  • Page 1 CROP TIGER 40 WHEEL Operator's Manual...
  • Page 2 787-001 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...

  • Page 3: Table Of Contents

    7.9 Crop feeding ........................... 7.10 Feeder unit ............................7.11 Threshing mechanism ........................7.12 Cleaning system..........................7.13 Grain delivery ..........................7.14 Loading the front attachment......................Faults and remedies 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...
  • Page 4 9.11 Grain delivery..........................9.12 Various components / Machine body ..................9.13 Lubrication chart ........................... 10 Placing out of operation and disposal 10.1 General Information........................00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...

  • Page 5: To This Operator's Manual

    Subheadings will draw your attention to any differences. Text types can be easily distinguished from each other by corresponding formatting. The following format types are distinguished: 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...
  • Page 6 Both terms designate possible variants. Components fitted as series components and equipment variants may vary in different countries. Your CLAAS service department 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...
  • Page 7 Apply lubricating oil to lubrication points. 152774-001 1.1.4 Technical data Technical specifications, dimensions and weights are non-binding. Changes reflecting the technical development and errors reserved. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...

  • Page 8: Safety

    CLAAS product. Please read, in particular, the sections “Safety rules”, “Before putting into initial operation” and “Before every operation” in the machine operator's manual. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...
  • Page 9 The relevant accident prevention regulations, all other generally recognised regulations on safety and occupational medicine and the road traffic regulations must be observed by users and owners at all times. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...
  • Page 10 • Before driving off and starting work, adjust the mirrors so that they enable full view of the road and of the working area behind the machine! 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013 Find manuals at http://best-manuals.com/search?&s=CLA-2951060...
  • Page 11 13-001 CAUTION! Nature and source of danger Consequences: material damage – Countermeasures 16-001 Note! Nature and source of information Consequences: enhanced machine economy or easy assembly – Measures 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 12 The granting of the exceptional approval and the exceptional permit follows different rules in the various countries. Information can usually be obtained from the road traffic departments in charge. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 13 Registration plate fitted on the machine varies in different countries as per their Traffic Rules.As a self- propelled machine with an allowed top speed of up to 20 km/h. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 14 • When travelling downhill with a slope of more than 7%, always shift one gear down (braking effect of diesel engine)! • Never exceed the permitted ground speed when travelling downhill. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 15 – Stop the diesel engine during operational waiting times. – Check fuel consumption at regular intervals. – Carry out the specified maintenance work at regular intervals. 152791-001 2.1.17 Anti-freeze Anti-freeze is highly flammable! 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 16 – Ensure that the flow of oil is not diverted towards the body. – Replace damaged hoses. – Replace hoses at the latest 6 years after the date of manufacture. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 17 • Before mounting the grain tank, please ensure that other persons cannot restart the machine. • Only climb into the grain tank through the opening intended for this purpose. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 18 • Repair work on the hydraulic system may only be carried out by specialist workshops. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 19 – Thoroughly clean with plenty of water and soap and remove polluted and soaked clothing immediately, consult a doctor if skin is irritated (e.g. redness etc.). Swallowing: – Do not induce vomiting; consult a doctor immediately. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 20: Safety Decals On The Machine

    – When parts that have hazard warning signs / safety decals are replaced, always make sure to attach the relevant new hazard warning signs / safety decals to each new part. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 21: Front Attachment

    70-001 Keep a sufficient safety distance from the front attachment. Before starting maintenance work or removing plugs, disengage the drive, stop the engine and remove the ignition key. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 22: Engine

    152800-001 2.2.3 Engine 120948-001 00 0516 034 0 (17) 170193-001 292-001 During operation, do not open or remove safety devices. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 23: Chassis

    170810-001 152226-001 2.2.5 Operator's platform 120971-001 00 0516 041 0 (24) 170198-001 314-001 Never reach or climb into the grain tank while the engine is running. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 24 170199-001 precautions before putting the unit into operation and follow these instructions. 120999-001 00 0516 044 0 (34) 170200-001 340-001 Riding on treads or platforms is not permitted. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 25: Feeder Unit

    152234-001 2.2.6 Feeder Unit 120934-001 00 0516 030 0 (13) 170208-001 278-001 Persons are allowed in the hazard area only if the lift cylinder safeguard is applied. 170201-001 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 26: Threshing Mechanism

    During operation, do not open or remove safety devices. 152296-001 2.2.7 Threshing mechanism 146013-001 00 0514 923 1(15) 158283-001 During operation, do not open or remove safety 170202-001 devices. 170203-001 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...

  • Page 27: Grain Delivery

    170204-001 running - maintain a safe distance. 152298-001 2.2.9 Grain Delivery 120943-001 00 0516 033 0 (16) 170205-001 288-001 Never move your hands into the rotating auger. 170206-001 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 28 2 Safety 2.2 Safety decals on the machine 787-001 146013-001 00 0514 923 1(15) 158283-001 During operation, do not open or remove safety 170207-001 devices. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 29 – Swing safety lock (1) up and fix it to lock (2). 172261-001 152856-001 2.3.3 Securing the machine against rolling away The wheel chocks are not included in the scope of delivery of the machine. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
  • Page 30 Power supply is OFF. Power supply is ON. 170879-001 153534-001 2.3.5 Attaching finger bar safety bar For transporting the front attachment, the safety bar must be placed on the finger bar. 00 0295 106 0 - BA CROP TIGER 40 WHEEL - 01/2013...
