Active HD CCTV Receiver Balun
Quick Installation Guide
1. Overview
The Active HD CCTV Receiver Balun (IC553A) allows one HD-SDI signal with
power and control lines to be transmitted up to 150 ft. (45 m) via a CAT6 cable at
HD resolution (720p, 1080i) in a point-to-point configuration. The balun supports
transmission of SDI digital video (including embedded Audio and/or Time Code)
within facilities and between video equipment. The IC553A is installed at the
receiver location and used with the IC552A installed at the remote camera
location. Use the baluns in HD CCTV surveillance systems and HD-SDI camera
systems.
2. Installation
One receiver-side balun and one transmitter-side balun is needed to establish a
point-to-point connection via a single UTP cable. The transmitter side must have a
an IC552A. Power for the unit may be provided via the remote camera power (12
VDC or 24 VAC) if present, or via the external 5-VDC power supply that is includ-
ed with the IC553A.
To install the balun, perform the following steps:
CAUTION: Do not attempt to open the housing. There are no user-serviceable
parts inside the balun. Opening the unit will void your warranty.
CAUTION: Do not connect the IC553A to a telecommunication outlet wired to
unrelated equipment. Making such a connection may damage the
equipment and/or the balun. Verify that the desired twisted pairs are
not being used for other LAN or telephone equipment.
Customer
Support
Information
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax
724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,
PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com
codes
codes
codes
BLACK BOX
March 2009
IC553A
codes
codes
codes
®
Advertisement
Table of Contents
Related Manuals for Black Box IC553A
Summary of Contents for Black Box IC553A
- Page 1 ® 1. Overview The Active HD CCTV Receiver Balun (IC553A) allows one HD-SDI signal with power and control lines to be transmitted up to 150 ft. (45 m) via a CAT6 cable at HD resolution (720p, 1080i) in a point-to-point configuration. The balun supports transmission of SDI digital video (including embedded Audio and/or Time Code) within facilities and between video equipment.
- Page 2 2. Verity that all wiring are pinned “straight-through,” have four twisted pairs, and have the standard Ethernet RJ-45 plug. 3. Connect the IC553A balun to an HD-SDI receiver (such as a monitor or DVR). Use a 3-foot, 1-m, 75-ohm coax cable, for the SDI signal. Connect all wires using 24 AWG or lower gauge.
- Page 3 Camera is drawing too much NOTE: Power available at 12 V is very limited. power. Use different equipment. NOTE: If you still cannot diagnose the problem, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. Page 3 724-746-5500 | blackbox.com...
- Page 4 150 feet (45 m), maximum for CAT6 UTP; NOTE: Maximum distance is a function of the receiving equipment and cable. Dedicated CAT5e/6 cables are recommended with no patch panels. NOTE: The IC553A balun will not work in 3G (1080p). Enclosure ABS UL94HB fire-retardant plastic Environment...
