Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
This device may not cause harmful interference
This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy. If this equipment is not installed
and used in accordance with the manufacturer's instructions, it may cause harmful
interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user's authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for audio noise emissions from
digital apparatusses set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Manufacturer's Disclaimer Statement
The information in this document is subject to change without notice and does not represent a
commitment on the part of the vendor. No warranty or representation, either expressed or implied,
is made with respect to the quality, accuracy or fitness for any particular purpose of this document.
The manufacturer reserves the right to make changes to the content of this document and/or the
products associated with it at any time without obligation to notify any person or organization of
such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental
or consequential damages arising out of the use or inability to use this product or documentation,
even if advised of the possibility of such damages. This document contains materials protected
by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted
in any form, by any means or for any purpose without expressed written consent of it's authors.
Product names appearing in this document are mentioned for identification purposes only. All
trademarks, product names or brand names appearing in this document are registered property
of their respective owners.
Printed in Taiwan
December 1998
PO ST-CON SUMER
RECYCLED PAPER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-6BPV and is the answer not in the manual?

Questions and answers

Summary of Contents for CHAINTECH CT-6BPV

  • Page 1 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 2: Table Of Contents

    T T T T T ab ab le of Contents le of Contents le of Contents le of Contents le of Contents Chapter 1 Introduction ................. 1 Product Specifications ............1 Package Contents ..............4 Mainboard Layout ..............5 Connector and Jumper Reference Chart ......6 Chapter 2 Hardware Setup ..............
  • Page 3 Feature Explanations SeePU Technology ................. 9 Software Power-off Control ..............11 Power-On By Modem ..............11/32 Over-ride Power Button ................ 12 Wake Up On LAN ................14/32 Creative's SB-LINK Sound ..............14 Power-On Function ................. 16/38 Poly-fuse Over Current Protection ............17 Power Failure Recovery ...............
  • Page 4 Memo Memo Memo Memo Memo...
  • Page 5: Chapter 1 Introduction

    Introduction Chapter 1 Introduction 1-1 Product Specifications Mainboard Processor ® ® - Supports up to 450MHz Intel Pentium II processors and Celeron processors up to 433MHz - Slot 1 CPU socket with universal retention mechanism for SEPP/SECC/SECC2 - High efficiency Switching Power Module (1.8v ~ 3.5v, 0.1v increments) - Supports 66/100 MHz system clock speeds Chipset - Intel 82440 BX or 82440ZX-100 (Option) two chip AGPset...
  • Page 6 Chapter 1 Back-Panel I/O Connector - PS/2 Mini-DIN Keyboard and Mouse ports - Two USB ports (Rear application) - One D-Sub 9-pin male Serial port - One 9-pin header for external Serial port * - One D-Sub 15-pin VGA port - One 15-pin header for external Game/MIDI support * - One S-Video and one composite connectors for TV-out (Optional) - One shield RJ-45 phone jack with three LED indicators (Optional)
  • Page 7 Introduction Board Dimensions - Micro NLX factor, 205mm x255mm, 4 layers - Four mounting holes Advanced Management Features Innovative SeePU Technology (Jumper free CPU installation via BIOS) - Provides 75/83/103/112/124/133MHz host clock frequency for over-clocking possibility - Software power off control for Win95,Power-on by modem, Power on by RTC-alarm, Power-on by password or hotkey, Over-ride power button, Power failure recovery, Blinking Power-LED in Suspend etc.
  • Page 8: Package Contents

    Chapter 1 1-2 Package Contents 1-2 Package Contents 1-2 Package Contents 1-2 Package Contents 1-2 Package Contents This product comes with the following components: One mainboard On-board Slot 1 retention mechanism and four screws One 40-pin IDE ribbon cable connector (Figure 1-1a) One 50-pin IDE ribbon cable connector w/adapter (Figure 1-1b) One 34-pin floppy disk drive ribbon cable connector (Figure 1-2a) One User's Manual...
  • Page 9: Mainboard Layout

    Introduction 1-3 Mainboard Layout 1-3 Mainboard Layout 1-3 Mainboard Layout 1-3 Mainboard Layout 1-3 Mainboard Layout S -conn. T V -out P rin te r R J-45 L ine -in L ine -o ut U S B 1 V G A C O M 1 U S B 2 M ou se...
  • Page 10: Connector And Jumper Reference Chart

