hager HZI815 Quick Start Manual

HZI815 / HZI825
Preliminary operations
Check the following upon delivery and after removal
of the packaging:
• Packaging and contents are in good condition.
• The product reference corresponds to the order.
• Contents should include:
- 1 ATSE controller
- 1 set of terminals connectors
+ 1 set of door mounting clips
- 1x Quick Start instruction sheet
This Quick Start is intended for personnel trained in
the installation and commissioning of this product.
For further details refer to the product instruction
manual available on www.hager.com.
This product must always be installed and
commissioned by qualified and approved personnel.
Maintenance and servicing operations should be
performed by trained and authorised personnel.
Do not handle any control or power cables connected
to the product when voltage may be, or may become
present on the product, directly through the mains or
indirectly through external circuits.
Always use an appropriate voltage detection device
to confirm the absence of voltage.
Ensure that no metal objects are allowed to fall in the
cabinet (risk of electrical arcing).
Failure to observe good enginering practises as well
as to follow these safety instructions may expose the
user and others to serious injury or death.
Clac !
1
z Automatic Transfer Switching
Equipment Controller for HIB4xxM
Installation and commissioning controller HZI815 / HZI825
Step 1
Installation
1,5 - 3
Risk of electrocution, burns or injury to persons
and / or damage to equipment. Risk of damaging
the device In case the product is dropped or
damaged in any way it is recommended to
replace the complete product.
Step 2 Step 3
Connection Programming
138
6LE007316Ab
