Related Manuals for Hearing Help Express Apollo-6310 Puma
Summary of Contents for Hearing Help Express Apollo-6310 Puma
- Page 1 Puma Apollo -6310 ™ User Guide My eartip style & size: My tubing size: My battery size: 312 (brown tab) 1-800-221-2099 © Hearing Help Express®, Inc. Trusted Since 1979...
-
Page 2: Table Of Contents
By entering in a trial for our products you agree to follow the user guide for safe and proper use and care of the device(s). Hearing Help Express, Inc. is not responsible for harm or damages incurred due to improper use or care of the device(s). -
Page 3: Parts Identified
Parts Identified Puma Apollo-6310 Get to know your Battery Size: 312 Battery Size: 312 (brown tab) (brown tab) 1. Microphone and Receiver 4. Slim-tube 4. Slim-tube 2. Dual-function rocker control 5. Eartip • Volume control 6. Sure-lock • Listening settings Serial number is located on 3. -
Page 4: How To Insert Battery
Try using the battery magnet located Inserting the Battery on the end of the enclosed cleaning tool. 1. Remove the brown colored tab from the flat, (+) positive side of the size 312 battery. Wait one minute for battery to reach full power before using (or testing) battery. -
Page 5: Tubing Choices / Removing & Attaching
Slim Tube Choices There are four sizes of slim-tubing available for the right Picturing Left ear slim-tubing and left ear. Attached to your hearing aid is the size we feel works best for most people. We have also included an additional size slim-tubing for you to try if needed. -
Page 6: Eartip Choices / Removing & Attaching
Eartip Choices We offer a variety of eartip options. We have attached the eartip style that we feel works best for most. Also included are several other eartip options. If you have trouble with the fit or the eartip or if you experience feedback (squeal), give the other eartips a try. -
Page 7: Inserting & Removing Apollo-6310
Insert & Remove Apollo-6310 How to insert the Apollo-6310: 1. Grasp the slim-tubing behind the eartip and gently push the eartip into your ear canal. 2. Place your Apollo-6310 over the top of your ear. 3. The slim-tubing will probably bulge slightly near the ear canal. -
Page 8: Volume Control
Adjusting the Volume Control Volume Control: Your Apollo-6310 is equipped with a dual-function rocker that controls both the volume level and listening settings. Increasing the volume: Each time you push the top end of Bottom the rocker control, you’ll increase one volume level (there are 15 volume levels). -
Page 9: Care & Cleaning
Care and Cleaning We’ve done what we can to protect your Apollo-6310 from moisture and earwax but a little regular cleaning by you will go a long way towards trouble-free use. Without regular cleaning, wax and moisture can build up and prevent your Apollo-6310 from working properly. We suggest cleaning your Apollo-6310 in the morning before you use it and storing it overnight in a DryAid Dehumidifier (call to order). -
Page 10: Helpful Tips
IMPORTANT CARE INSTRUCTIONS BEGINNING THE DAY: After showering, apply all lotions, creams, hairspray, perfume and cologne BEFORE putting on your Apollo-6310s. Water and such sprays can damage hearing aids. And please remember, your hearing aids are sensitive and don’t like extreme heat or cold. Never place your Apollo-6310 in water. -
Page 11: Service Plans
Protect your hearing investment Protection Plan – One year of worry-free hearing aid repairs or replacements! (call for pricing) • Get PROTECTED - Water, droppage, step on it - you name it! We will fix or replace it free of charge for one year (loss or theft are not covered). •... -
Page 12: Troubleshooting/Service
(p. 9). Call toll-free to order. Service If your Apollo-6310 requires service, send it to: Hearing Help Express 1714 Sycamore Rd • PO Box 586 • DeKalb, IL 60115-0586 1. Call 1-800-221-2099 for 3. Pack your device securely in a authorization before returning sturdy box. -
Page 13: Technical Data / Additional Info
Apollo-6310 Technical Information Maximum SSPL90 120 dB HFA SSPL90 105.9 dB HFA full-on gain 37.5 dB Reference test gain 30.1 dB Frequency range 200 Hz to 7100 Hz Equivalent input noise <26 dB Total harmonic distortion 500 Hz: .2%, 800 Hz: .3%, 1600 Hz: 1.1% Attack time (msec) Release time (msec) Typical Peak Gain... - Page 14 Precautions: A hearing aid is a precision electronic device and licensed physician. Federal law permits a fully informed adult to as such, it requires the care in use and handling that you would purchase hearing aids by mail with or without seeking a medical afford any fine piece of equipment.
-
Page 15: Accessories
Helpful Accessories All prices subject to change. Tulip Dome Eartips – $4.95 each SAVE Tulip Dome Eartip 3 for $11.97 Tulip Dome #89115 Open, Closed, and Double Dome Eartips – $2.50 each Double Dome Eartips Open Dome Eartips Small Double Dome #86231 Small Open Dome #86251... - Page 16 Helpful Accessories Battery Care Kit – Worry-free hearing aid battery use. Worry-free hearing aid battery use. Battery Care Kit includes: • Digital Keychain Battery Tester – Small enough to go with Small enough to go with you anywhere. Takes the guesswork out of battery testing. •...
- Page 17 NANO CLEAN, item #88755 $10.99 Order Risk-free! Try any Hearing Help Express accessory for 30 days risk-free. If you’re not 100% satis ed, return all materials within 30 days from the date of delivery, and we’ll refund 100% of your purchase price.
-
Page 18: Important Information
We thought you’d like to know... Two hearing aids are better than one! If you have hearing loss in both ears, then you most likely need two hearing aids. Being able to hear with both ears allows for a balanced and full sound experience. - Page 19 “ This is my second purchase from Hearing Help Express. I highly recommend calling if you have questions or need help. They go above and beyond for their customers! Thanks! K.S. – LA “ Many thanks to your caring staff for being so kind and patient with me over the phone.
-
Page 20: Warranty
Your 2-way assurance of complete satisfaction 45-Day, Risk-Free Trial One Year Limited Money-Back Guarantee Manufacturer's Warranty Try your Hearing Help Express® Your Apollo-6310 hearing aid is Apollo-6310 hearing aid for 45 days warranteed for one year against risk-free. If you are not 100% satisfied,...
