PCB Piezotronics IMI SENSORS EX686B01 Installation And Operating Manual page 42

Model Number
686B0X
Performance
Alarm Threshold(± 10 %)
Frequency Range(± 3 dB)
Hysteresis(% < Alarm Threshold)
Residual Vibration Level(Reference)
Residual Vibration Level(% Alarm Threshold)
MAVT(Sets Alarm Threshold to 2X actual vibration)
Transverse Sensitivity
Power On Delay(± 1 sec)
Startup Delay(± 1 sec or 1 min)(Time)
Startup Delay(x Alarm Threshold)
Startup Delay(Active)
Operational Delay(± 1 sec)
Relay(Type)
Relay(Latching)
Relay(Contacts)
Environmental
Temperature Range(Operating)
Temperature Range(Storage)
Overload Limit(Shock)
Enclosure Rating
Electrical
Power Required
Current Rating(Relay Closed)
Leak Current(Relay Open)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Torque
Mounting Thread
Sensing Element(Internal)
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
[2]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without
notice.
SMART VIBRATION SWITCH
ENGLISH
0.25 to 5 in/sec pk 4.5 to 90 mm/s rms
420 to 60 kcpm 7 to 1000 Hz
3; 6; or 10 % 3; 6; or 10 %
Dependent or Independent [1]
Dependent or Independent
1 to 40 % 1 to 40 %
Enabled or Disabled Enabled or Disabled
<7 % <7 %
3 or 20 sec 3 or 20 sec
1 to 60 sec or 1 to 30 min 1 to 60 sec or 1 to 30 min
x2; x4; x8; Blocked x2; x4; x8; Blocked
Enabled or Disabled Enabled or Disabled
1 to 60 sec 1 to 60 sec
SPST, Form A or B SPST, Form A or B
MOSFET MOSFET
Latching / Non-Latching Latching / Non-Latching
Normally Open / Closed Normally Open / Closed
-40 to 185 °F -40 to 85 °C
-40 to 257 °F -40 to 125 °C
5000 g pk 49,050 m/s² pk
IP68 IP68
24 to 240 V DC/AC 50/60 Hz 24 to 240 V DC/AC 50/60 Hz
500 mA 500 mA
≤ 1 mA ≤ 1 mA
8
>10 Ohm >10
1.25 in x 2.6 in 1.25 in x 66 mm
5.2 oz 148 gm
3 to 5 ft-lb 4 to 7 Nm
1/4-28 Female 1/4-28 Female
Piezoelectric Accelerometer Piezoelectric Accelerometer
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015 2-Pin MIL-C-5015
Top
SI
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[1]
EX
- Hazardous Area Approval- contact factory for specific approvals
[1]
Current Rating(Relay Closed)
[1]
Hazardous Area Approval
Power Required
[1]
Relay(Capacity)
[1]
[1]
M
[1] - Metric Mount
Supplied Accessory : Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)
[1]
NOTES:
[1] USB Programmable - See configuration sheet supplied with switch for exact setting.
[2] See PCB Declaration of Conformance PS023 or PS060 for details.
8
Ohm
SUPPLIED ACCESSORIES:
Model 081A41 Mounting stud 1/4-28 socket head set screw brass tip stainless steel 5/8" long
Top
(1)
Entered: AP Engineer: do
Date: 9/4/2012 Date: 9/4/2012
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 39883
OPTIONAL VERSIONS
100 mA 100 mA
Cl I, Div 2, Groups A, B, C, D; Cl I, Div 2, Groups A, B, C, D;
Ex nL IICT3, AEx nA IICT3 Ex nL IICT3, AEx nA IICT3
10 to 30 VDC 10 to 30 VDC
10 to 30 VDC, 100 mA 10 to 30 VDC, 100 mA
Sales: EGY Approved: BAM
Date: 9/4/2012 Date: 9/4/2012
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Spec Number:
40110
