Owners Manual
ORIGINAL INSTRUCTIONS
Head Office:
P.O. Box 2018
Hilton Highway, Washdyke
Timaru, New Zealand
Telephone (03) 688 2029
Facsimile (03) 688 2821
Enviro DD35
Australian Branch:
4B Silverton Close
Laverton North 3026
Melbourne, Australia
Telephone (03) 9314-9666
Facsimile (03) 9314-6810
Pt. No. 67439
Issue 1120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enviro DD35 and is the answer not in the manual?

Questions and answers

Related Manuals for Duncan Enviro DD35

Summary of Contents for Duncan Enviro DD35

  • Page 1 Owners Manual Enviro DD35 ORIGINAL INSTRUCTIONS Head Office: Australian Branch: P.O. Box 2018 4B Silverton Close Hilton Highway, Washdyke Laverton North 3026 Timaru, New Zealand Melbourne, Australia Pt. No. 67439 Telephone (03) 688 2029 Telephone (03) 9314-9666 Issue 1120 Facsimile (03) 9314-6810...

  • Page 3: Table Of Contents

    Enviro DD35 Contents Page ........

  • Page 4: Introduction

    Introduction Acquisition & Warranty On delivery of your new Duncan Enviro DD35 please check that the machine is not damaged. In cases of shipping damage, please ask your dealer to arrange for the appropriate claim to be lodged immediately. Assemble any parts supplied loose and inspect your machine with the aid of this manual to familiarise yourself with its features.

  • Page 5: Description Of Machine

    Description of Machine The Duncan ‘Enviro DD35’ is a Double Disc drill. The large split hopper is mounted on a robust frame accommodating large diameter tyres. Sowing depth is controlled by adjusting the hydraulic ram as required. The quality European air metering units handle all seeds from turnip and rape through to peas and maize and permits easy calibration.

  • Page 7: Dimensions & Capacities

    ‘Enviro DD35’ Dimensions & Capacities Dimensions & Capacities 27 Run Width (over wheels /mm) 3580 Height (Groundwheels up /mm) 2430 Machine Length (mm) 4190 Tyre Size 10.0/75-15.3 (18 ply AW702) Recommended Tyre Pressure 7 bar (101 psi) Maximum speed (km/hr)

  • Page 8: Safety Symbols On Machine

    ‘Enviro DD35’ Safety ATTENTION On the machine important safety information is indicated by these symbols. These highlight general safety aspects in regard to the machine rather than specific hazards. Do not ride or allow passengers on the machine. Under no circumstances are passengers to be permitted on the machine while it is in operation or being transported.

  • Page 9: Safety - General

    ‘Enviro DD35’ Safety SAFETY - General This section of the manual offers general guidelines for the safe operation of machinery. It does not replace N.B. Throughout this local safety regulations. These guidelines were current at manual important safety the time of publication, but may be superseded by later information is indicated regulations.

  • Page 10: Appropriate Dress

    ‘Enviro DD35’ Safety SAFETY - General (Continued) Appropriate Dress Wear close fitting clothing and avoid rings or other forms of jewellery which could become caught in the machinery. People with long hair must have it securely fixed and confined close to the head.

  • Page 11: Handle Agricultural Chemicals Safely

    ‘Enviro DD35’ Safety SAFETY - General (Continued) Handle Agricultural Chemicals Safely All farm chemicals should be stored, used, handled and disposed of safely and in accordance with the supplier’s/ manufacturer’s recommendations. Read the product label before using, noting any warnings or special cautions, including any protective clothing or equipment that may be required, ie.

  • Page 12: Practise Safe Maintenance

    ‘Enviro DD35’ Safety SAFETY - General (Continued) Practice Safe Maintenance Keep the machine in safe working condition. Routine maintenance and regular servicing will help reduce risks and prolong the life of the machine. General Maintenance Accidents occur most frequently during servicing and repair. The...

  • Page 13: Safety - Machine Specific

    Safety SAFETY - Machine Specific This section of the manual gives specific guidelines for the safe operation of the Enviro DD35. These guidelines were current at the time of publication, but may be superseded by later circumstances. They do not necessarily cover every possible hazard and must be read in conjunction with the SAFETY - General section (Page 7 to 10).
  • Page 14 ‘Enviro DD35’ Safety SAFETY - Machine Specific (Continued) Hazard Points on the Enviro DD35 (Continued) For guard locations on machine, refer Page 13. Transport The two wheels located at the sides of the machine are for the purpose of controlling sowing depth. These are also used to support the machine weight during transport (while linked to the tractor).

