Page 1: Elz_1 Version 2 Manual Supplement
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 ELZ_1 Version 2 Manual Supplement Rev. 1.0... -
Page 2: Table Of Contents
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Contents ..............................1 ELZ_1 Version 2 Manual Supplement ..................1 About this manual ......................3 Step sequencer ......................... 3 Enabling step sequence mode................... 3 Screen ........................4 Main operations in step sequencer mode ..............4 Step recording ...................... -
Page 3: About This Manual
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 About this manual This manual explains features added in the Version 2 SYSTEM firmware. Step sequencer A 64-step/6-voice step sequencer has been added in Version 2. Up to 128 patterns can be created in the step sequencer. -
Page 4: Screen
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Screen ❶ ❷ ❸ ❹ ❶ Pattern number/save destination Pattern number ❷ Operation guide ❸ STEP location ❹ Piano roll Main operations in step sequencer mode Button Function OK button Start/stop sequence playback... -
Page 5: Step Recording
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Step recording In this mode, notes can be input step-by-step at any pace. ① When stopped, press the SAVE button to start recording. ② Use the STEP parameter to select the desired step. -
Page 6: Parameters When Stopped/Step Recording
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Parameters when stopped/step recording Parameters when stopped/step recording TYPE Stopped: PTN 000 ‒ 127 Stopped: Select pattern knob Step recording: SAVE TO Step recording: Select where to save PRM1 STEP 1 ‒ 64... -
Page 7: Real-Time Recording
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Real-time recording In this mode, notes are input in real time. ① During playback, press the SAVE button to start recording in real time. ② Play the keyboard with the desired timing ③... -
Page 8: Parameters When Playing Back/Real-Time Recording
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Parameters when playing back/real-time recording Parameters when playing back/real-time recording TYPE Playing: PTN 000 ‒ 127 Playing: Select pattern knob Recording: SAVE TO Recording: Select where to save PRM1 REC MODE ADD, This sets how recording occurs. -
Page 9: Pattern Management
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Pattern management Use the PATTERN menu to manage pattern settings in the ELZ_1. ① Press the MENU button. ② Use the DOWN and UP buttons to select PATTERN. ③ Press the OK button to open the PATTERN menu. -
Page 10: Initializing The Settings Of One Pattern
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Initializing the settings of one Pattern A pattern can be initialized to basic settings. ① Use the DOWN and UP buttons to select the desired pattern, and press the OK button. ② Use the DOWN and UP buttons to select Initialize, and press the OK button to open a confirmation screen. -
Page 11: Importing Pattern Settings
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 It will be saved in the MEMORY folder in the unit storage. The following characters and symbols can be used. ABCDEFGHIJKLMNOPQRSTUVWXYZ abcdefghijklmnopqrstuvwxyz 0123456789 !#$%&'()+,-.;=@[]^_`{}̃ (space) Importing Pattern settings A pattern file saved in the ELZ_1 storage can be imported to the selected Pattern slot. -
Page 12: Synchronizing The Elz_1 With External Clock (Clock Menu)
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Synchronizing the ELZ_1 with external clock (CLOCK menu) The ELZ_1 arpeggiator and step sequencer can be synchronized with an external clock source. Use the CLOCK menu to select the clock source. ① Press the MENU button. -
Page 13: Sync Function
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 SYNC function Important Proper connection with all SYNC devices is not guaranteed. Never input voltage higher than through the ELZ_1 AUX IN jack. Doing so could cause damage. Clock pulses output from KORG volca series devices and Teenage... -
Page 14: Adjusting The Sync Signal Input Gain
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Adjusting the sync signal input gain If the ELZ_1 sequencer or arpeggiator does not synchronize properly with the sync signal, try adjusting the input gain for the sync signal. ① Press the MENU button. -
Page 15: Using The Sync Thru Function
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Using the SYNC THRU function When enabled, the sync signal input through the AUX IN will be output through the left channel of the headphone jack. ① Set the clock source to Sync (Thru). (See... -
Page 16: New Synth Engine Functions
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 New synth engine functions Modulation added for additional parameters The synth engines with added parameters that can be modulated are as follows. Synthesizer engine Parameters that can now be selected with ASSIGN... -
Page 17: Additional User Data Now Backed Up
SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 Additional user data now backed up User data backed up The following data is backed up. • MEMORY 0 ‒ 127 • Bank01 ‒ 50 and FM01 ‒ 20 waveforms used by 8BIT WAVE MEMORY •... - Page 18 SONICWARE ELZ_1 Version 2 Manual Supplement Rev. 1.0 SONICWARE INC. www.sonicware.jp ELZ_1_ADM_EN_A...
