MIDI settings

This section explains settings related to MIDI.
Setting the MIDI channels for pattern
parameters
① While pressing the
key, and select PT.CH.
② Turn the VALUE knob to set the channel.
• The channel is shown on the display.
• The setting range is OFF and CH.01 – CH.16.
• The channel will be used for sending and receiving.
Setting the MIDI channel for accessing
the active track (auto channel)
① While pressing the
key, and select AT.CH.
② Turn the VALUE knob to set the channel.
• The channel is shown on the display.
• The setting range is OFF and CH.01 – CH.16.
• The channel will be used for sending and receiving.

Setting the output channel

① While pressing the
key, and select O.CH.
② Turn the VALUE knob to select the channel to
use.
• The channel is shown on the display.
• The setting options are TRCK and AUTO.
Turning control change transmission
on/off
① While pressing the
button, and select TX.CC.
② Turn the VALUE knob to turn this ON/OFF.
• ON/OFF will appear on the display.
• Control change reception is always enabled.
button, press the MIDI CH
button, press the MIDI CH
button, press the MIDI CH
button, press the
MIDI

Turning MIDI clock output on/off

① While pressing the func button, press the
button, and select TX.CK.
② Turn the VALUE knob to turn this ON/OFF.
• ON/OFF will appear on the display.

Setting MIDI OUT

① While pressing the
and select M.OUT.
② Turn the VALUE knob, and set MIDI OUT.
• OUT/THRU will appear on the display.
Setting MIDI command receipt and
transmission
① While pressing the
and select M.CMD.
② Turn the VALUE knob, and select the MIDI
command setting.
• The setting is shown on the display.
• 4 settings can be chosen.
1. OFF: Neither transmit nor receive
2. RX: Only receive
3. TX: Only transmit
4. RX.TX: Transmit and receive
Turning active sensing transmission
ON/OFF
① While pressing the func button, press the
key, and select TX.AS.
② Turn the VALUE knob to turn this ON/OFF.
• ON/OFF will appear on the display.
Turning active sensing reception
ON/OFF
① While pressing the
and select RX.AS.
② Turn the
VALUE knob to turn this ON/OFF.
29
MIDI
button, press the MIDI key,
button, press the MIDI key,
MIDI
button, press the MIDI key,
