Vibratory Roller
SERVICE MANUAL
Part number 47772910
DV209C
DV210C
Tier 4A
1
edition English
st
December 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV209C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Case DV209C

  • Page 1 DV209C DV210C Tier 4A Vibratory Roller SERVICE MANUAL Part number 47772910 edition English December 2014...
  • Page 2 Contents INTRODUCTION Machine completion and equipment ..........05 [05.102] Machine completion ..............05.1 Engine..................
  • Page 3 [50.100] Heating ................50.1 Electrical systems ...............
  • Page 4 47772910 15/12/2014 Find manuals at https://best-manuals.com...
  • Page 5 INTRODUCTION 47772910 15/12/2014 Find manuals at https://best-manuals.com...
  • Page 6: Table Of Contents

    Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Safety rules .
  • Page 7: Foreword - Important Notice Regarding Equipment Servicing

    In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer.
  • Page 8: Safety Rules

    INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions.
  • Page 9: Safety Rules

    INTRODUCTION Safety rules Carefully read the safety rules contained herein and follow advised precautions to avoid potential hazards and to safeguard your safety and personal integrity. Your safety and that of the people around you depends on you. It is essential that you understand this manual for a correct inspection, lubrication and repair of this machine. Read this manual carefully and check that: •...
  • Page 10 INTRODUCTION Make sure that you fully understand the symbols of the safety decals applied on the machine. Make sure that they are always clean and perfectly legible. Be prepared for emergencies. Always keep a first aid kit and a fire extinguisher close at hand on the machine.
  • Page 11: Safety Rules

    INTRODUCTION Safety rules Prevention of fire or explosions The engine fuel can originate an explosion or a fire. Never refuel when the engine is running. Do not smoke during refuelling. Take all the necessary safety measures when welding, grinding or when working near a naked flame. Use a non-inflammable product for cleaning parts.
  • Page 12 INTRODUCTION Prevention of burns The battery electrolyte generates severe burns. The battery contains sulphuric acid. Avoid any contact with the skin, eyes or clothing. Antidote: • EXTERNAL: Rinse well with water, removing any soiled clothing. • INTERNAL: Avoid vomiting. Drink water to rinse your mouth.
  • Page 13 INTRODUCTION Precautions for waste disposal Improperly disposing of waste can threaten the environ- ment. Each country has its own Regulations on this subject. It is therefore advisable to prepare suitable containers to collect and store momentarily all solid and fluid materials that must not be scattered in the environment to avoid pollution.
  • Page 14: Safety Rules - Ecology And The Environment

    Improper disposal of batteries can contaminate the soil, groundwater, and waterways. CASE CONSTRUCTION strongly recommends that you return all used batteries to a CASE CONSTRUCTION dealer, who will dispose of the used batteries or recycle the used batteries properly.
  • Page 15: Safety Rules - Shop And Assembly

    INTRODUCTION Safety rules - Shop and assembly O-ring seals Lubricate the O-ring seals before you insert them in the seats. This will prevent the O-ring seals from overturning and twisting, which would jeopardize sealing efficiency. Sealing compounds Apply a sealing compound on the mating surfaces when specified by the procedure. Before you apply the sealing compound, prepare the surfaces as directed by the product container.
  • Page 16 W0111A Special tools The special tools that CASE CONSTRUCTION suggests and illustrate in this manual have been specifically re- searched and designed for use with CASE CONSTRUCTION machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting oper- ation.
  • Page 17: Safety Rules - Hydraulic Contamination

    INTRODUCTION Safety rules – Hydraulic contamination Contamination in the hydraulic system is a major cause of the malfunction of hydraulic components. Contamination is any foreign material in the hydraulic oil. Contamination can enter the hydraulic system in several ways: • When you drain the oil or disconnect any line •...
  • Page 18: Personal Safety

    INTRODUCTION Personal safety Wear Personal Protective Equipment (PPE) such as hard hat, eye protection, heavy gloves, hearing protection, pro- tective clothing, etc. Wear working footwear with non-slip soles. Smooth soles may slip from steps and pedals resulting in injury or incorrect operation.
  • Page 19: Torque

