Summary of Contents for Sigma mobile X-treme PQ39

  • Page 1 Smartphone X-treme PQ39 User manual...
  • Page 2 Dear Client! Thank you for purchasing Sigma mobile product! Please read this manual before using the device to ensure safe and proper use and prevent it from damages.  Software, design features and content of manual may be changed to improve the product without a prior notice.
  • Page 3 Package Contents:  Smartphone Sigma mobile X-treme PQ39  Network charger  USB Type C cable  Headset  Manual  Warranty Card Size: 169*86*16 mm The manufacturer reserves the right to change complement, specifications and appearance. Specifications Android™ 7.0 Popular operating system for smartphones, the ability to install applications.
  • Page 4: Table Of Contents

    Content Safety and security ....................5 Headset usage ....................5 Start ......................... 5 Buttons and ports ....................6 Standby mode ....................6 Button to additional menu ................. 7 Connection to 3G/4G network ................7 Indicator icons ....................7 Charging the battery ..................8 Installing a SIM-card and memory card ..............
  • Page 5: Safety And Security

    SAFETY AND SECURITY  Do not disassemble device and do not repair it by yourself.  Permitted outside temperature operating mode: -20 to 50*C.  Storage temperature:-5 to +45*C.  Relative humidity: 5% to 90%, non-condensing (25 ° C).  Avoid the contact with fire to avoid explosion or fire. ...
  • Page 6: Buttons And Ports

    Turn off: Press and hold for four seconds power button until the switching off interface appears. Choose the button, which confirms the switching off. The device turns off Buttons and ports nanoSIM/microSD slot Front camera Power on/off Audio 3.5mm port USB Type-C Main camera Camera (press and hold to...
  • Page 7: Button To Additional Menu

    To unlock the screen, you may swipe from the bottom in any part of the screen. It is possible to protect yourself from unauthorized access in several ways: - Locking by the graphical key; - Locking by the password or PIN; - Locking by fingerprint Button to additional menu On the main screen and in the different programs might be the icon .
  • Page 8: Charging The Battery

    Charging the battery Charge the battery before using it for the first time. Use only Sigma mobile approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.  When the battery power is low, the battery icon appears as empty.
  • Page 9: Installing A Sim-Card And Memory Card

     If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.  If you use multiple apps at once, network apps, or apps that need a connection to another device, the battery will drain quickly.
  • Page 10: Main Techniques

    Sigma mobile service center for safe removal. Be careful not to lose your SIM card and do not let others use it. Sigma mobile is not liable for any damage or inconvenience caused by the loss or theft of the cards.
  • Page 11 Attention! Do not allow the touchscreen to come into contact with other electrical devices. Electrostatic discharges can cause the touchscreen to malfunction. To avoid damaging the touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips. The device may not recognize touch inputs close to the edges of the screen, which are outside of the touch input area.
  • Page 12 status bar downwards. To close the notification panel, swipe upwards on the screen. Scroll down to see additional notifications. On the notifications panel you may view current device settings  Settings : switch to device settings  Wi-Fi: Wi-Fi function on/off ...
  • Page 13: Account Settings

    Panels managing Adding new panel New panel is added automatically when the new object is added beyond the existing panels. Moving the panel On the Home screen, tap and hold an empty area to add, move, or remove a panel. Delete the panel In order to delete the panel, delete first all of the objects of its panel.
  • Page 14: Files Transferring

    To enter the system by the Google account or register Google account touches the program menu - Settings → Accounts →Add account→ Google. It is possible to use a few Google accounts. Removing accounts On the program menu press Settings → Accounts, choose the account that should be removed then press →...
  • Page 15: Settings

