Summary of Contents for Regal Century VGreen 270
- Page 1 VARIABLE SPEED QUICK START GUIDE P R E M I U M E F F I C I E N C Y VA R I A B L E S P E E D M OTO R...
- Page 2 USER INTERFACE OPERATION Display Screen LED Lights Power On Light (Green) Fault Light (Red) Back Button Navigation Buttons Selector Knob Override Buttons NAVIGATION OVERVIEW +, - increases/decreases selected value ←, → navigates to adjustable value (digit) or different menu (SET) accepts the current screen values (BACK) returns to previous program setting and does NOT accept current screen values or clears a message on the screen...
- Page 3 MENU STRUCTURE FOR SELECTOR KNOB POSITIONS 6. SETUP 1. SET CLOCK a. Freeze Protection a. Date and Time i. Enabled/Disabled 2. STEP 1 (Set Schedule) ii. Turn ON Temperature a. Speed, Start Time, Stop Time b. Aux Load Setup 3. STEP 2 (Set Schedule) i.
- Page 4 SET THE CLOCK The first time the user interface is turned ON, the clock must be set to the current time. SET CLOCK MENU BUTTONS Turn the selector knob to SET CLOCK. 2. At any time, the user can press BACK to return to the previous area. 3.
- Page 5 SET THE SCHEDULE Set the Speed and Start/Stop times for the motor in the Set Schedule menu. The schedule is based on a 24-hour cycle and will repeat each day of the week. The highest speed rating for the VGreen 270 motor is 3450 RPM and the lowest is ®...
- Page 6 SETUP Setup allows the user to configure the following parameters: • Freeze Protection • Reset Factory Defaults • Prime Settings • Auxiliary Load Settings • Set Contrast Level Setup Menu Buttons FREEZE PROTECTION Freeze Protection can be either enabled or disabled when the user turns the User Interface selector knob to Setup.
- Page 7 PRIME CONFIGURATION The priming speed and time can be adjusted within this menu. The minimum priming speed is 1500 RPM. The maximum priming time is 10 minutes. Make certain the selector knob points to Setup. Press → two times to change the Prime settings.
- Page 8 “Standard Terms and Conditions of Sale”). These terms and conditions of sale, disclaimers and limitations of liability apply to any person who may buy, acquire or use a Regal product referred to herein, including any person who buys from a licensed distributor of these branded products.
