Manual RHGSE Operation and Maintenance Manual ZOM-11000-2 v2 rev E
6.17) Installing a new wire rope with the cable reel extension
The RHGSE has the ability to attach the wire rope shipping reel in order to facilitate installation of a
new wire rope.
Attach the ZGS-10454-1 Cable Reel Extension with its pin as shown.
Slide the shipping reel on the extension and attach the wire rope following the OEMs instructions. The
adapter can be used with both major OEM's cable shipping reels.
Goodrich Cable Reel
Breeze Cable Reel
Once the wire rope is completely on the rescue hoist, remove the cable reel and cable reel
extension and run the wire rope on and off the hoist onto the RHGSE three or four times
while increasing the load incrementally on each cycle in order to condition the wire rope.
