Daikin UATQ-C Series Installation Manual
  1. Manuals
  2. Brands
  3. Daikin Manuals
  4. Air Conditioner
  5. UATQ-C Series
  6. Installation manual

Daikin UATQ-C Series Installation Manual

Rooftop package air conditioner
Hide thumbs

Advertisement

Table of Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UATQ-C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daikin UATQ-C Series

Summary of Contents for Daikin UATQ-C Series

  • Page 2 1-CVR IM-5RTC-0315(2)-DAIKIN_EN.2 2 1-CVR IM-5RTC-0315(2)-DAIKIN_EN.2 2 1/14/16 1:55:29 PM 1/14/16 1:55:29 PM...

  • Page 3: Outline And Dimensions

    Weight of corner(kg) Total weight (kg) 1280 1520 1112 1112 1530 1300 CENTER OF GRAVITY Model: UATQ90C Weight of corner(kg) Total weight (kg) 1280 1112 1520 1112 1300 1530 CENTER OF GRAVITY 1-IM-5RTC-0315(2)-DAIKIN-EN.indd1 1 1-IM-5RTC-0315(2)-DAIKIN-EN.indd1 1 1/14/16 1:55:55 PM 1/14/16 1:55:55 PM...
  • Page 4 1800 1630 1988 1052 1800 CENTER OF GRAVITY Model: UATQ180C 1045 Weight at corner(kg) Total weight (kg) 190 190 230 230 1905 1672 1965 1672 1920 1988 CENTER OF GRAVITY 1-IM-5RTC-0315(2)-DAIKIN-EN.indd2 2 1-IM-5RTC-0315(2)-DAIKIN-EN.indd2 2 1/14/16 1:55:56 PM 1/14/16 1:55:56 PM...
  • Page 5 1320 2110 CENTER OF GRAVITY Model: UATQ300C Weight at corner (kg) Total weight 1060 (kg) 270 300 280 240 1090 1120 2410 2030 2110 2430 1320 2110 CENTER OF GRAVITY 1-IM-5RTC-0315(2)-DAIKIN-EN.indd3 3 1-IM-5RTC-0315(2)-DAIKIN-EN.indd3 3 1/14/16 1:55:56 PM 1/14/16 1:55:56 PM...

  • Page 6: Safety Precautions

    Please contact your local dealer for more information. NOTICE Disposal Requirement Dismantling of the unit, treatment of the refrigerant, oil and other parts must be done in accordance with the applicable legislation. 1-IM-5RTC-0315(2)-DAIKIN-EN.indd4 4 1-IM-5RTC-0315(2)-DAIKIN-EN.indd4 4 1/14/16 1:55:57 PM 1/14/16 1:55:57 PM...

  • Page 7: Refrigerant Circuit Diagram

    Capillary Tube HEADER HEADER HEADER DISTRIBUTOR Thermal Expansion Valve Sensor Bulb Note: (a) UATQ120/150/180/210/240/300C consists of 2 circuits in the system. (b) Item no. 9 is applicable for UATQ180/210C only. 1-IM-5RTC-0315(2)-DAIKIN-EN.indd5 5 1-IM-5RTC-0315(2)-DAIKIN-EN.indd5 5 1/14/16 1:55:57 PM 1/14/16 1:55:57 PM...

  • Page 8: Unpacking Procedures

    UNSCREW WOOD SCREWS. REMOVE TOP WOODEN CRATE FOLLOWING BY POLYBAG. REMOVE BRACKETS. REMOVE ALL CARTON BOARDS. REMOVE STOPPER. FASTEN THE SCREWS BACK ON PANEL (4 CORNERS). REMOVE BOTTOM WOODEN CRATE. 1-IM-5RTC-0315(2)-DAIKIN-EN.indd6 6 1-IM-5RTC-0315(2)-DAIKIN-EN.indd6 6 1/14/16 1:55:57 PM 1/14/16 1:55:57 PM...

  • Page 9: Installation Of The Unit

    Unit shown in diagram is UATQ210/240C. Other models will follow the same method in lifting. Spreader bar Lifting beam Chain ! CAUTION Do not install the unit at altitude over 2000m Lifting holes for shackle (4 corners) 1-IM-5RTC-0315(2)-DAIKIN-EN.indd7 7 1-IM-5RTC-0315(2)-DAIKIN-EN.indd7 7 1/14/16 1:55:57 PM 1/14/16 1:55:57 PM...
  • Page 10 Condenser air inlet service, Air filter service air outlet Condenser air inlet Electrical control circuit service & compressor service Condenser air inlet Evaporator coil, Condenser air filter service air inlet 1-IM-5RTC-0315(2)-DAIKIN-EN.indd8 8 1-IM-5RTC-0315(2)-DAIKIN-EN.indd8 8 1/14/16 1:55:58 PM 1/14/16 1:55:58 PM...

