Page 1: Troubleshooting Guide
TROUBLESHOOTING GUIDE Fourth Edition – February 2006 LAUNDRY PRODUCTS Combo Washer Dryer MODELS EZ3710CEE (WHITE / PLATINUM) - VENTLESS EZ1710 V (WHITE / PLATINUM) - VENTING... - Page 2 TABLE OF CONTENTS TROUBLESHOOTING : • INSTALLATION…………..………………….………………….. • WASH CYCLE………………………………..….…………………… 4 - 7 • DRY CYCLE………..……………….……………………………….. 8 - 9...
-
Page 3: Troubleshooting
Problem Possible Cause 1a. Shipping brackets not removed 1b. Machine not leveled 1. Machine 1c. Machine installed on uneven vibrating or floor vibrating noise 1d. Machine installed on wood floor 1e. Rubber cap missing from rear foot 2a. Door not screwed in properly 2. - Page 4 24" above the floor. 1d. Close door firmly, so that it latches. 1e. Set the washer knob to position#3. Switch On the power. Test for 115V AC across Pin#11 of small pressure switch and terminal#2 on the control module.
- Page 5 3a. Filter 3b. Drain hose 3c. Drain 3. Won't drain 3d. Pump 3e. Timer 4a. Not leveled. 4b. Foreign object in tub. 4. Noisy 4c. Shock Absorber. 5a. Shipping brackets attached. 5. Vibrates 5b. Unstable floor 5c. Not leveled properly 5d.
- Page 6 6b. Spinning with water in tub. 6c. Motor (tachometer). 7a. Water supply off. 7b. Filling interrupted. 7. Timer doesn't advance 7c. Timer. 8. Water flows 8a. Water inlet valves leaking. into tub with machine off. 9a. Pressure Switch. 9. Machine overfills.
- Page 7 11. Clothes wet 11a. Water in tub. at end of wash cycle. 11b. Inadequate final spin. TESTING THE DRIVE MOTOR Check Resistance as under Pin 2 & 6 Pin 3 & 7 Pin 4 & 8 11R9 23R0 (Tachometer) door with the other hand. 11a.
- Page 8 Dry Cycle (EZ 3710 / EZ 1710) Problem Possible Cause 1a. No power input. 1. No tumble action. 1b. Door not closed. 1c. Belt. 2a. No Heat coming into the drum 2b. Timer not advanced beyond the cool-down period. 2. Clothes 2c.
- Page 9 If present, valve may be defective. 3f. Disassemble blower housing from tub. Ensure that seals are positioned properly & reassemble. 4a. Use Equator detergent, or other low-suds brand. Measure detergent, using 2 tablespoons or 1/8 cup maximum. 4b. Connect hoses to the proper inlet valves.
- Page 10 COMPANY INFORMATION EQUATOR CONTACT NUMBERS SERVICE, PARTS, ACCESSORIES & DETERGENT ORDERING: (800) 776-3538 TECHNICAL SUPPORT: (888) 935-1565...