  • Page 15: Safety Decals & Safety Guards

    ‘Enviro DD35’ Safety SAFETY - Machine Specific (Continued) Item Decal/Guard Pt. No. Qty ‘No Ride’ 43900 ‘Pinch Point/Moving Parts’ 43901 ‘Slippery When Wet’ 43902 ‘Keep Clear’ 43904 Jockey Drive Swing Guard 25745 ‘40 km/hr’ 43912 Lift Point’ 14389 Pt. No. 67439...

  • Page 16: Transport

    ‘Enviro DD35’ Transport Transport Fig 1 Raise the drill into the transport position and hold at the full extent of the rams for a few seconds to allow cylinders to rephase/equalise. Important - To avoid machine damage due to drill lowering during transport, always close the hydraulic valve on the drawbar.

  • Page 17: Read Before Operation

    ‘Enviro DD35’ Read Before Operation Components Referred to in the Pre-Calibration Setup and Calibration Process The following pages describe how to set the machine up for calibration, the calibration process and subsequent adjustments to obtain the desired seed and/or fertilizer output.

  • Page 18: Pre-Calibration Setup Flowchart

    ‘Enviro DD35’ Pre-Calibration Setup normal/fine toggle Start Empty boxes and clear old seed and fertilizer from high (idler in) metering unit. low (idler out) Is seed size between 4 and 10mm? Locate product in 'Normal' Locate product in 'Fine' seed seed table.

  • Page 19: Calibration Procedure

    ‘Enviro DD35’ Calibration Seed Calibration The calibration test should be done to confirm the settings of the required seed rate and is done with the drill stationary and level with the fan off. The metering units must be set prior to filling with seed.

  • Page 20: Hand Crank Turns For Seed Rate Calibration

    ‘Enviro DD35’ Calibration Hand Crank Turns for Seed Rate Calibration Turns Turns Machine Sowing for 1/40 for 1/10 Size Spacing(mm) Width (m) Hectare Hectare 27 Run 3.375 Weigh the seed collected during the test in kilograms. Caution: Scales must be accurate to 2 grams, as any error will be multiplied by either 10 or 40, giving inaccurate calibration results.

  • Page 21: Calibration Deviations

    ‘Enviro DD35’ Calibration Wheel Slip Deviations It is always possible with rubber tyred drills in extreme ground conditions to get wheel slip. Not normally a problem with cleated type tyres in good condition, but more so in the arable situation with the less agressive tread patterns.

  • Page 22: Sowing Chart -Normal Seed

    ‘Enviro DD35’ Sowing Chart Normal...

  • Page 23: Sowing Chart -Fine Seed

    ‘Enviro DD35’ Sowing Chart Fine FINE SEED (toggle 'FINE') 27R DD35 SPECIFIC Setting PRODUCT GRAVITY (kg/l) Position> 2.5 12.5 17.5 22.5 RATE ONCE SET DO NOT REDUCE/CLOSE WITH SEED IN BIN** Lucerne (Alfalfa) 0.9 2.6 3.9 10.9 12.1 13.1 Turnip 0.9 1.9 2.9...

  • Page 24: Airflow & Fan Speed

    ‘Enviro DD35’ Airflow & Fan Speed Airflow and Fan Settings 1. Hydraulic Fan -connect the hoses in the following order: First - connect Zero pressure Case Drain 3/8” hose (1/2” BSP Female QR) to hydraulic reservoir * Second -connect Motor Return 3/4” hose (3/4” BSP Female QR) to tractor high flow low pressure return port.

  • Page 25: Operation

    Operation General Operation Guidelines Hydraulic Fan -connect the hoses in the following order: First - connect Zero pressure Case Drain 3/8” hose (1/2” BSP Female QR) to hydraulic reservoir * Second -connect Motor Return 3/4” hose (3/4” BSP Female QR) to tractor high flow low pressure return port.

  • Page 26: Depth Control

    ‘Enviro DD35’ General Operation Sowing Depth Control The sowing depth is dependent on: 1 The wheel height in relation to the chassis 2 Tyre pressure 3 Ground condition i.e. hard or soft The wheel height in relation to the chassis is controlled using the threaded depth adjustment collar (1) on the non-drive wheel leg ram.

