210 SERIES COMPACT NETWORK SWITCHES
Quick Start Guide
AN-210-SW-C-8-PoE

Advertisement

loading
Need help?

Need help?

Do you have a question about the 210 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Araknis Networks 210 Series

Summary of Contents for Araknis Networks 210 Series

  • Page 1 210 SERIES COMPACT NETWORK SWITCHES Quick Start Guide AN-210-SW-C-8-PoE...

  • Page 3: Fcc Warning

    210 Series Compact Network Switches Quick Start Guide FCC Warning Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the...
  • Page 4 210 Series Compact Network Switches Quick Start Guide CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. UL Statement All models have been evaluated by UL.

  • Page 5: Welcome To Araknis Networks

    210 Series Compact Network Switches Quick Start Guide Welcome to Araknis Networks™ Thank you for choosing an Araknis 210-series Compact Network Switch. This PoE-powered switch features Gigabit connectivity on all ports, updated modern aesthetics, and a level of control rarely seen in managed solutions. The Araknis 210-series switch is a sleek and highly capable addition to any network.
  • Page 6 210 Series Compact Network Switches Quick Start Guide Step 1: Unbox Switch Rubber Feet (4) Structured Wiring Spare Can Mounting Can Mounting Kit Push Pins (4) w/ Push Pins (2) Body: 8.5mm(D), 10.4mm(L), 6.35mm(W) Pin: 8.5mm(D), 18.2mm(L), 3.7mm(W) Shelf Mount Kit:...
  • Page 7 210 Series Compact Network Switches Quick Start Guide Step 2: Install 210 compact switches feature several mounting options for easy setup in any scenario. See the following pages for specific instructions. Shelf Wall Structured Wiring Can (use included rubber feet)
  • Page 8 210 Series Compact Network Switches Quick Start Guide Structured Wiring Can Installation M3 x 4mm screw NOTE: The switch can only be mounted to the structured wiring can with the Ethernet ports facing right or left.
  • Page 9 210 Series Compact Network Switches Quick Start Guide Mounting Shelf Installation (Due to its width, this model should span two mounting shelves. We do not recommend using only one.) ©2021, Wirepath Home Systems, LLC. All rights reserved.
  • Page 10 210 Series Compact Network Switches Quick Start Guide Step 3: Connect Router IP Camera Switch 1 Gbps Link/Act RESET 1 Gbps 100–240V AC 9 SFP Link/Act 10 SFP Switch Wall Outlet Computer NOTE: Connect SFP ports using Araknis SFP adapters for RJ45 or multi-mode fiber cables. SFP adapters sold separately.

  • Page 11: Step 4: Poe Budget

    210 Series Compact Network Switches Quick Start Guide Step 4: PoE Budget The power budget for delivering Power over Ethernet limits the total number of watts available between all of the ports (limited to 30W total consumption on each port). Add the total number of watts consumed by all connected PoE devices to ensure that every thing can be powered, as illustrated in the example below.
  • Page 12 210 Series Compact Network Switches Quick Start Guide Step 5: Verify 1. Power LED – On: system is up. Off: system is down. 2. 1Gbps LED – On: port connected at 1Gbps speed. (RJ-45 LEDs only) Off: port is connected at 10/100Mbps speed.
  • Page 13 210 Series Compact Network Switches Quick Start Guide Step 6: Claim on OvrC OvrC provides remote firmware upgrades, real-time notifications, and intuitive customer management, right from your computer or mobile device. Setup is plug-and-play, with no port forwarding or DDNS address required. To add this device to your OvrC account: Connect the switch to the network (Internet access required).
  • Page 14 210 Series Compact Network Switches Quick Start Guide Pro Tip: Rebooting the Switch Reboot – Press and hold the RESET button on the back of the switch for 5 seconds, then release. The switch will power cycle and the front status lights will flash.

  • Page 16: Contact Information

    2-Year Limited Warranty and Regulatory Information Find details of this product's 2-Year Limited Warranty at snapav.com/warranty, or request a paper copy from Customer Service at (866) 424-4489. Find other legal resources, such as regulatory notices and patent information, at snapav.com/legal. Contact Information araknisnetworks.com Technical Support (866) 838-5052...
