Better hearing –
JUST THE BASICS
1.
Insert the battery.
2.
Position the Style Pro
behind your ear and
gently push the ear tip
into your ear canal.
3.
Secure in place with
the sure-lock.
4.
Adjust the volume.
Ready ...Set ...Go!
Look inside for
complete instructions.
Hansaton
Style Pro
Advertisement
Related Manuals for Hearing Help Express Hansaton Style Pro
Summary of Contents for Hearing Help Express Hansaton Style Pro
- Page 1 Better hearing – Ready ...Set ...Go! JUST THE BASICS Look inside for Insert the battery. complete instructions. Position the Style Pro behind your ear and gently push the ear tip into your ear canal. Secure in place with the sure-lock. Hansaton Style Pro Adjust the volume.
- Page 2 Lightweight and comfortable So, put the Hansaton Style Pro to the test and find out if it’s right for you. We only ask that you read these instructions so you can make the most of your Hansaton Style Pro. And do take advantage of your 45-day home trial.
- Page 3 Introduction Style Pro controls 12-13 Table of contents Care and cleaning 14-15 Style Pro parts identified Helpful tips How to insert battery Troubleshooting/service Slim-tubing choices Additional information 18-19 How to attach the slim-tubing Technical data 20-21 How to tell Left from Right Accessories 22-23 (Prices subject to change.)
- Page 4 On / Off Control: Power level 3 Your Style Pro turns on once the battery is Microphone installed and the battery Ports door is closed. To turn Slim it off simply open the Dual-purpose tubing battery door. control (Volume wheel/ Serial number: program button) Located on the back...
- Page 5 1. Remove the brown colored tab from the flat, positive side (+) of the size 312 battery. Many batteries need a minute to activate. 2. Open battery compartment gently, with a finger nail. 3. Place the battery in the battery door (NOT directly inside the hearing aid).
- Page 6 Your Style Pro arrives ready to be used with the most popular size ear tip and tubing already attached. Men will find the following: Size 3 tubing and large ear tip attached. Extras included: size 2 tubing, small ear tip, medium ear tip. Women will find the following: Size 2 tubing and medium ear tip attached.
- Page 7 How to attach the slim-tubing: 1. Line up the triangular base of the slim-tubing with the metal stem on the Style Pro hearing aid. 2. Push the two parts together and rotate the tubing to lock into place. How to remove the slim-tubing: 1.
- Page 8 How to tell your right aid from your left aid: Style Pro hearing aids can be used in either ear by selecting a right slim-tubing or a left slim-tubing. Each slim-tubing is preformed to “point” into either the right or left ear. Right tubing has red lettering on it and left tubing has blue lettering printed near the ear tip.
- Page 9 Ear tip choices: Dome Large Dome Medium Dome Small How to attach ear tip: 1. Line up the narrow tubing nozzle with the opening on the inside of the ear tip. 2. Push together firmly until the ear tip is securely attached.
- Page 10 Inserting the Style Pro: 1. Place your Style Pro over the top of your ear. 2. Hold the slim-tubing behind the ear tip and gently push the ear tip into your ear canal. 3. The slim-tubing will probably bulge slightly near the ear canal. Point at the bend in the tubing and push gently.
- Page 11 Inserting the Style Pro: 4. Place the sure-lock into the bowl of your ear. The sure-lock is the thin filament attached to the tubing. Use your finger to secure the sure-lock into the most comfortable position. When finished tubing should be To Remove: flush with skin and barely noticeable.
- Page 12 Style Pro controls Your Style Pro has a dual-purpose control that functions as both the volume control wheel and the push button program control. Adjusting the volume: You adjust the volume up and down by rotating Increase the volume control wheel. As you increase or decrease the volume you will hear one soft beep at each volume level.
- Page 13 Style Pro program push button When you push the dual-purpose control you will hear beeps. The number of beeps refers to the setting. When the Style Pro is turned on it starts at setting 1. Setting 1: Daily setting – 1 beep. Use in most listening situations. (First program when the Style Pro is turned on.) Setting 2: Easy-focus in noise –...
- Page 14 Clean your Style Pro hearing aid regularly. Without regular cleaning, wax and moisture can build up and prevent the hearing aid from work- ing properly. It is best to clean your Style Pro in the morning before you use it. (Many people find it best to clean the ear tip and tubing weekly.) How to clean your Style Pro: Cleaning Brush 1.
- Page 15 How to clean your Style Pro tubing and ear tip: 1. Gently remove the slim-tubing from the hearing aid. (See pg. 7 for tubing removal instructions) 2. Insert the cleaning tool into the triangular base at the end of the slim-tubing.
- Page 16 1. Start Slowly – Begin by using your new hearing aid a few hours a day while you are alone. If you are not used to wearing a hearing aid, you will probably notice many sounds you have not heard in a while.
- Page 17 Call toll-free to order. (p. 14) If your hearing aid requires service, send it to: Hearing Help Express • 105 N First St • PO Box 586 • DeKalb, IL 60115-0586 1. Enclose a note with your name, address, 3. Pack your hearing aid securely in a sturdy phone number and a description of what box.
- Page 18 Precautions: A hearing aid is a precision occurs, consult your physician. identified and treated before the hearing electronic device and as such, it requires aid is purchased. Keep new and used batteries out of the care in use and handling that you reach of children and those with Following the medical evaluation, the would afford any fine piece of equipment.
- Page 19 Federal law restricts the sale of hearing (preferably an ear specialist) before dis- NOTE: Special care should be exercised in aids to those individuals who have pensing a hearing aid if the hearing aid selecting and fitting a hearing aid whose obtained a medical evaluation from a dispenser determines through inquiry, maximum sound pressure level exceeds...
- Page 20 Hansaton Style Pro Technical Data Maximum SSPL90 114 dB HFA SSPL90 98 dB HFA full-on gain 28 dB Reference test gain 22 dB Frequency range 100 Hz to 7700 Hz Equivalent input noise 12 dB Total harmonic distortion 500 Hz: 3.3%, 800 Hz: 1.5%, 1600 Hz: .9%...
- Page 21 Style Pro 2cm Coupler Curves OSPL90 Frequency Response Curve Input-Output Curve...
- Page 22 Dome Ear Tips Dome Small #89121 Dome Medium #89122 Dome Large #89123 Dome Ear Tips $2.50 Dome Large Dome Medium Dome Small SAVE: 3 of any size (Dome large for men, medium for women originally on tubing) for only $5.95 Style Pro Slim-Tube and Ear Tip Cleaning Tool Easily remove debris and wax from the sound tubing and ear tip.
- Page 23 Slim-Tubing (Men received: size 3 tubing attached to Style Pro, size 2 sent as extra. Women received: size 2 tubing attached to Style Pro, size 1 sent as extra.) Left #88690 #88692 Blue writing on slim-tube #88694 indicates left ear tubing size #88696 (dome tip not included).
- Page 24 45-Day, Risk-Free Trial One Year Warranty Money-Back Guarantee on Parts and Labor Try your Style Pro Hearing Help Express® Your Style Pro Hearing Help Express hearing aid for 45 days risk-free. If you hearing aid is warranteed for one year...