    INTRODUCTION Torque • Confirm regularly that bolted connections have not come loose. • Use torque wrenches for tightening. • If a special torque is needed, it is mentioned in the section. Thread size TIGHTENING TORQUE For screws For srews 8.8 (8G) 10.9 (10K) 10 N·m (7.4 lb ft) 14 N·m (10.3 lb ft)
  • Page 20 INTRODUCTION Tightening torques for cap nuts with O-ring - hoses Size wrench Thread size Hose Nominal 135 N·m (99.6 lb 115 N·m (84.8 lb 155 N·m (114.3 lb 30x2 166 N·m (122.4 lb 140 N·m (103.3 lb 192 N·m (141.6 lb 36x2 240 N·m (177.0 lb 210 N·m (154.9 lb...
  • Page 21 INTRODUCTION Table for torques of plugs with flat gasket G - M Tightening torques for flanges G 1/8 15 N·m (11 lb ft) G1/4 33 N·m (24 lb ft) G 3/8 70 N·m (52 lb ft) G 1/2 90 N·m (66 lb ft) G 3/4 150 N·m (111 lb ft) 220 N·m (162 lb ft)
  • Page 22: Hydraulic Contamination - Contamination

    INTRODUCTION Hydraulic contamination – Contamination Contamination in the hydraulic system is a major cause of the malfunction of hydraulic components. Contamination is any foreign material in the hydraulic oil. Contamination can enter the hydraulic system in several ways. 1. When you drain the oil or disconnect any line. 2.
  • Page 23: Consumables

    INTRODUCTION Consumables CASE CON- RECOMMENDED FLUIDS STRUC- INTERNATIONAL MODELS QUANTITY Specifications AND APPLICATION TIONSpecifi- cations CASE SAE 10W40 AKCELA 9 L (2.38 US gal) ENGINE - OIL API CJ-4 UNITEK ACEA E9 10W-40 COOLING SYSTEM CNH XHD CNH XHD H...
  • Page 24 INTRODUCTION Engine oil Engine oil has been specified as per its performance classification and viscosity classification. Performance classification under: American Petroleum Institute (API) Viscosity classification The ambient temperature and type of operations at the place where the machine will be used are decisive in deter- mining Society of Automotive Engineers (SAE) viscosity class.
  • Page 25 INTRODUCTION NOTICE: Do not allow the upper temperature limit to be Viscosity diagram exceeded for long periods of time as this will reduce the capabilities of the oil. When using oil API CG-4/SH, the oil change interval must be reduced by half, i.e. 125 h. SS12C358 47772910 15/12/2014...
  • Page 26 Always check the antifreeze concentration of the coolant with a refractometer before the winter season starts. Hydraulic oil Only hydraulic oil CASE AKCELA HY-TRAN® ULTRA™ HYDRAULIC TRANSMISSION OIL may be used for the machine’s hydraulic system. Fill the machine with hydraulic oil of cinematic viscosity 68 mm² per second at 40 °C (104 °F), i.e. ISO VG 68. This oil is most appropriate for use within the widest range of ambient temperatures.
  • Page 27 NOTICE: Brake fluid that corresponds to the international classification DOT 4 may also be used for the brake system. Lube grease Use plastic lubricant with lithium content to lubricate the machine: Case Akcela Extreme pressure grease moly To lubricate the speed reduction transmission, use the lubricant according to: ISO 6743/9 BDHB2 Washer fluid Use clean water at a temperature of no lower than 0 °C (32 °F) when filling the washer fluid reservoir.
  • Page 28: Product Identification

    INTRODUCTION Product identification When ordering parts, requesting information or assistance, always give your Dealer the model and Product Identifi- cation Number (PIN) of your machine and component concerned. Machine Product identification plate provides the following information: 1. Type / Model 2.
  • Page 29 INTRODUCTION Engine Engine identification plate (1) is located below the Ma- chine identification plate RAIL14COM0213AA Roll Over Protective Structure (ROPS) ROPS identification plate (1) is located on the protective structure inside the cab RAIL14COM0260AA 47772910 15/12/2014...
  • Page 30: Product Identification

    INTRODUCTION Product identification RAIL14COM0271HC 47772910 15/12/2014...
  • Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
