- Page 1 DIGITAL WIRELESS TV HEADSET SOUNDS (Product can support 2 Headsets) English...
-
Page 2: Table Of Contents
Contents !!!Please ensure you read the user manual thoroughly before use!!! !!!Please refer to our website: www.geemarc.com for an up to date user guide, as there may be important updates and changes you need to be aware of !!! INTRODUCTION ............3 SAFETY &... - Page 3 Contents TROUBLESHOOTING ........18 ● No Sound ..............18 ● Distortion ..............18 Cleaning & Maintenance ..........19 Spare/replacement parts ........... 19 Customer support ............19 GUARANTEE .............. 20 UKCA DECLARATION ..........20 BATTERY WARNINGS ........20 DISPOSAL INFORMATION ........21 FEATURES ..............
-
Page 4: Introduction
The Geemarc Digital Wireless Audio Listener is an audio amplification system specifically designed for people with hearing difficulties. The Geemarc Audio Listener can be used with all kinds of audio systems for interference-free listening enjoyment – TV set, Smartphone, DVD player, CD player, Hi-Fi system, iPod or other. - Page 5 Introduction Up to 6 hours of rechargeable battery life per full charge – ● never lose the soundtrack in mid-program; Only 3 hours to fully recharge the Headset simply by ● replacing the Headset in its Charging Cradle. Auto Power OFF Headset simply by replacing the Headset ●...
-
Page 6: Safety & Care Advice
Electrical connection: The unit is designed to operate from a 100-240VAC - 50/60Hz supply. (Classified as 'hazardous voltage' according to EN 62368-1 standard). Caution: Batteries should only be replaced by Geemarc or authorised Vendor. Please refer to the chapter: <Spare / replacement parts> for more information. -
Page 7: Pack Components
PACK COMPONENTS PACK COMPONENTS (A1) Headset Receiver (A2) Charging Cradles and Transmitter (A3) Power Supply (A4) Audio Cable (both ends with 3.5 mm stereo plug) (A5) Toslink Cable for Optical Digital Audio Connection (Optical version only). IMPORTANT: Before using the cable remove the clear plastic protective covers from both ends. -
Page 8: Function Identification
FUNCTION IDENTIFICATION FUNCTION IDENTIFICATION Function Identification: Headset Receiver FRONT REAR (B1) Earbuds (B2) Spare ear tips. There are 2 styles of ear tip. (B3) Volume Increase Control, Balance Control (B4) Volume Decrease Control, Balance Control (B5) Power/Signal/Charging/Local Microphone LED Indicators: Battery Charge (Red = charging, Green = fully charged) LED Indicator (Orange): Local Microphone Amplification for Verbal Communications. - Page 9 FUNCTION IDENTIFICATION LED Indicator (Blue Slow flashing): Not Paired with Transmitter, or Transmitter is powered off. LED Indicator (Blue Fast flashing): in Pairing Mode. Orange LED: Blue LED: Local Microphone Working / Pair status Amplification Green LED: Red LED: Fully charged Charging (B6) Power Button and Mute Button for Verbal Communications...
-
Page 10: Function Identification: Charging Cradle
FUNCTION IDENTIFICATION Function Identification: Base Charging Cradles(Transmitter) FRONT REAR (C1) Charging Pins (C2) Pair LED Indicator : Blue Lights up - Paired Headsets found; Blue Slow flashing - Not paired devices found; Blue Fast flashing - Not paired devices found or No sound input for more than 10 minutes. -
Page 11: Installation
INSTALLATION INSTALLATION Transmitter Optical jack 3.5mm headphone socket 6.3mm headphone socket (Analog version only) RCA socket SCART socket (D1) Connect the Power Supply to yellow Socket (5V/1A) located on the Charge Cradle rear panel. (D2) Connect the Power Supply to an electricity socket (100- 240V ~ 50/60Hz). -
Page 12: Headset
INSTALLATION • RCA Adapter Cable (Option and Analog version only); • 3.5 mm to 6.3 mm Adapter Plug (Option and Analog version only); • SCART Adapter (Option and Analog version only); or CL7370 Digital version, you can also ： (D5) Connect one end of the to Digital Audio Toslink Cable Input in the rear panel of the Charge Cradle. -
Page 13: Operation
OPERATION OPERATION Initial Operation 1. Make sure the CL7370 is plugged into the main. 2. Switch ON the CL7370 – at the back of the Charging Cradle (see figure (1) at right). 3. Place the Headset in the Charging Cradle for at least three hours to allow it to fully charge. - Page 14 OPERATION 3. Adjust the Volume to the desired sound level (see figure (4) at right), Press '+' button to increase volume and '-'button to decrease volume. Headset beeps when volume reaches maximum or minimum. then fit the Earbuds in your ears. NOTE: Make sure the volume on your Audio Source (TV set or other audio device) is turned up to at least half of its full volume to get good sound quality in your Earbuds.
-
Page 15: Controlling The Tone (Bass & Treble)
OPERATION Controlling the Tone (Bass & Treble) You can adjust the tone of the audio you are listening and to enhance your listening pleasure by amplifying either the Treble or the Bass in the Headset Receiver. Press the Tone Button on the rear of headset to switch cyclically between: 1. -
Page 16: Conversation
OPERATION Using the MIC Button for Conversation You can switch from Listening mode to Conversation mode without having to take off the Headset. To talk or listen someone: 1. Short Press the MIC button (see figure (7) at right). This will shut off the Audio Source and the Headset will become an amplifier by activating the Microphone. -
Page 17: Pairing Extra Headsets
OPERATION WARNING: The battery must not be exposed to excessive heat such as sunshine, fire etc. Do not attempt to replace the original rechargeable battery. The battery must always be fully charged before first use. An initial 3 hours charge is required to guarantee an acceptable service life for the rechargeable battery. - Page 18 OPERATION blue LED in the headset front is in fast flashing, then release the buttons. .Switch ON the base and the blue LED start fast flashing, When the blue LED stop flashing and lights up, the pairing is complete automatically. Note: 1.
-
Page 19: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING No Sound Ensure the power supply is properly plugged into the electricity ● socket and that its cable is properly connected to yellow connector 5V/1A on the Charge Cradle. Ensure that the Headset is switched ON (fix Blue Led). ●... -
Page 20: Cleaning & Maintenance
Customer Helpline Telephone: 01707 387602 1. Additional Headsets 2. Ear pads To replace the Headset battery, please contact Customer Support. Customer support For product support and help, visit our website at www.geemarc.com E-mail : help@geemarc.com For our Customer Helpline Telephone: 01707 387602... -
Page 21: Guarantee
GUARANTEE From the moment your Geemarc CL7370 product is purchased, Geemarc guarantee it for the period of two years. During this time, all repairs or replacements (at our discretion) are free of charge. Should you experience a problem then contact our Helpline or visit our website at www.geemarc.com. -
Page 22: Disposal Information
DISPOSAL INFORMATION . FEATURES DISPOSAL INFORMATION Disposal of old electrical & electronic equipment (applicable in the European Union and other European countries with separate collection systems) The symbol on the product or its packaging indicates that this product may not be treated as household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 23: Technical Specifications
For product support and help visit our website at www.geemarc.com Parc de l’Etoile, 2 Rue Galilée, 59791 Grande-Synthe, France E-mail : help@geemarc.com Telephone : 01707 387602 lines are open 09h00 to 16h00 Mon to Fri This product is made in China To Geemarc Telecom © 02 August, 2021... - Page 24 UGCL7370_En_v1.0...