    Enter at least four numbers, and then enter the password again to verify it. Setting a password On the Applications screen, tap Settings → Security → Lock screen → Password. Enter at least four characters including numbers and symbols, and then enter the password again to verify it.
  • Page 16 7) Enter by PIN-code with WPS; 8) MAC-address and IP-address. After all installation is done, icon of connection with the wireless network appears at the top of the screen Bluetooth Use Bluetooth to exchange data or media files with other Bluetooth-enabled devices.
  • Page 17: Device

    Bluetooth tethering: Use Bluetooth tethering to share the device’s mobile network connection with computers or other devices via Bluetooth. Set up and connect to virtual private networks (VPNs). Cellular networks  Mobile data: Use to allow packet switching data networks for network services. ...
  • Page 18: Personal

    Apps There is program list installed in the device. If any program is touched, the additional features appear available for it:  Turn off  Delete  Force stop  Clear the data Attention! Standard programs that come with device cannot be deleted. Also, some downloaded applications and some standard programs cannot be deleted.
  • Page 19  Unknown sources: permission to install applications from unknown sources.  To encrypt device: set a password to encrypt data stored on the device. Password must be entered each time when activate the device. Charge the battery before activate this option, as data encryption takes time more than an hour. ...
  • Page 20: System

     Additional settings Google voice typing There is changing of the voice command settings. Languages: language list for texting.  To block offensive words: prohibition against recognizing by the device abusive words entered by voice data.  Offline speech recognition: downloading and installation of the voice data for voice input offline.
  • Page 21: Connection

    Scheduled power on & off Time settings for scheduled shutdowns and turns Accessibility Availability services – special functions, designed for users with certain disabilities. Use the settings and change it to improve the availability and usability of the device. Printing Turn On / Off settings and print with network printers.
  • Page 22: Contacts

     Settings Receiving calls Calls respond When a call comes in, drag right outside the large circle. When the waiting mode is on, it is possible to answer another receiving call. If you answer on the second call, the first one is placed on standby mode. Rejecting a calls When a call comes in, drag left outside the large circle.
  • Page 23: Messaging

    Contacts managing Touch CONTACTS on the screen. New contact to select where to save the contact and enter contact information. Having done the entering, tap , changes are saved automatically. Contact editing Choose contact for editing and then tap Contact removing To remove the contact, tap and choose Delete.
  • Page 24: Programs

     Choose the contact in the message list.  View the dialogue. Messages settings Touch the message on the program screen, tap , choose Settings.In this menu you may set:  Default program for sending SMS  SMS settings: delivery reports, SMS storage location, editing the quick test, editing of the SMS center sending, SMS inputting mode ...
  • Page 25: Camera

    Sending emails  Tap to compose an email.  Add recipients and enter an email text.  Tap to send the email. Reading emails When Email is open, the device will automatically retrieve new emails. To manually retrieve emails, swipe downwards on the screen. Tap an email on the screen to read it.
  • Page 26: Gallery

    Taking photos or recording videos  Set the shooting mode: Normal, Panorama  Tap the image on the preview screen where the camera should focus.  Spread two fingers apart on the screen to zoom in, and pinch to zoom out. ...
  • Page 27: Google™ Programs

    On the video draft the sign is displayed . To play the video, tap it. To hide or display the menu touch the screen.  To select additional options, tap .  To send photo or video, tap  To remove photos or videos, tap and delete.
  • Page 28: Troubleshooting

     The touchscreen may malfunction in humid conditions or when exposed to water.  Restart your device to clear any temporary software bugs.  If the touchscreen is scratched or damaged, visit a Sigma mobile Service Centre. Your device does not react on pressing the keys or encounters a fatal error...
  • Page 29 Try the following solutions. If the problem is still not resolved, contact a Sigma mobile Service Centre. Restarting the device If your device does not react on pressing the keys or freezes you may need to close apps or turn off the device and turn it on again.
  • Page 30  Charge the battery.  Free some memory by transferring files to a computer or deleting files from your device.  Restart your device. If you still have troubles with the camera app, contact Sigma mobile service Centre. Photo quality is poorer than the preview ...
