Duncan Enviro DD30 Owner's Manual

Smart ag electric drive operation
Hide thumbs Also See for Enviro DD30:

Advertisement

Quick Links

Download this manual
Owners Manual
'Smart AG Electric Drive
Head Office:
P.O. Box 2018
Hilton Highway, Washdyke
Timaru, New Zealand
Telephone (03) 688 2029
Facsimile (03) 688 2821
Enviro DD30
Operation'
Australian Branch:
Building 2 107-117 Boundary
Road
Laverton North, Melbourne,
Victoria 3026 Australia
Telephone (03) 9369-6548
Facsimile (03) 9314-6810
Pt. No. 67453
Issue 0321

Advertisement

loading
Need help?

Need help?

Do you have a question about the Enviro DD30 and is the answer not in the manual?

Questions and answers

Paul Willem
March 6, 2025

how many discs

0
1 comments:
Mr. Anderson
March 6, 2025

The Duncan Enviro DD30 has a double disc setup, meaning each row has two discs. The DD30 is available as a 23-row machine, so it includes 46 discs in total (23 rows × 2 discs per row).

This answer is automatically generated

0

Related Manuals for Duncan Enviro DD30

Summary of Contents for Duncan Enviro DD30

  • Page 1 Owners Manual Enviro DD30 ‘Smart AG Electric Drive Operation’ Head Office: Australian Branch: P.O. Box 2018 Building 2 107-117 Boundary Hilton Highway, Washdyke Road Timaru, New Zealand Laverton North, Melbourne, Telephone (03) 688 2029 Victoria 3026 Australia Telephone (03) 9369-6548...
  • Page 3 Enviro DD30 Contents Page Setup, Calibration & Operating Procedure: Read Before Operation ....Pre-calibration setup flowchart ... .

  • Page 4: Read Before Operation

    ‘Enviro DD30’ Read Before Operation Components Referred to in the Pre-Calibration Setup and Calibration Process The following pages describe how to set the machine up for calibration, the calibration process and subsequent adjustments to obtain the desired seed and/or fertilizer output.
  • Page 5 ‘Enviro DD30’ Read Before Operation Components Referred to in the Pre-Calibration Setup and Calibration Process The following pages describe how to set the machine up for calibration, the calibration process and subsequent adjustments to obtain the desired seed and/or fertilizer output.
  • Page 6 ‘Enviro DD30’ SmartAG Overview Front Screen - Overview Front Screen Settings Menu > Select the Settings tab (looks like a gearwheel) to display the settings menu. This will mostly be used the access the calibration screens which are described in the calibration section of this manual.

  • Page 7: Settings Menu - Overview

    ‘Enviro DD30 ’ SmartAG Overview Settings Menu - Overview Settings Menu Setup Menu > This opens the Settings and Setup menu. This enables product calibration, machine settings and display options. Note that all the settings for your machine are already set and tested at the factory.
  • Page 8 ‘Enviro DD30’ SmartAG Overview Screen Tabs - Overview Note: Bin Levels are 700 on DD30 Tab 2 - Bin Contents and Bin Motor ‘ON/OFF’ Front/Rear Bin Level Estimate > Each bin capacity is 700 litres. The value displayed is a...
  • Page 9 ‘Enviro DD30’ Pre-Calibration Setup normal/fine toggle Start Empty boxes and clear old seed and fertilizer from metering unit. high (idler in) low (idler out) Is seed size between 4 and 10mm? Locate product in 'Normal' Locate product in 'Fine' seed seed table.
  • Page 10 ‘Enviro DD30’ Calibration Seed Calibration The calibration test should be done to confirm the required seed rate to be sown and is done with the drill stationary and level and the fan off. Seed Calibration Procedures Prepare a suitable area for weighing and setup the scales.
  • Page 11 ‘Enviro DD30’ Calibration Seed Calibration With the drill set up for calibration and the display configured for the chosen product we are now ready to calibrate. Navigate to the Bin/Tank screen if not there already. Touch Product to get to the Product screen as shown.
  • Page 12 ‘Enviro DD30’ Calibration Seed Calibration (continued) 10 Touch tick again. Touch OK. Touch tick to accept to return to the Bin/Tank screen. Touch the ‘home’ icon to return to the main screen. 11 Note that you may manually enter a calibration factor by touching the Manual Cal button.
  • Page 13 ‘Enviro DD30’ Save/Restore>USB Save Settings and Return to Factory Settings Navigate to the Setup screen from the Main Screen by touching the gear icon. Touch the case icon then the SYSTEM icon. Touch RESET icon. (This will take you to a menu and...
  • Page 14 ‘Enviro DD30’ Sowing Chart Normal...
  • Page 15 ‘Enviro DD30’ Sowing Chart Fine FINE SEED (toggle ‘FINE’, Butterfly Valve Settings shown below) SPECIFIC Setting PRODUCT GRAVITY (kg/l) Position> 2.5 12.5 17.5 22.5 RATE ONCE SET DO NOT REDUCE/CLOSE WITH SEED IN BIN** Lucerne (Alfalfa) 0.77 1.10 3.06 4.60 6.49 7.93 9.34 11.28 12.95 14.39 15.50 Turnip 0.65...

  • Page 16: Airflow & Fan Speed

    ‘Enviro DD30’ Airflow & Fan Speed Airflow and Fan Settings 1. Hydraulic Fan -connect the hoses in the following order: First - connect Zero pressure Case Drain 3/8” hose (1/2” BSP Female QR) to hydraulic reservoir * Second -connect Motor Return 3/4” hose (3/4” BSP Female QR) to tractor high flow low pressure return port.

  • Page 17: Operation

    ‘Enviro DD30’ Operation Operation General Operation Guidelines Hydraulic Fan -connect the hoses in the following order: First - connect Zero pressure Case Drain 3/8” hose (1/2” BSP Female QR) to hydraulic reservoir * Second -connect Motor Return 3/4” hose (3/4” BSP Female QR) to tractor high flow low pressure return port.