  • Page 11: Physical Data

    (1) The entire wiring diagram of unit a. Power supply d. Unit b. Main switch/fuse e. Remote control/Thermostat (field supply) Connection wiring for c. Power supply unit & remote controller wiring for unit g. Earth 1-IM-5RTC-0315(2)-DAIKIN-EN.indd9 9 1-IM-5RTC-0315(2)-DAIKIN-EN.indd9 9 1/14/16 1:55:59 PM 1/14/16 1:55:59 PM...
  • Page 12 • Earth wiring must be connected. • The power supply cord must be equivalent to H07RN-F which is the minimum requirement, and to be used in protective tube. 1-IM-5RTC-0315(2)-DAIKIN-EN.indd10 10 1-IM-5RTC-0315(2)-DAIKIN-EN.indd10 10 1/14/16 1:55:59 PM 1/14/16 1:55:59 PM...
  • Page 13 Model : UATQ60/90C No. Item Description Contactor Capacitor Phase Protector Terminal Block Relay OUT FAN 2 OUT FAN 1 Fuse OUT FAN 4 Transformer DS3 DS2 DS1 ROOM NEUTRAL Timer Control Module 1-IM-5RTC-0315(2)-DAIKIN-EN.indd11 11 1-IM-5RTC-0315(2)-DAIKIN-EN.indd11 11 1/14/16 1:55:59 PM 1/14/16 1:55:59 PM...
  • Page 14 OUT FAN 3 OUT FAN 2 OUT FAN 1 OUT FAN 3 OUT FAN 2 OUT FAN 1 OUT FAN 4 DS3 DS2 DS1 ROOM NEUTRAL DS3 DS2 DS1 ROOM NEUTRAL 1-IM-5RTC-0315(2)-DAIKIN-EN.indd12 12 1-IM-5RTC-0315(2)-DAIKIN-EN.indd12 12 1/14/16 1:55:59 PM 1/14/16 1:55:59 PM...

  • Page 15: Fan Performance Data

    1371 2.58 5000 1167 2.38 1236 2.65 1302 2.93 6000 Italic Font 2.2kW motor (Standard) 3.0kW motor Factory set point Revolutions per minute Cubic feet per minute Motor power output 1-IM-5RTC-0315(2)-DAIKIN-EN.indd13 13 1-IM-5RTC-0315(2)-DAIKIN-EN.indd13 13 1/14/16 1:56:00 PM 1/14/16 1:56:00 PM...
  • Page 16 9000 3.86 4.25 1014 4.66 1065 5.08 1120 5.50 10800 5.21 Italic Font 3.7kW motor 5.5kW motor Factory set point Revolutions per minute Cubic feet per minute Motor power output 1-IM-5RTC-0315(2)-DAIKIN-EN.indd14 14 1-IM-5RTC-0315(2)-DAIKIN-EN.indd14 14 1/14/16 1:56:00 PM 1/14/16 1:56:00 PM...

  • Page 17: Operating Range

    2. When R phase missing, no LED or buzzer will indicate the error, but relay 71 and relay 81 will cut off. ! WARNING • Troubleshooting must be performed by qualified personnel. 1-IM-5RTC-0315(2)-DAIKIN-EN.indd15 15 1-IM-5RTC-0315(2)-DAIKIN-EN.indd15 15 1/14/16 1:56:01 PM 1/14/16 1:56:01 PM...

  • Page 18: Service And Maintenance

    Temperature setting too low. Reset the temperature. No cool air delivered. Temperature setting too high. Set the temperature lower . If the fault persists, please call your authorized local dealer/serviceman. 1-IM-5RTC-0315(2)-DAIKIN-EN.indd16 16 1-IM-5RTC-0315(2)-DAIKIN-EN.indd16 16 1/14/16 1:56:02 PM 1/14/16 1:56:02 PM...
  • Page 19 1-CVR IM-5RTC-0315(2)-DAIKIN_EN.3 3 1-CVR IM-5RTC-0315(2)-DAIKIN_EN.3 3 1/14/16 1:55:29 PM 1/14/16 1:55:29 PM...
  • Page 20 P.O.Box 18674, Jebel Ali Free Zone, Dubai-UAE Tokyo offi ce: Email: info@daikinmea.com JR Shinagawa East Bldg., 2-18-1, Konan, Web: www.daikinmea.com Minato-ku, Tokyo, 108-0075 Japan http://www.daikin.com/global/ Importer for Turkey Allianz Plaza-Kucukbakkalkoy Mah.Kayısdagi Cad.No:1 34750 Atasehir-ISTANBUL / TURKIYE 1-CVR IM-5RTC-0315(2)-DAIKIN_EN.4 4 1-CVR IM-5RTC-0315(2)-DAIKIN_EN.4 4...
