- Page 1 Omni Wash Arches Owner’s Manual Sonny's Enterprises LLC 5605 Hiatus Road Tamarac, Florida 33321...
-
Page 2: Table Of Contents
Owner’s Manual Omni Wash Arches *Table of Contents* WARNING *SAFETY REQUIREMENTS* WARNING ..............3 *INTRODUCTION* ........................5 Product Specifications ....................... 6 Utilities Requirements ...................... 12 Dimensions ........................13 Equipment Installation ...................... 15 Omni Wash Arch Installation ................... 15 Adjustments and Testing ....................17 *GENERAL OPERATION* ...................... -
Page 3: Warning *Safety Requirements* Warning
Owner’s Manual Omni Wash Arches WARNING *SAFETY REQUIREMENTS* WARNING 1. All employees must be thoroughly trained in safe operation and standard maintenance practices. All employees must review this entire manual monthly. 2. Do not enter the wash tunnel when the equipment is operating. Death or dismemberment may occur. - Page 4 Owner’s Manual Omni Wash Arches 13. Store all cleaning and washing solutions and oils in a well-ventilated area. Clean up fluid spills immediately to prevent hazardous safety conditions. Be certain to follow all safety procedures on SDS Sheets for each chemical product used. 14.
-
Page 5: Introduction
Owner’s Manual Omni Wash Arches *INTRODUCTION* This Manual contains information that is vital to the successful installation, operation and maintenance of your SONNY’S vehicle washing equipment. Please read, and understand, the full contents of this manual before installation and operation of the equipment. Keep this booklet in a location where it may be used for ongoing reference. -
Page 6: Product Specifications
Owner’s Manual Omni Wash Arches Product Specifications ➢ Unique shifting and oscillating motion provide thorough coverage. ➢ 4 inch square aluminum frame. Also available in stainless steel. ➢ Stainless steel spray bars. ➢ Non-grease UHMW bushings throughout. ➢ Spray bar oscillation controlled by hydraulic motors requiring 3GPM maximum. - Page 7 Owner’s Manual Omni Wash Arches © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 7 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
- Page 8 Owner’s Manual Omni Wash Arches © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 8 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
- Page 9 Owner’s Manual Omni Wash Arches © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 9 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
- Page 10 Owner’s Manual Omni Wash Arches © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 10 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
- Page 11 Owner’s Manual Omni Wash Arches © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 11 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
-
Page 12: Utilities Requirements
Owner’s Manual Omni Wash Arches *INSTALLATION* Utilities Requirements UTILITIES INTERCONNECTION AND THE MATERIALS REQUIRED FOR INTERCONNECTION TO SONNY’S EQUIPMENT ARE THE RESPONSIBILITY OF THE CUSTOMER ! PERFORM ALL TRADES WORK TO ALL APPLICABLE LOCAL AND NATIONAL CODES ! Electric • The Customer’s Electrician is to provide materials and install single phase power (24VAC or 110VAC (specify at the time of order) from the tunnel equipment controller to high pressure pump controls, hydraulic power pack control, and the supplied 4-way air solenoid valve on the Air Distribution Manifold. -
Page 13: Dimensions
Owner’s Manual Omni Wash Arches Dimensions Figure #1 © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 13 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –... - Page 14 Owner’s Manual Omni Wash Arches Figure #2 © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 14 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
-
Page 15: Equipment Installation
Owner’s Manual Omni Wash Arches Equipment Installation Omni Wash Arch Installation Tools Consumables 1. Safety Glasses 1. Stainless Shims 2. ½" Drive Ratchet Set 2. PTFE Tape 3. Standard Combo Wrenches 3. PTFE Paste 4. Standard Screwdriver 5. 1” Hammer Drill 6. - Page 16 Owner’s Manual Omni Wash Arches 10. Open the needle valves on each cylinder and air reservoir and fill to 3/4 each reservoir with fluid. 11. Physically pivot each manifold back and forth until no more bubbles appear in the reservoir while compressing the cylinder. 12.
-
Page 17: Adjustments And Testing
Owner’s Manual Omni Wash Arches Adjustments and Testing Test Water, Hydraulic and Air Using the 4-way air valves on the air distribution manifold, manually activate each air cylinder and ensure the Omni manifold pivots properly and that in the OFF position it is facing as in Position #1 in Figure #2. - Page 18 Owner’s Manual Omni Wash Arches 2. Position #2. After the windshield moves out of range of the spray pattern the 4-way air valve for the top Omni manifold should activate and the manifold should move to the rear facing position to clean the rear window as it passes. The needle valve on the air/fluid reservoir can be adjusted to control the speed of the tracking to occur quick enough to get the rear window on a pickup truck.
-
Page 19: General Operation
Owner’s Manual Omni Wash Arches *GENERAL OPERATION* Omni Manifolds Starting and stopping Omni manifold oscillation is controlled by the Customer’s equipment programmer signal to the motor starter coil controlling three phase powers to the Customer’s hydraulic power pack that is plumbed to the hydraulic motors. The speed of the oscillation of the motor(s) being driven may be changed by the flow control valve on the hydraulic power pack. -
Page 20: Preventive Maintenance
Owner’s Manual Omni Wash Arches *PREVENTIVE MAINTENANCE* DAILY 1. Check all lines and fittings for leaks. Repair, or replace, as needed. 2. Check for proper operation, listening for any unusual noises and checking for proper tracking. WEEKLY 1. Carefully check the reservoirs and air cylinders; and ensure the reservoirs are at least ¼ full when the cylinder is fully extended. -
Page 21: Parts
Owner’s Manual Omni Wash Arches *PARTS* © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 21 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –... - Page 22 Owner’s Manual Omni Wash Arches © 2021 SONNY’S The CarWash Factory ® . All Rights Reserved. SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used, disclosed or Page 22 of 24 published without prior written consent. Content, prices, and availability subject to change without notice. Omni Wash Arches.docx –...
-
Page 23: Warranty
Owner’s Manual Omni Wash Arches *WARRANTY* SONNY’S ENTERPRISES, INC. FACTORY LIMITED LIFETIME WARRANTY Equipment manufactured by SONNY’S ENTERPRISES, INC. is warranted to be free from defect in material and workmanship. Welded metal framework and other non-moving, non-wearable fabricated metal components manufactured by SONNY’S are warranted for the life of the equipment to the original purchaser. -
Page 24: Customer Service
Owner’s Manual Omni Wash Arches *CUSTOMER SERVICE* Please contact SONNY’S Equipment Department for installation and/or operational questions regarding this piece of equipment. Please refer to the Parts Catalog and contact SONNY’S Customer Service Order Entry Department for any replacement parts for this piece of equipment. You can also visit the web at www.SonnysDirect.com.
