Summary of Contents for Nuna trvl
- Page 1 trvl...
- Page 2 Whatever made you fall in love with Nuna, rest assured your adventures with your little one will be easier from now on, freeing you to enjoy more happy family moments together.
-
Page 3: Table Of Contents
Contents Product Information Product Registration IMPORTANT! Warranty Contact KEEP THESE Child Usage Requirements INSTRUCTIONS FOR Warnings FUTURE REFERENCE: Parts List READ CAREFULLY Product Setup Product Use Accessories Cleaning and Maintenance TRVL instructions TRVL instructions... -
Page 4: Product Information
For warranty information please visit: www.nunababy.com/warranty Contact For replacement parts, service, or additional warranty questions, please contact our customer service department. In the USA: infousa@nunababy.com www.nunababy.com 1.855.NUNA.USA TRVL instructions TRVL instructions... -
Page 5: Warnings
The stroller does not replace a crib or a bed. Should your child approved by Nuna, e.g. child seats, bag hooks, rain covers, need to sleep, they should be placed in a crib or sleeping area buggy boards, etc., may damage or make the stroller unsafe. -
Page 6: Parts List
Parts List Make sure all parts are available before assembly. If any part is missing, please contact Nuna (see page 4 for information). No tools are required for assembly. 13 Infant Carrier Lock Stroller Frame 14 Secondary Lock Armbar 15 Handle... -
Page 7: Product Setup
- Open the stroller frame. - A “click” sound means the stroller frame is open completely. Check that the stroller is completely latched open before continuing. Storage Basket - Hook the storage basket on the rear legs on both sides. TRVL instructions TRVL instructions... - Page 8 Check that the wheels are securely attached by pulling out. - To remove the front wheel, slide the release button out (1) and then detach the front wheel from the front leg (2). click TRVL instructions TRVL instructions...
- Page 9 - To remove the armbar, press the armbar release buttons (1) and pull the armbar out (2). click Check Setup Stroller frame is latched open Rear and front wheels are securely attached Armbar is securely attached click TRVL instructions TRVL instructions...
-
Page 10: Product Use
- Open the harness covers to adjust the harness. - Fit the harness snugly to your child by sliding the adjustment straps to tighten. Shoulder Harness Position - The upper shoulder harness buckles can be moved up and down for added adjustment. TRVL instructions TRVL instructions... - Page 11 (3). Recline - To raise the recline, pull the recline adjustment straps and push the seat up. - To recline the backrest, squeeze the recline adjustment handle and pull the backrest down. TRVL instructions TRVL instructions...
- Page 12 - Slide the tab on the harness pad through the shoulder harness buckle. - Fold the harness pad and fasten the snaps. TRVL instructions TRVL instructions...
- Page 13 Front Swivel Locks It is recommended to use the front swivel locks on uneven surfaces. - Turn the front swivel lock to lock the front wheel. - Turn the front swivel lock back to unlock it. TRVL instructions TRVL instructions...
- Page 14 - Fold the canopy. - Slide the lock against the handle (1) and then squeeze the folding button (2). - Fold the top of the stroller down. - The frame can fold and stand on its own. TRVL instructions TRVL instructions...
-
Page 15: Accessories
Pull up on the infant carrier to check that it is fully locked to the stroller. Remove the infant carrier before folding the stroller. - To remove the infant carrier, release the infant carrier lock, squeeze the release handle (1), and lift the infant carrier up (2). TRVL instructions TRVL instructions... -
Page 16: Cleaning And Maintenance
For reasons of safety, only use original Nuna parts. Check regularly if everything functions properly. If any parts are torn, broken, or missing, stop using this product. Nuna Baby Essentials, Inc. Nuna and all associated logos are trademarks. TRVL instructions...
