Sync Ergonomics PROJECT 0.2 EVO Setup Manual

Hide thumbs Also See for PROJECT 0.2 EVO:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PROJECT 0.2 EVO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sync Ergonomics PROJECT 0.2 EVO

Summary of Contents for Sync Ergonomics PROJECT 0.2 EVO

  • Page 2 Ergonomics components. WARNING: In order to be installed correctly the components of Project 0.2 EVO require specialised knowledge of a time trial bicycle. It is recommended that installation should be performed by a qualified bicycle mechanic. Improper assembly of any of the components of EVO could cause damage to the product(s) and/or bicycle, may lead to loss of control of the bicycle, and may lead to personal injury, or in severe cases even death.
  • Page 3 WARNING: Do not attempt to modify your Sync components, outside of what is described within this setup guide as appropriate for assembly. Modification may impact the structural integrity of the components and could result in component failure, or failure of the complete system. Sync Ergonomics is not liable...
  • Page 4 NOTE: Systems differ to what is seen here, according to the differences in basebar adapters.
  • Page 5 The purpose of the basebar adapter is to provide a consistent interface for the EVO top plate. The EVO top plate provides a consistent 125 mm extension clamp spacing. Basebar adapters are bike/handlebar specific and it should not be attempted to mount these components on any other handlebar than specified.
  • Page 6 The V2 EVO basebar adapter is installed directly on top of the center stack spacer assembly, allowing utilization of the original spacer stack for height adjustment. NOTE: Connect the basebar adapter using the original mounting hardware and assemble as per the original assembly instructions. NOTE: See the bike specific supplements for further details.
  • Page 7 The EVO clamp adapters sit between the top plate and the extension clamps. This component allows for changing the angle of the extension clamp, through the use of the angled clamp adapter (see setup supplement).
  • Page 8 The EVO extension clamps bolt down to the top plate using the supplied M5 x 22 mm bolts. We recommend the application of MOTOREX Bike Grease for the clamp bolts. Ensure you use the supplied M5 flat form washers. Once pieced together, torque the EVO extension clamp bolts to 6 Nm. 6 Nm...
  • Page 9 WARNING: Low Rise 3D extensions are designed to work with Shimano SW-R9160 and SRAM eTap CLICS only. Any modification for other shifters voids the product warranty. Sync Ergonomics is not liable for product damage and/or personal injury resulting from product modification.
  • Page 10 2.5 Nm When cut to the correct length and height, secure the extensions in the EVO extension clamps with the two grub screws provided (pre-inserted into the clamps). We recommend the application of a light textured carbon paste between the extension and the inside of the clamp to ensure a secure fit.
  • Page 11 Thanks to the connection at the shifter, you can run the Di2 wires through the spacer stack during assembly, leaving sufficient length to connect the shifters as a final step. The wires will run through the basebar adapter/s, through the spacers, clamp adapter and carbon brace, into the clamp and up and out of the extensions.
  • Page 12 Sync Ergonomics online store and can be purchased separately when worn out. WARNING: Over torquing the cup connection screws will lead to permanent damage of the arm cup base plate. Sync Ergonomics is not liable for product damage and/or personal injury resulting from inappropriate product setup.
