompany it with the complete corresponding machine-readable ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 29 executables containing that work also fall under Section 6, whether the operating system on which the executable runs, unless that obligations under this License and any other pertinent obligations, or not they are linked directly with the Library itself. component itself accompanies the executable. It may happen then as a consequence you may not distribute the Library at all.
- Page 30 of that version or of any later version published by the Free Software Foundation. If the Library does not specify a license version number, you may choose any version ever published by the Free Software Foundation. 14. If you wish to incorporate parts of the Library into other free programs whose distribution conditions are incompatible with these, write to the author to ask for permission.
- Page 31 Create a support account, register and manage your products, download updates, firmware images and release notes, and create technical support tickets. https://support.fortinet.com Fortinet Document Library Up-to-date versions of Fortinet publications for the entire family of Fortinet products. http://docs.fortinet.com Training Services Course descriptions, availability, schedules, and location of training programs in your area.