  • Page 27: Farmscan Jackal Settings

    ‘Enviro DD35’ Jackal Areameter Farmscan Jackal v3.5 Settings Setup Refer to the manual supplied with your Farmscan Jackal kit for information and operation. Farmscan Jackal v3.5 Factory Setup for Enviro DD30 Air Refer to the Farmscan Jackal v3.5 manual. Input 1 -Three wire proximity sensor for ‘Area/Speed Wheel’ measurement taken from shaft on drive pedestal.

  • Page 29: Blank Page For Your Calibration Notes

    Enviro DD35 Calibration Notes Pt. No. 67439 Issue 1120...

  • Page 30: Maintenance & Care

    ‘Enviro DD35’ Maintenance & Care Maintenance & Care General Safety and Accident Prevention Advice Make sure that if the tractor remains attached to the drill that the ignition key is removed. During maintenance the drill should be supported in such a manner that if hydraulic failure was to occur the machine would still be adequately supported.

  • Page 31: Lubrication Instructions

    ‘Enviro DD35’ Maintenance & Care Maintenance & Care - Lubrication Instructions Precautions with Grease Greases should not be mixed as the structure may be weakened by the mixes of different types of thickener, which may cause softening and loss of grease from the bearings by running out.

  • Page 32: Maintenance Schedule

    ‘Enviro DD35’ Maintenance & Care Maintenance & Care - Lubrication Instructions Daily Weekly Pre Season Components (or after 20Ha) (or after 75Ha) (or 500 Ha) Depth Adjustment Collar ● ● ● Wheel Nuts ● ● ● Pivot Pin Fasteners ●...
  • Page 33 ‘Enviro DD35’ Maintenance & Care Maintenance Schedule (continued) 6 Framework The framework structure should be inspected annually for defects, i.e., cracks in members or welded connections. The framework should be cleaned prior to the inspection. 7 Metering Units Ensure that the metering units are clean and that the rubber sealing lip is not damaged.

  • Page 34: Storage

    ‘Enviro DD35’ Maintenance & Care Maintenance & Care (Continued) Preparing the Machine for Storage. Locate on a dry level surface. The machine should be stored wherever possible so the rams are not supporting any weight. The drive chains should be lubricated with suitable roller chain lubricant before prolonged periods of storage.

  • Page 35: Troubleshooting/Maintenance Notes

    ‘Enviro DD35’ Troubleshooting Problem Possible Cause Action Refer to Page… Jockey wheel under inflated Check pressure Are the Jackal meter settings correct? Check settings Has the setup/calibration procedure been Check setup and followed correctly? recalibrate Over Sowing Gearwheel position incorrect...

  • Page 36: Commisioning/Troubleshooting Phasing Rams

    ‘Enviro DD35’ Phasing Cylinders Commisioning Phasing Cylinders 1. General (a) The cylinders will re-phase in both directions. Each piston is fitted with 2 poppet valves which open at the end of the stroke to allow oil to bypass the piston. The bypass of oil at the end of the stroke allows for initial bleeding of the system and re-phasing in operation.
  • Page 37 ‘Enviro DD35’ Phasing Cylinders Commisioning Phasing Cylinders (continued) 3. Fault Finding (continued) 2. Cylinders moving at different rates (a) Check that there is no air in the system. Raise and lower the machine; all cylinders should move at the same time, any lag indicates that there is air in the system. Re-bleed the system if necessary.
  • Page 38 Enviro DD35 Maintenance Notes...
  • Page 39 Pt. No. 67439 Issue 1120...