    Chapter 1 1-4 Connector and Jumper Reference Chart Jumper & Function Connector No. WOL (Wake on LAN) Connector Creative's SB-LINK Sound Connector CN3 (riser card) ATX Power Supply Connector Game/MIDI Header J1 (riser card) Slim CD-ROM Connector Over-ridePower Button Connector Power Indicator LED Connector Green Switch/Green LED Connector System Reset Switch Connector...
  • Page 11: Chapter 2 Hardware Setup

    Hardware Setup Chapter 2 Chapter 2 Chapter 2 Chapter 2 Chapter 2 Har d d d d d ware Setup ware Setup ware Setup ware Setup ware Setup If your mainboard has already been installed in your computer you may still need to refer to this chapter if you plan to upgrade your system's hardware.
  • Page 12: Installing An S.e.c. Processor In Slot 1

    Chapter 2 2-2 Installing an S.E.C. Processor in Slot 1 1. Insert the Pentium II processor into the retention mechanism. Press evenly and gently until the snaps on the upper side of the processor have been inserted into the holes at the top of the retention mechanism. 2.
  • Page 13: Setting Your Cpu's Parameters( Seepu Technology)

    Hardware Setup 2-3 Setting Your CPU's Parameters( SeePU Technology) SeePU is a new user friendly technology that enables the user to setup a mainboard's CPU parameters through an easy to use BIOS setup procedure. It is no longer necessary to make many jumper settings as with conventional mainboards. 1.
  • Page 14 Chapter 2 You do not need to make voltage settings because SeePU automatically sets your CPU voltage. ROM PCI / ISA BIOS (2A69JC39) SeePU & HARDWARE MONITORING AWARD SOFTWARE, INC. ***** CPU Setup ****** CPU Type : User's Define Frequency Ratio : 3.5X CPU Bus Frequency : 100MHz...
  • Page 15: Connector And Jumper Settings

    Hardware Setup 2-4 Connector and Jumper Settings Connectors are used to link the system board with other parts of the system, including the power supply, the keyboard, and the various controllers on the front panel of the system case. The power supply connector is the last connection to be made while installing a mainboard.
  • Page 16 Chapter 2 Front Panel Connector Set (J8) A through F A. Over-ride Power Button Connector The power button on the ATX chassis can be used as a normal power switch as well as a button to activate Advanced Power Management Suspend mode. This mode is used for saving electricity when the computer is not in use for long periods of time.
  • Page 17 Hardware Setup E. Speaker Connector Definition Speaker Signal +5V DC F. IDE Activity LED Connector The IDE activity LED lights up whenever the system reads/writes to the IDE devices. CPU/System Cooling Fan Connectors FAN/J11(riser card) These added connectors allow the fan to draw their power from the mainboard instead of the disk drive connector.
  • Page 18 Chapter 2 WOL (Wake-on-LAN) Connector (CN1) Enable the Wake Up On LAN selection in BIOS's Power Management Menu to use this function. The capability to remotely manage PCs on a network is a significant factor in reducing administrative and ownership costs. Magic Packet technology is designed to give WOL (Wake- on-LAN) capability to the LAN controller.
  • Page 19 Hardware Setup PS/2 Mouse and Keyboard Ports If a PS/2 mouse is used, BIOS will automatically detect and assign IRQ12 to the PS/2 mouse. Definition Data No Connect Ground +5V (fused) Clock No Connect Clear CMOS Data Jumper (JP2) Normal (default) Clear CMOS data To clear the contents of the CMOS, please follow the steps below.
  • Page 20 Chapter 2 IrDA IC Sensor (IR1) The built in Infrared LED sensor must be beam dircetly toward another Infrared sensor at a distance of 1.5 meter in order to transmit and receive data. USB(Universal Serial Bus) Ports If you want to use a USB keyboard, you must enable the USB keyboard support function in BIOS's Integrated Peripherals menu (See Section 3-8).
  • Page 21 Hardware Setup Poly-fuse Over Current Protection The poly-fuse protects the system from dangerous voltages the system might be exposed to via the keyboard or USB connectors. In case of such exposure, the poly- fuse will immediately be disconnected from the circuit, just like a normal fuse. After being disconnected for a short period of time, the poly-fuse will return to its normal state, after which the keyboard or USB can function properly.
  • Page 22: Main Memory Configuration

    Chapter 2 2-5 Main Memory Configuration The DRAM memory system consists four banks and the memory size ranges from 16~256 MBytes. If you only use one bank it does not matter which one you use and if you use two or more banks, it does not matter which bank you install first. DRAM Specifications DIMM type: 3.3V, Synchronous DRAM...
  • Page 23: Chapter 3 Award Bios Setup Program

