MSW-II
S C
UBWOOFER ONNECTIONS
If you have a Dolby* Digital or DTS
with a low-frequency-effects (LFE) output:
SUBWOOFER OR
LFE OUTPUT
R.A.B.O.S.™
Controls
Modulus MSW-II
This unit is designed to become quite warm,
during normal operation.
• Set Low-Pass Filter § to "Off" .
® receiver/processor
R.A.B.O.S.
™ ¡
Freq.
ON OFF
PHASE
∞
180° 0°
£
Width LOW PASS
§
ON OFF
¢
Level INPUT
LFE
¶
L R
NRTL/C
CSA22-2 NO. 1
UL 1492
POWER
•
FUSE AC 120V~60Hz
T5A L/250V 75 Watts
If your receiver/processor has subwoofer
outputs for the left and right channels:
RECEIVER/PROCESSOR
™ ¡
R.A.B.O.S.™
Freq.
Controls
£
Width
¢
Level
Modulus MSW-II
This unit is designed to become quite warm,
during normal operation.
• Set Low-Pass Filter § to "On. "
MODULUS II HOME THEATER SYSTEM
R.A.B.O.S.
ON OFF
PHASE
∞
180° 0°
LOW PASS
§
ON OFF
INPUT
LFE
¶
L R
NRTL/C
CSA22-2 NO. 1
UL 1492
POWER
•
FUSE AC 120V~60Hz
T5A L/250V 75 Watts