  • Page 41: Parts List

    Parts List ‘Enviro DD35 Air’ Seed Drill Head Office: Australian Branch: P.O. Box 2018 4B Silverton Close Hilton Highway, Washdyke Laverton North 3026 Timaru, New Zealand Melbourne, Australia Telephone (03) 688 2029 Telephone (03) 9314-9666 Facsimile (03) 9314-6810 Facsimile (03) 688 2821 Pt.
  • Page 42 ‘Enviro DD35’ Complete Assembly...
  • Page 43 ‘Enviro DD35’ Complete Assembly ITEM PART No. DESCRIPTION Refer Page 42-45 Main Frame & Drawbar Assembly Refer Page 46 Wheel Leg Refer Page 50-57 Disc Assemblies Refer Page 58-63 Seed Metering Drive Pedestal Refer Page 64-65 Box Mounting Frame Refer Page 66-67 Footboard &...
  • Page 44 ‘Enviro DD35’ Mainframe and Drawbar 13 14 11 12 23 24 25 26...
  • Page 45 ‘Enviro DD35’ Mainframe and Drawbar ITEM PART No. DESCRIPTION 74246 3,5m DD Enviro Mainframe 27R 60033 Drawbar Welded Assembly 4800315 Hose Support 60094 Drawbar Axle 45285 Roll Pin 63115 Centre Hitch Welded Assembly 60405 Towing Eye Assembly 26577 LH Support Stay...
  • Page 46 ‘Enviro DD35’ Mainframe and Drawbar Note: Drawbar hydraulic parts can be purchased as a kit. The part number is 26720K.
  • Page 47 ‘Enviro DD35’ Mainframe and Drawbar ITEM PART No. DESCRIPTION Drawbar Turnbuckle Parts 43395 H/D Ratchet Turnbuckle 47254 Bolt 1” UNF x 5” HT 47251 Bolt 1” UNF x 3.5” HT 47552 1” UNF Nyloc Nut Drawbar Hydraulic Parts 43852 Hydraulic Cylinder 26723 Hydraulic Hose 2.80m...
  • Page 48 ‘Enviro DD35’ Wheel Leg...
  • Page 49 ‘Enviro DD35’ Wheel Leg ITEM PART No. DESCRIPTION 60045PH Left Hand Wheel Leg (not shown) 60061PH Right Hand Wheel Leg 72332 Pin Whl Leg W/Assy 60065 Spacer 43426 Glacier Bush Ø45 43010 90° Grease Nipple 60245 Mk4 Ren Hub Only ADR-6 Stud 45638 10.0/75-15,3 Wheel Assy 6 Stud...
  • Page 50 ‘Enviro DD35’ Wheel Hydraulics Slave Master Cylinder Cylinder 13, 14 24, 25 20 - 23...
  • Page 51 ‘Enviro DD35’ Wheel Hydraulics ITEM PART No. DESCRIPTION 26702 3.5” x 6.5” Master Rephasing Cylinder (Includes pin) 26703 3.25” x 6.5” Slave Rephasing Cylinder (Includes pin) 43848 Stroke Limiting Collar 7/8” (where fitted) 60866 Hydraulic Hose, 2.70m 60864 Hydraulic Hose, 2.70m 60864 Hydraulic Hose, 2.70m...
  • Page 52 ‘Enviro DD35’ Disc Assemblies...
  • Page 53 ‘Enviro DD35’ Disc Assemblies ITEM PART No. DESCRIPTION 60811k Straight Coulter with Press Wheel (LH Leading) 66394k Straight Coulter with Press Wheel (RH Leading) 66393k Straight Coulter no Press Wheel (RH Leading) 60812k 40 R Offset Coulter with Press Wheel (LH Leading)
  • Page 54 ‘Enviro DD35’ Disc Assemblies or 17...
  • Page 55 ‘Enviro DD35’ Disc Assemblies ITEM PART No. DESCRIPTION 64510 Pivot Bolt (Cone Seat) 64511 Pivot Nut (Cone Seat) 45143 M24 Nyloc Nut 64512 Spring Cap 64513 Compression Spring 45024 M12 x 55 Grade 8.8 Z/P Bolt 64514 Spring Bolt 64515...
  • Page 56 ‘Enviro DD35’ Disc Assemblies Straight Mount Shown 17 18 Scraper Assy See Below See Page 56 Scraper Assy...
  • Page 57 ‘Enviro DD35’ Disc Assemblies ITEM PART No. DESCRIPTION 66403 Press Wheel Fixed Plate RH 43953 Nylon Washer 30 x 70 x 2 66402 Press Wheel Fixed Plate LH 45140 M16 Nyloc Nut 45020 M12 x 35 Grade 8.8 Z/P Bolt 45023 M12 x 50 Grade 8.8 Z/P Bolt...
  • Page 58 ‘Enviro DD35’ Disc Assemblies...
  • Page 59 ‘Enviro DD35’ Disc Assemblies ITEM PART No. DESCRIPTION 63133 Straight Coulter (LH Leading) 66352 Straight Coulter (RH Leading) 66370 40 R Offset Coulter (LH Leading) 66357 40 R Offset Coulter (RH Leading) 66372 40 L Offset Coulter (LH Leading) 66355...
  • Page 60 ‘Enviro DD35’ Disc Assemblies Note: The scalloped disc is always ‘leading’ but may be fitted to the left or right side; it is dependant on the disc-mount used. (refer page 56)