    Award BIOS Setup Program Chapter 3 Chapter 3 Chapter 3 Chapter 3 Chapter 3 3 3 3 3 3 Award BIOS Setup Program Award's BIOS ROM has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM so that it can retain the setup information, even when the power is turned off.
  • Page 24: Standard Cmos Setup

    User's Manual 3-1 Standard CMOS Setup The Standard CMOS Setup allows users to configure system components such as hard disk drive, floppy disk drive and video display as well as date, time and boot- up error signaling. This configuration menu should be changed when installing a mainboard for the first time, changing hardware in your system such as the HDD, FDD, video display, or when the CMOS data has been lost or contaminated.
  • Page 25 Award BIOS Setup Program Type (Auto/User/None): Use the fields under the Type column to determine the method you will use to configure the IDE devices. If you choose Auto, BIOS will automatically detect and make optimal settings for most IDE hard drives. The mainboard manufacturer recommends that you choose Auto for all drives.
  • Page 26 User's Manual Large - for IDE drives that do not support LBA and have more than 1024 cylinders. Try this setting if your hard disk does not operate properly with the LBA setting. Large mode is not supported by all operating systems, i.e., only certain versions of DOS support large mode.
  • Page 27: Bios Features Setup

    Award BIOS Setup Program 3-2 BIOS Features Setup By choosing the BIOS Features Setup option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard. ROM PCI / ISA BIOS (2A69JC39) BIOS FEATURES SETUP AWARD SOFTWARE, INC.
  • Page 28 User's Manual B. CACHE CONTROL CPU Internal Cache/External Cache Cache memory is much faster than conventional DRAM system memory. These fields allow you to enable or disable the CPUs Level 1 built-in cache and Level 2 external cache. Both settings are left enabled to significantly increase the performance of your computer.
  • Page 29 Award BIOS Setup Program Typematic Rate (Chars/Sec) The typematic rate sets the rate at which characters on the screen repeat when a key is pressed and held down. Typematic Delay (Msec) The typematic delay sets how long after you press a key that a character begins repeating.
  • Page 30: Chipset Setup

    User's Manual 3-3 Chipset Setup By choosing the Chipset Setup option from the CMOS Setup Utility menu(Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard. ROM PCI / ISA BIOS (2A69JC39) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC.
  • Page 31 Award BIOS Setup Program B. 8-bit I/O Recovery Time & 16-bit I/O Recovery Time Back-to-back CPU or PCI master originated 8-bit and 16-bit cycles have an arbitrary delay of at least 3.5 system clock cycles. This category is used to add additional recovery delay between 8-bit and between 16-bit cycles.
  • Page 32: Power Management Setup

    User's Manual 3-4 Power Management Setup This section provides information on the Green PC power management funtcions. By choosing the Power Management Setup option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the ROM PCI / ISA BIOS (2A69JC39) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC.
  • Page 33 Award BIOS Setup Program The computer runs in Normal operation mode until the Doze timer expires, at which point the computer enters Doze mode. If no external activity occurs, the computer will go into Standby and Suspend modes when their respective timers expire.
  • Page 34 User's Manual V/H SYNC+Blank - The system turns off the vertical and horizontal synchronization ports, writes blanks to the VGA buffer and the monitor's electron gun turns off. This function requires a monitor with Green features in order to take advantage of the power saving function. If you enable this function and do not have a Green monitor, the result will be the same as if you had selected Blank.
  • Page 35 Award BIOS Setup Program H. Standby Mode The Power Management function must not be set to disabled to enable this function. If the system runs in Doze mode and the Standby timer expires, the system will enter Standby mode. In Standby mode, the hard disk drive and the monitor shut off while all other devices still operate at full speed.
  • Page 36 User's Manual N. Power On By Modem When enabled, a modem that receives a call will wake up the system from soft off and green mode. You should connect the modem to the COM port and turn on the resume event in green mode. O.
  • Page 37: Pnp/Pci Configuration

    Award BIOS Setup Program 3-5 PNP/PCI Configuration This section provides IRQ and DMA setting information. By choosing the PNP/ PCI Configuration option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard.
  • Page 38 User's Manual C. Reset Configuration Data When enabled the system BIOS will clear/reset the ESCD during POST. After clearing the ESCD, the BIOS will then change this item's value to Disabled. Otherwise, the ESCD data will become useless. D. IRQ#/DMA# assign to When resources are controlled manually, you can assign each system interrupt &...
  • Page 39: Load Setup Defaults

