O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. Tomake assembly of your basketball system easier, use the Hardware Identifier on page 3
and 4 to identify and sort all fasteners. Check all cartons for kits. All hardware is not
located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting
holes may not align and parts may not easily fit together. Leave locknuts slightly loose until you are
instructed to tighten them.
5.
An electric screwdriver is helpful in assembly. However, please set at low torque and use caution
because you could overtighten the hardware and strip the screws.
6.
Save this instruction in the event that the manufacturer has to be contacted for replacement
parts.
Please Do Not Return This Product To The Store!
Contact Escalade Sports customer service department at:
Phone:
1-888-USA-GOAL
Fax:
1-866-873-3536
E-mail:
basketball@escaladesports.com
Mailing Address:
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE® SPORTS PRODUCT INFORMATION
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
®
Toll
Free !
Toll
Free !
www.G oalrilla.com
TECHNICAL ASSISTANCE
FREQUENTL Y ASKED QUESTIONS
MODEL NO.
B3303F
B3303W
CV54
BASKETBALL SYSTEM
2L-7218-01
2011 Escalade Sports
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ESCALADE GOALRILLA CV54
Summary of Contents for ESCALADE GOALRILLA CV54
- Page 1 FREQUENTL Y ASKED QUESTIONS ADDITIONAL ESCALADE® SPORTS PRODUCT INFORMATION 2L-7218-01 Escalade® Sports products may be manufactured and/or licensed under the following patents. 6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128 2011 Escalade Sports Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
- Page 2 4L-8090-01...
-
Page 3: Hardware Identifier
HARDWARE IDENTIFIER 1/2” X 1-1/4” Dia. Plastic-Washer (4 Pieces) / 1 2” -13 x 1” / 1 2” Flat Washer Hex Bolt (2 Pieces) (2 Pieces) Pull Pin (1 Piece) 1/2” Split Lock Washer (2 Pieces) Hardware located in 4A-7081-00 box / 1 2”... - Page 4 HARDWARE IDENTIFIER 3/8” X 19mm Flat Washer (4 pieces) Hardware required for rim assembly 1/2”-13 X 1 3/4 Hex Bolt (2 Pieces) 3/8” Flat Washer 1/2”-13 x 10” (8 Pieces) Hex Bolt (3 Pieces) 3/8”-16 X 1-1/4” Hex Bolt 1/2” X 1-1/4”...
- Page 5 INSTALLATION TIMELINE Prior to anchor system and goal assembly, call utility services for location of underground utility lines before you dig. Vertical main post assembly is a two part process. PART 1 PART 2 Day 1. Complete Anchor System Installation Instructions. Day 5.
- Page 6 GOALRILLA ASSEMBL Y INSTRUCTIONS (Day 5) TOOLS REQUIRED FOR THE FOLLOWING STEPS 1 - 15/16" open end wrench 1 - Level 1 - 15/16” socket and ratchet (optional) 1 - Tape Measure 1 - 9/16” Deep Well Socket & Ratchet 1 - Rubber Mallet 1 - 3/4”...
- Page 7 NOTE: It is important for the installer to understand the NOTE: All board arms are made of rectangular tubing. necessity of the Plastic washers (#5) provided. These Tightening hardware too tight may damage tubing and washers adequately space painted parts at all pivot points. make adjustment of system difficult.
- Page 8 Attach Upper Arms (#6) to Pole (#2), as shown in Figure 7, using a bolt (#7), two flatwashers (#3), four plastic washers (#5) and hex nut (#4). Note: Tighten bolts snug but, do not over tighten. Board Arms must pivot freely. If the two T ube Plugs (#9) are not already installed insert them into open ends of Upper Arm (#6).
- Page 9 Note: If the Step Bushing (#22) and Board Bushing (#33) are not already pre-installed follow step 14 and 15. Insert a Two Way Step Bushing (#22) in to the inside of bracket on each side of the Backboard (#23) as shown in Detail A.
- Page 10 INSTALL RIM EXACTLY AS SHOWN. FAILURE TO DO SO COULD DAMAGE GLASS. 18. Mount Goal Assembly (#28) and Rim Pad (#27) to Backboard, as shown in Figure 12, using four bolts (#29), washer (#26) and four nuts (#24). Tighten Fasteners finger tight, leave loose enough to level rim.
- Page 11 Two adults are recommended for this step, one to level and one to adjust the bottom #35 nuts. If further leveling is required loosen top #35 nuts but do not loosen past the top of #39 “J” Bolt. DO NOT REMOVE NUTS #35 Place a level on pole and adjust bottom nuts #35 with a 15/16”...
-
Page 12: Care Information
NEVER USE RIM WITH COVERPLATE REMOVED! 26. Adjust unit to 7-1/2 feet. Use a tape measure to measure from the top of the rim to the playing surface. Stick Height Decal (#17) to back of actuator (#16) with the "7.5" mark aligned with bottom of Actuator Sleeve (#15). -
Page 13: Limited Lifetime Warranty
® Subject to proper installation and normal Residential use, Escalade Sports warrants, subject to the limitations below, to the original retail purchaser all structural components of the Goalrilla™ System to be free of defects in material and workmanship for the duration of ownership by the original retail purchaser. - Page 14 B3303 PARTS LIST Key# Part # Description Qty . 3M-8926-00 Pole Pad -Universal 1A-7031-00 Post Assembly 2B-6093-02 1/2” Flat Washer 2B-6242-01 1/2-13 Nylon Locknut 3M-6245-00 1/2” X 1-1/4” Plastic Washer 1A-7652-00 Upper Board Arm 1B-6787-02 1/2-13 X 9 " Hex Bolt-Grade 5 1B-6222-02 1/2-13 X 10"...
- Page 15 Left Right 2L-7218-01...