  • Page 61 ‘Enviro DD35’ Disc Assemblies ITEM PART No. DESCRIPTION 74829 DD DIsc Seal Spacer (replaces 45154 & 63102) 43352 Vee Ring Seal V-40A 63101 Stepped Spacer 63071 Plain Disc Sub Assy (includes items 6,7,8,9,10,12,14,15,16,17,18) 63072 Scalloped Disc Sub-Assy (includes 6,7,8,9,11,12,13,15,16,17,18) 29241...
  • Page 62 ‘Enviro DD35’ Jockey Drive Components for both drives 40 - 44 are the same 21 22...
  • Page 63 ‘Enviro DD35’ Jockey Drive ITEM PART No. DESCRIPTION 63128 21T Sprocket 1/2”P 20mm Bore 74262 Box Drive Shaft Long DD35 22294 Sprocket Key (6 x 6 x 25) 45137 M8 Nyloc Nut 45151 M8 Light Flat Washer Z/P 44992s M8 x 20 Grade 8.8 Z/P S/Screw …...
  • Page 64 ‘Enviro DD35’ Chains & Tensioners For Jockey Chain Tensioner see items 23 to 28 on previous page...
  • Page 65 ‘Enviro DD35’ Chains & Tensioners ITEM PART No. DESCRIPTION 63125 1/2” BS Chain x 63 Links 44014 Plastic Chain Tensioner 24103 1/2” BS Chain x 61 Links 43388 1/2” P Joiner Link Pt. No. 67439 Issue 1120...
  • Page 66 ‘Enviro DD35’ Driveshafts (Metering) ‘INBOARD’ END ‘OUTBOARD’ END ‘OUTBOARD’ END (20mm x 20mm) ‘INBOARD’ END (25mm X 25mm)
  • Page 67 ‘Enviro DD35’ Driveshafts (Metering) ITEM PART No. DESCRIPTION 63230 O/Board Universal Shaft W/Assy 63231 InBoard Universal Shaft W/Assy 47615 6 x 40 Pipe Lynch Pin 44957SS M6 x 35 304 S/Steel Bolt 45136SS M6 Nyloc Nut Grade 316 S/S 44039 UJ Coupling Rubber Boot (not shown) Pt.
  • Page 68 ‘Enviro DD35’ Seedbox Frame 10 11 7, 8...
  • Page 69 ‘Enviro DD35’ Seedbox Frame ITEM PART No. DESCRIPTION 63183 Hopper Mount Frame W/Assy 74249 Side Support W/Assy DD35 74252 LH Frame Brace Front DD35 W/As 74256 RH Frame Brace Front DD35 W/As 63211 Foot Stand W/Assy 45039 M16 x 45 Grade 8.8 Z/P Bolt...
  • Page 70 ‘Enviro DD35’ Footboard & Ladder Although this detail shows a Right Hand mounted footboard/rail, the rail is anchored in the same way.
  • Page 71 ‘Enviro DD35’ Footboard & Ladder ITEM PART No. DESCRIPTION 60163 End Guard Rail W/Assy 61705 Side Guard Rail W/Assy 43757 Drop Lock 45138 M10 Nyloc Nut 61700 RH Footboard Assembly 60170 Footboard Step Bracket W/Assy 63219 Ladder Assembly 64122 Guard Rail Multi-Purpose Frame 45023 M12 x 50 Grade 8.8 Z/P Bolt...
  • Page 72 ‘Enviro DD35’ Seed/Fert Box 12 15...
  • Page 73 ‘Enviro DD35’ Seed/Fert Box ITEM PART No. DESCRIPTION 44110 Distributor Head 32R 63179 Blanking Plug Seed Distr Head (5 per head) 63150 MS Hopper W/Assy 63177 14 Hole Tube Inset Panel W/Assy (1 per compartment) 44951sss M6 x 16 316 S/S S/Screw...
  • Page 74 ‘Enviro DD35’ Metering Unit...
  • Page 75 ‘Enviro DD35’ Metering Unit ITEM PART No. DESCRIPTION 44063 Metering Device 45152 M10 Light Flat Washer Z/P 45138 M10 Nyloc Nut 44068 Elbow 45151 M8 Light Flat Washer Z/P 45137 M8 Nyloc Nut 63259 Cover 44993s M8 x 25 Grade 8.8 Z/P S/Screw 45004 M10 x 35 Grade 8.8 Z/P Bolt...
  • Page 76 ‘Enviro DD35’ Fan & Air Hoses ITEM PART No. DESCRIPTION 44017 Blower 15 Series 44992s M8 x 20 Grade 8.8 Z/P S/Screw 44018 Flanged Blower Manifold Splitter 45137 M8 Nyloc Nut 45139 M12 Nyloc Nut 45032 M12 x 110 Grade 8.8 Z/P Bolt...
  • Page 77 ‘Enviro DD35’ Fan Hydraulics ITEM PART No. DESCRIPTION 44060k FAN MOTOR HOSE KIT contains items 1 to 13:- 44072 Hydraulic Hose (4.0m) 44073 Hydraulic Hose (4.2m) 44074 Hydraulic Hose (4.0m) 44075 7/8” UN’O x 1/2” BSPPM Nipple 44142 7/8” UN’O’x1-1/16”JIC Nipple 44078 9/16”JICF x 1/4”BSPM 90°...
  • Page 79 ‘Enviro DD35’ Jackal ITEM PART No. DESCRIPTION 44026K Contains the following: 44027 Jackal v3.5 Monitor and Control Speed, Area Meter and Fan 44037 Owner’s Manual Jackal v3.5 Monitor and Control Speed 44028 Window Mount AH-407 44576 11 way Terminal Block P322 Grey...