    Award BIOS Setup Program 3-6 Load Setup Defaults Load Setup Defaults loads the default system values directly from the CMOS Setup Utility menu (Figure3-1). If the stored record created by the setup program becomes corrupted and therefore unusable, these defaults will be loaded automatically when you turn on the computer.
  • Page 40: Seepu & Hardware Monitoring

    User's Manual 3-7 SeePU & Hardware Monitoring By choosing the SeePU & Hardware Monitoring option from the CMOS Setup Utility menu(Figure 3-8), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard. ROM PCI / ISA BIOS (2A69JC39) SeePU &...
  • Page 41: Integrated Peripherals

    Award BIOS Setup Program 3-8 Integrated Peripherals This section provides information on setting peripheral devices. By choosing the Integrated Peripherals option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard.
  • Page 42 User's Manual B. USB Keyboard Support If your current operating system doesn't support USB drivers (i.e., DOS) this function must be enabled for USB keyboard operation in these operating systems. When using a USB keyboard this function is automatically Enabled during bootup regardless of its setting in BIOS.
  • Page 43: Supervisor Password & User Password Setting

    Award BIOS Setup Program 3-9 Supervisor Password & User Password Setting There are four different variables that control password settings. The first two are located under the Security Option function in BIOS Features Setup Menu (Figure 3-3). When the Security Option function is set to Setup, a password is required to enter BIOS and change BIOS settings.
  • Page 44 User's Manual B. Set Both Supervisor Password and User Password Figure 3-11 Set Both Supervisor and User Password...
  • Page 45: Ide Hdd Auto Detection

    Award BIOS Setup Program 3-10 IDE HDD Auto Detection This utility can automatically detect IDE hard disk type and parameters. The detection process take about 5 seconds for each physical drive. After the utility detects the disk drive, type Y and press [Enter] to automatically load the parameters in the Hard Disk section of the Standard CMOS Setup menu.
  • Page 46 User's Manual M e m o M e m o M e m o M e m o M e m o...
  • Page 47: Chapter 4 Brief Software Driver Guide

    Brief Software Driver Guide Chapter 4 Chapter 4 Chapter 4 Chapter 4 Chapter 4 Brief Software Driver Guide The Mainboard Software Guide is found on the CD-ROM that is enclosed with your mainboard and is a PDF file which must be viewed with Adobe's freeware called ®...
  • Page 48 User's Manual Memo Memo Memo Memo Memo...
  • Page 49: Chapter 5 Ess Solo-1 Pci Audio Sub-System

    Chapter 5 Audio Subsystem 5-1 Feature ESS PCI audio Solo-1 (ES1938S) subsystem on a single chip. Advance wavetable synthesizer using wavedata on the system memory. Up to 48KHz programable sample rate for record and playback. Intergrated Spatializer 3D effects Processor. Advance power management meets ACPI standards.
  • Page 50 User's Manual Memo Memo Memo Memo Memo...
  • Page 51: Chapter 6 Ati Rage Pro-Turbo/Rage128-Vr Agp

    Chapter 6 ATI Rage Pro-Turbo/Rage128-VR AGP The board supports both ATI Rage Pro-Turbo or Rage 128-VR AGP chip for mainstream and highend workstation graphics market. ATI Rage Pro-Turbo AGP is a cost sentive and highly intergrated 2D, 3D and video accelerator. The ATI Rage 128-VR AGP is a high performance AGP chip with enhanced 2D, 3D, and video accelerator with AGP 2X.
  • Page 52 Chapter 6 6-5 Jumper Setting - On-board VGA Chip Jumper (See Section 2-4) 6-6 Reference Direct3D - Direct3D is the next genaration of real-time, interactive 3D technology for mainstream computer user on internet. Direct 3D is a complete set of real- time 3D graphics services that delivers fast software-based rendering of the full 3D pipiline (transformations, lighting and rasterization) and transparent access to hardware acceleration.
  • Page 53 Introduction Appendix I Appendix I Appendix I Appendix I Appendix I On Board I/O Addresses & IRQ Maps System Resource I/O Address 1. Timer IRQ0 040, 043 2. Keyboard IRQ1 060, 064 3. Programmable INT IRQ2 0020, 0021, 00A0, 00A1 4.
  • Page 54 User's Manual Memo Memo Memo Memo Memo...
  • Page 55 Appendix II Appendix II Appendix II Appendix II Appendix II MAINBOARD S -con n. T V -out P rinter R J-45 L ine -in L in e -o u t U S B 1 V G A C O M1 U S B 2 FAN: CPU cooling fan connector M ou se...
  • Page 56 Memo Memo Memo Memo Memo...
