- Page 1 USER GUIDE My eartip size: My battery size: 312 (brown tab) 1-800-221-2099 an IntriCon company PO Box 586 • DeKalb, IL 60115 • HearingHelp.com...
-
Page 2: Table Of Contents
IntriCon company WELCOME TO HEARING HELP EXPRESS! Congratulations on your choice of the Ranger-8720 hearing aid to help you on your journey to improved hearing. We’re confident you’ll enjoy all the benefits the Ranger® has to offer, especially knowing you saved thousands of dollars without sacrificing hearing improvement. -
Page 3: Parts Identified
The fit of your hearing aid is very important. Try the different sizes of eartips until you find one that is secure and comfortable. BATTERY INFORMATION Your Ranger-8720 uses a size 312 (brown tab) zinc-air battery Hearing Help Express offers a variety of premium battery brands. -
Page 4: How To Insert Battery
When the battery is no longer strong LOW BATTERY INDICATOR enough to power your Ranger-8720, you will hear a voice prompt say “low battery” (this repeats every 8 minutes). Your Ranger-8720 will shut down after you hear a voice prompt say “replace battery”. -
Page 5: Eartips / Attaching & Removing
HOW TO ATTACH REMOVE THE EARTIP ATTACHING THE EARTIP: Push the flat end of the silicone eartip securely onto the firm, plastic elbow joint at the end of the tubing. REMOVING THE EARTIP: Hold the eartip between two fingers and grasp the elbow area of the tubing and pull the two parts away from each other. -
Page 6: Which Is Left And Right
WHICH IS LEFT AND RIGHT How to tell your right aid from your left aid: Your Ranger-8720 hearing aid can be used on either ear. Once you have attached your eartip or custom earmold your hearing aid is set for either your right or left ear. -
Page 7: Volume Control
ADJUSTING THE VOLUME CONTROL Volume Control: Your Ranger-8720 is equipped with a push button volume control (located above the battery holder compartment. volume control (located above the battery holder compartment. This button allows you to select your listening volume. Increase the volume: With your fingertip repeatedly press the volume control button. - Page 8 ADJUSTING THE VOLUME AND PROGRAM SETTINGS USING YOUR SMART PHONE On your smartphone, DOWNLOAD the HHE Hearing app from the App Store or Google Play store. Connect your hearing aid(s) to the app **Your hearing aids must be turned on in order to connect to the app** Open the HHE Select the Follow the prompts...
-
Page 9: Cleaning & Care Instructions
Ranger-8720s. Water and such sprays can damage hearing aids. And please remember, your hearing aids are sensitive and don’t like extreme heat or cold. Never place your Ranger-8720 in water. If it becomes wet, immediately remove the battery and let your Ranger stand in a dry place or DryAid dehumidifier for several hours. -
Page 10: Troubleshooting/Service
TROUBLESHOOTING YOUR RANGER If your hearing aid is: WHISTLING (FEEDBACK) Your Ranger-8720 may briefly whistle when a hand, hat or other object is near it or when inserting and removing. Turn the volume down, it may be set too high (pg. 7 or pg. 8). -
Page 11: Service Plans
PROTECT YOUR HEARING INVESTMENT Protection Plan – worry-free hearing aid repairs or replacements! One and two year plans available (call for pricing). • Get PROTECTED - If your hearing aid gets wet, is dropped or even stepped on, we’ll fi x or replace it free of charge for the term of the plan (loss or theft are not covered). -
Page 12: Additional Information
Precautions: A hearing aid is a precision electronic device and medical evaluation from a licensed physician. as such, it requires the care in use and handling that you would Federal law permits a fully informed adult to sign a waiver afford any fine piece of equipment. -
Page 13: Technical Data
8720 RANGER TECHNICAL INFORMATION Maximum SSPL90 129.7 dB HFA SSPL90 125 dB HFA full-on gain 51.9 dB Reference test gain 48.2 dB Frequency range 200 Hz to 6032 Hz Equivalent input noise 25.7 dB SPL Total harmonic distortion 500 Hz: 3.2%, 800 Hz: 2.4%, 1600 Hz: .2% Attack time (msec) Release time (msec) Induction coil sensitivity (at 31.6 mA/m) HFA... -
Page 14: Accessories
All prices subject HELPFUL ACCESSORIES to change. Eartips – Eartips come in five different sizes. You can improve the fit by using a different size eartip. small med-small medium med-large large Eartips should be cleaned and/or replaced when necessary. small (S) #88581 $2.50 SAVE! - Page 15 Battery Care Kit, item #25101 $24.99 Order Risk-free! Try any Hearing Help Express accessory for 30 days risk-free. If you’re not 100% satisfi ed, return all materials within 30 days from the date of delivery, and we’ll refund 100% of your purchase price.
-
Page 16: Warranty
You are responsible for the safe return of all materials in their original condition. Ship insured mail. One Year Limited Manufacturer’s Warranty Your Ranger-8720 hearing aid is warranteed for one year against defects in manufacturer's materials and workmanship. That means if they didn't do a good job making your hearing aids then we're going to fix them.
