Infinity MODULUS II Service Manual page 2

Technical Manual
MCC-1
II
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Cabinet
• Grille (for Charcoal)
(for Platinum)
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
406-000-05091 Owner's manual International Version
406-000-00921 (OWNER'S MANUAL) & 405-000-00328 (WARRANTY CARD)
POSITIONED ON THE TOP OF INNER CARTON
398-FE-00264
(BUBBLE LEVEL AND
METAL PLATE)
373-000-00128
8Ω
125 watts*
80Hz – 20kHz (±3dB)
88dB (2.83V @ 1 meter)
2500Hz, 12dB/Octave
MCC-1 (Not for Sale)
II
244-040-00253B
244-040-00253W
Dual 4" (102mm) CMMD, ™
magnetically shielded
10PR80BZR-DW01
3.3 ohms ±10%
3/4" (19mm) CMMD, ™
magnetically shielded
60DA20AD-DT01
3.0 ohms ±10%
013-7500-00752
The MCC-1 center is part of the
II
Modulus Home Theater System.
II
431-000-00956
(POLYFOAM SET TOP/BOTTOM)
PLASTIC BAG
431-000-01014 (EPE)
431-000-00956
(POLYFOAM SET TOP/BOTTOM)
431-000-00958
(POLYFOAM SET TOP/BOTTOM)
PLASTIC BAG
431-000-00958
(POLYFOAM SET TOP/BOTTOM)
400-000-04383 (INNER CARTON)
402-000-01845 (GIFT BOX)
BATTERY
398-ABS-00312
(TESTING DISK)
398-PVC-00263
(PVC SHEET)
221-000-00344 (PVC COVER)
033-000-00101 (ABS MICROPHONE)
431-000-00957
(POLYFOAM SET TOP/BOTTOM)
PLASTIC BAG
431-000-00957
(POLYFOAM SET TOP/BOTTOM)
GIFT BOX 402-000-01774 (PLATINUM)
402-000-01772 (CHARCOAL)
402-000-05164(PLATINUM
INTERNATIONAL VERSION)
Infinity Systems, 250 Crossways Park Drive, Woodbury, New York 11797
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Dimensions
(H x W x D)
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
MCC-1 WIRING DIAGRAM
II
GRN
YEL
TWEETER
60DA20AD-DT01
RED
BLK
NETWORK
013-7500-00752
MCC-1
+
L1
2.4mH
INPUT
C1
9.1uf
100V
–
R1
3.3ohm
7W 2.7uf
100V
6.0V Input 80Hz to 20kHz
5.0V Input 80Hz to 3kHz
2.83V Input 2kHz to 20kHz
6-1/4" x 20-3/4" x 4-1/2"
(159mm x 527mm x 114mm)
8.3 lb (3.8kg) Each
GRN
WHT
WOOFER
10PR80BZR-DW01
GRN
WHT
WOOFER
10PR80BZR-DW01
SCHEMATIC
II
60mm GRN
.205
L.F.1
60mm WHT
.110
60mm GRN
.205
L.F.2
60mm WHT
.110
50mm BLU
.187
C2
L2
H.F.
0.65mH
50mm WHT
.110
Rev2 03/05
6/04
