ITEM
Input Voltage
Input Current
Relay Voltage
Relay Current
Fuse Rating
Fuse Rating
Fuse Rating
Standby Current
pH
ORP
Free Chlorine - PPM
Free Chlorine - PPM
ITEM
Elevation
Temperature
Temperature
IP Rating
Pollution
4010758
Conforms to
UL STD 1563
Certified to CSA STD
C22.2 No. 218.1
PoolWarden Manual
DESCRIPTION
Maximum input AC voltage
Maximum input current
Maximum relay voltage
Maximum Relay Current
F1
F2
F3
Maximum operating current
Measurement of pH
Oxidation Reduction Potential
With optional TrueDPD sensor NSF Certified Range 0 to 6.0 PPM 10%
Extended non-NSF Certified Range
Environmental Specifications
DESCRIPTION
Not to be used above
Minimum/Maximum Operating Temperature
Water temperature measurement.
Suitable for Outdoor Use
Pollution Degree
Certifications
•
www.poolwardentraining.com
LIMIT
240 VAC, 50-60 Hz
10 A
240 VAC
2.5 A
5A, 250V, 05x20
5A, 250V, 05x20
1A, 250V, 05x20
0.1 A Max
4.22 to 9.98
0 to 999 mV
6.0 to 9.5 PPM 20%
LIMIT
2000 m
30/110 °F
32 to 122 °F
IPX3
2
NSF/ANSI 50 - Equipment
for Swimming Pools, Spas,
Hot Tubs and Other
Recreational Water Facilities
http://info.nsf.org/Certified/Pools/Listi
ngs.asp?Company=C0214550&Stan
dard=050&
•
530-205-4520
•
6
