  • Page 1 WH 14DSDL ∙ WH 18DSDL WR 14DSDL ∙ WR 18DSDL WH18DSDL WR18DSDL Handling instructions...
  • Page 2: General Power Tool Safety Warnings

    c) Prevent unintentional starting. Ensure the GENERAL POWER TOOL SAFETY switch is in the off position before connecting to WARNINGS power source and/or battery pack, picking up or carrying the tool. WARNING Carrying power tools with your fi nger on the switch Read all safety warnings and all instructions.
  • Page 3: Additional Safety Warnings

    14. Please use the designated attachments which are that can make a connection from one terminal to listed in the operations manual and HiKOKI’s catalog. another. Accidents or injuries could result from not doing so.
  • Page 4: Regarding Lithium-Ion Battery Transportation

    ○ Before storing a battery, remove any swarf and dust that may adhere to it and do not store it together with metal Power Output parts (screws, nails, etc.). 2. Do not pierce battery with a sharp object such as a nail, strike with a hammer, step on, throw or subject the 2 to 3 digit number battery to severe physical shock.
  • Page 5: Standard Accessories

    SPECIFICATIONS The specifi cations of this machine are listed in the Table on page 9. NOTE Due to HiKOKI’s continuing program of research and development, the specifi cations herein are subject to change without prior notice.
  • Page 6 Table 1-a Indications of the pilot lamp Lights for 0.5 seconds. Does not light for Before Blinks 0.5 seconds. (off for 0.5 seconds) charging While Lights continuously Lights charging Lights for 0.5 seconds. Does not light for Charging Blinks 0.5 seconds. (off for 0.5 seconds) Pilot lamp.
  • Page 7: Mounting And Operation

    (every second), please take the charger to the HiKOKI tightening torque. Pay attention to wear of a socket holes periodically, and replace with a new one if needed.
  • Page 8 NOTE When replacing the carbon brush with a new one, be sure to use the HiKOKI Carbon Brush Code No. 999054. 6. Replacing carbon brushes (Fig. 11) Take out the carbon brush by fi rst removing the brush cap and then hooking the protrusion of the carbon brush with a fl...
  • Page 9 WH14DSDL WH18DSDL WR14DSDL WR18DSDL 14.4 14.4 /min 0 - 2600 0 - 2600 0 - 2600 0 - 2600 /min 0 - 2000 0 - 2000 0 - 2000 0 - 2000 /min 0 - 3200 0 - 3200 0 - 3200 0 - 3200 4 - 10 4 - 10...
  • Page 10 〈UC18YFSL〉 〈UC18YKSL〉 〈UC18YSL3〉...
  • Page 12 11.5mm...
  • Page 13 14.4V (Li-ion) 336471 18V (Li-ion) 336475 999054 UC18YKSL (14.4V - 18V) 337131 UC18YFSL (14.4V - 18V) 329897 UC18YSL3 (14.4V – 18V) 337140...
  • Page 16 Shinagawa Intercity Tower A, 15-1, Konan 2-chome, Minato-ku, Tokyo, Japan Code No. C99708111 G Printed in China...