  • Page 80: Optional Extras

    ‘Enviro DD35’ Lighting (Optional) Rear Left Front Left Rear Right Front Right 5 mm Ensure outer casing of cable protrudes past cable clamp by at least 5 mm Terminals viewed from direction of cable entry Cable Terminal Function Colour Number...
  • Page 81 ‘Enviro DD35’ Lighting (Optional) ITEM PART No. DESCRIPTION 62975K Contains items 1 to 15: 45664 Hazard Decal Full Set 61718P# Hazard Panel Front Profile 61719P# Hazard Panel Rear Profile 61715 Viz Plate Holding Bracket 61709 FR-LH/RR-RH Viz Frame (Front left or Rear right)
  • Page 82 ‘Enviro DD35’ Rear Tow Hitch (Optional) The Disc Units have been hidden for clarity...
  • Page 83 ‘Enviro DD35’ Rear Tow Hitch (Optional) ITEM PART No. DESCRIPTION 63035 Rear Towhitch Welded Assembly 63297 Tine Harrow Stub Assembly 45040 M16 x 50 Grade 8.8 Z/P Bolt 45043 M16 x 65 Grade 8.8 Z/P Bolt 45045 M16 x 75 Grade 8.8 Z/P Bolt...
  • Page 84 ‘Enviro DD35’ Tine Harrow (Optional)
  • Page 85 ‘Enviro DD35’ Tine Harrow (Optional) ITEM PART No. DESCRIPTION RFT35 Tine Harrow 3.5m 60426 Tine Harrow Strut W/Assy 60428 Strut Bolt Plate 60430 Swinging Arm W/Assy 60435 Guidingbar W/assy 60437 Levelling Harrow Spring 60438 Guiding bar Bush 60439 Guiding Spacer...
  • Page 86 ‘Enviro DD35’ Uni-Roller (Optional) 19 tyres...
  • Page 87 ‘Enviro DD35’ Uni-Roller (Optional) ITEM PART No. DESCRIPTION RTR35 UniRoller Complete 3,5m 60476 3,5m UniRoller Frame W/Assy 60490 3,5m UniRoller Frame W/Assy 60496 Link 60483 3,5m UniRoller Tube W/Assy 43589 Tyre 185/70 R13 60494 End Retaining Plate 43588 Bearing Unit...
  • Page 88 ‘Enviro DD35’ Weight Front (Optional) The Disc Units have been hidden for clarity...
  • Page 89 ‘Enviro DD35’ Weight Front (Optional) ITEM PART No. DESCRIPTION 63285 Front Wght Holding Brkt W/Assy 45069 M20 x 90 Grade 8.8 Bolt Z/P 45141 M20 Nyloc Nut 63273C Case Weight 40kg 45160 M16 H/D Flat Washer Z/P 45168 M16 Spring Washer Z/P 45132 M16 Grade 8.8 Hex Nut Z/P...
  • Page 90 ‘Enviro DD35’ Weight Rear (Optional) The Disc Units have been hidden for clarity...
  • Page 91 ‘Enviro DD35’ Weight Rear (Optional) ITEM PART No. DESCRIPTION 63273C Case Weight 40kg 45160 M16 H/D Flat Washer Z/P 45168 M16 Spring Washer Z/P 45132 M16 Grade 8.8 Hex Nut Z/P 63274 Weight Holding Rod 250mm Long Kit 62987K includes all mounting hardware for FRONT and REAR of machine but excludes weights (item 1) Pt.
