ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Cabinet
• Grille (for Charcoal)
(for Platinum)
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
406-000-05091 Owner's manual International Version
406-000-00921 (OWNER'S MANUAL) & 405-000-00328 (WARRANTY CARD)
POSITIONED ON THE TOP OF INNER CARTON
398-FE-00264
(BUBBLE LEVEL AND
METAL PLATE)
373-000-00128
8Ω
125 watts*
100Hz – 20kHz (±3dB)
86dB (2.83V @ 1 meter)
2500Hz, 12dB/Octave
MS-1 (Not for Sale)
II
244-040-00254G
244-040-00254W
4" (102mm) CMMD, ™
magnetically shielded
10PR80BZR-DW01
3.3 ohms ±10%
3/4" (19mm) CMMD, ™
magnetically shielded
60DA20AD-DT01
3.0 ohms ±10%
0B-1500-00751
The MS-1 satellites are part of the
II
Modulus Home Theater System.
II
431-000-00956
(POLYFOAM SET TOP/BOTTOM)
PLASTIC BAG
431-000-01014 (EPE)
431-000-00956
(POLYFOAM SET TOP/BOTTOM)
431-000-00958
(POLYFOAM SET TOP/BOTTOM)
PLASTIC BAG
431-000-00958
(POLYFOAM SET TOP/BOTTOM)
400-000-04383 (INNER CARTON)
402-000-01845 (GIFT BOX)
BATTERY
398-ABS-00312
(TESTING DISK)
398-PVC-00263
(PVC SHEET)
221-000-00344 (PVC COVER)
033-000-00101 (ABS MICROPHONE)
431-000-00957
(POLYFOAM SET TOP/BOTTOM)
PLASTIC BAG
431-000-00957
(POLYFOAM SET TOP/BOTTOM)
GIFT BOX 402-000-01774 (PLATINUM)
402-000-01772 (CHARCOAL)
402-000-05164(PLATINUM
INTERNATIONAL VERSION)
Infinity Systems, 250 Crossways Park Drive, Woodbury, New York 11797
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Dimensions – Shelf Position 11" x 5-1/2" x 4-1/2"
(H x W x D)
Wall Position
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
MS-1 WIRING DIAGRAM
II
RED
YEL
60DA20AD-DT01
RED
YEL
NETWORK
0B-1500-00751
MS-1
II
+
L1
1.2mH
INPUT
—
R1
2.7ohm
1.8uf
7W
100V
6.0V Input 100Hz to 20kHz
5.0V Input 100Hz to 3kHz
2.83V Input 2kHz to 20kHz
(279mm x 140mm x 114mm)
9-3/4" x 5-1/2" x 5-3/4"
(248mm x 140mm x 146mm)
5.1 lb (2.3kg) Each
(4 pcs. in the Modulus Home
Theater System)
(1 pc. in the Modulus MS-1
Single Pack)
TWEETER
RED
RED/BLK
WOOFER
10PR80BZR-DW01
SCHEMATIC
120mm GRN
.205
C1
L.F.
12uf
100V
120mm WHT
.110
100mm BLU
.187
C2
L2
H.F.
0.40mH
100mm WHT
.110
Rev2 03/05
II
6/04
