O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. To make assembly of your basketball system easier , use the Hardware Identifier on page 3
to identify and sort all fasteners. Check all cartons for kits. All hardware is not located
in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together . Leave locknuts slightly loose until you are instructed to
tighten them.
5. An electric screwdriver is helpful in assembly. However, please set at low torque and use caution
because you could overtighten the hardware and strip the screws.
6. Save this instruction and your proof of purchase (receipt) in the event that the manufacturer
has to be contacted for replacement parts.
Please Do Not Return This Product T o The Store!
Contact Escalade
Phone:
1-888-USA-GOAL
Fax:
1-866-873-3536
E-mail:
basketball@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE
Escalade
®
Sports products may be manufactured and/or licensed under the following patents:
6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128, 7244046
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
®
Sports customer service department at:
®
SPORTS PRODUCT INFORMATION
Toll – Free!
Toll – Free!
www.escaladesports.com
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
MODEL NO.
B5400W
B5400F
SB54iG
BASKETBALL SYSTEM
ITEMS NEEDED (not included)
50 lbs bags of concrete
9-
Post hole digger (optional)
1-
Wheel barrow
1-
Garden hose
1-
1-
Level
1-
Tape Measure
6-
2X4's
2-
50 lbs sand bags
Standard masonry block
1-
9/16", 3/4" & adjustable wrench
1-
Cordless drill & 9/64" drill bit
1-
5/16" socket driver (for cordless drill)
1-
1-
Pair of Safety Glasses
1-
Phillips Screwdriver
1-
Ladder
©
2011 Escalade Sports
2L-7196-01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ESCALADE SILVERBACK SB54iG
Summary of Contents for ESCALADE SILVERBACK SB54iG
- Page 1 Sports products may be manufactured and/or licensed under the following patents: 6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128, 7244046 Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product. © 2011 Escalade Sports...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Owner must ensure that all players know and follow these rules for safe operation of the system. WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. - Page 3 3/8 -16 3/8 - 16 X 1 3/4 Hex Bolt (4 Pieces) (2 Pieces) #10 X 1 (6 Pieces)
- Page 4 INSTALLATION TIMELINE 1. Prior to pole installation and goal assembly, call utility services for location of underground utility lines before you dig. 2. Vertical main post assembly is a two part process. PART 1 PART 2 Day 1. Post assembly, pour concrete, set post and Day 3.
- Page 5 POST ASSEMBLY INSTRUCTIONS IMPORTANT THE FOLLOWING STEPS WILL REQUIRE AT LEAST THREE CAPABLE ADULTS. Figure 3 Before putting any of the poles tubes together, mark bottom pole (#2) 6 inches from the top end. Be sure to match up both “Back Side” stickers on the back of the poles and that the holes on top Be sure to match pole are toward the back.
- Page 6 Note: Periodically check pole with level to ensure that pole is vertical. 9. Stabilize the pole by using six 2X4’s and placing two 50 lbs. bags of sand on top to keep pole from shifting, periodically check the pole with level to ensure that pole is vertical. See Figure 5.
- Page 7 ASSEMBLY INSTRUCTIONS (Day 3) IMPORTANT! BE SURE CONCRETE HAS BEEN ALLOWED TO CURE FOR AT LEAST 2 DAYS. Figure 6 11. Attach Post Ears (#30) to holes near the bottom of Top Post (#3) using two hex bolts (#25) four washers (#18) and two lock nuts (#4).
- Page 8 IMPORTANT! Nylon washers (#5) adequately space painted parts at all pivot points. Neglecting the use of these washers will result in rusted parts. NOTE: All board arms are made of rectangular tubing. Tightening hardware too tight may damage tubing and make adjustment of system difficult. 16.
- Page 9 19. Attach of Upper Arms (#6) to Top Pole (#3), as shown Figure 10, using a bolt (#7), two flat washers (#18), two spacers (#8) and one lock nut (#4). Note: Tighten bolts snug but, do not over tighten. Board Arms must pivot freely.
- Page 10 Figure 12 ATTACHING BA CKBOARD T O BO ARD ARMS REQUIRES A T LEAST THREE CAPABLE ADULTS. 23. With at least two capable people, raise the backboard assembly up and have the third attach Lower Board Arms to lower mounting tubes on backboard using two bolts (#24), two plastic washers (#5), four washers (#18) and two lock nuts (#4).
- Page 11 Remove protective backboard covering and mount Goal Assembly (#28) and Rim Pad (#27) to Backboard, as shown in Figure 13, using four bolts (#41), four washers (#26), and four locknuts (#4). Tighten fasteners, but leave them loose enough to level rim. 26.
- Page 12 32. Adjust unit to 7-1/2 feet. Use a tape measure to measure from the top of the rim to the playing surface. Stick Height Decal (#17) to back of Actuator (#16) with the "7.5" mark aligned with bottom of Actuator Sleeve (#15). See Figure 14. Figure 14 Figure 15 33.
- Page 13 OR OTHER CAUSES NOT ARISING OUT OF DEFECTS IN MATERIAL OR WORKMANSHIP . ® Subject to proper installation and normal Residential use, Escalade Sports warrants, subject to the limitations below, to the original retail ® purchaser all structural components of the Silverback System to be free of defects in material and workmanship for a period of Seven (7) years from the original purchase.
-
Page 14: Maintenance
SILVERBACK CARE INFORMATION - BACKBOARD - Items needed to clean backboard: 100% cotton soft cloth, (only) Glass Cleaner Clean backboard using a 100% Cotton soft cloth and glass cleaner. Clean glass as you would household windows. Strong cleansers will damage backboard and void warranty. - Page 15 (Pre-Installed) (Pre-Installed) 2L-7196-01...
