Sync Ergonomics Project 0.2 EVO Setup Manual

Hide thumbs Also See for Project 0.2 EVO:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Project 0.2 EVO and is the answer not in the manual?

Questions and answers

Related Manuals for Sync Ergonomics Project 0.2 EVO

Summary of Contents for Sync Ergonomics Project 0.2 EVO

  • Page 2 Ergonomics components. WARNING: In order to be installed correctly the components of Project 0.2 EVO require specialised knowledge of a time trial bicycle. It is recommended that installation should be performed by a qualified bicycle mechanic. Improper assembly of any of the components of EVO could cause damage to the product(s) and/or bicycle, may lead to loss of control of the bicycle, and may lead to personal injury, or in severe cases even death.
  • Page 3 WARNING: Do not attempt to modify your Sync components, outside of what is described within this setup guide as appropriate for assembly. Modification may impact the structural integrity of a components and could result in component failure, or failure of the complete system. Sync Ergonomics is not liable...
  • Page 4 SYN-EVO-CA-M5-32.5-SV EVO Shiv Tri Disc Clamp Adapter SYN-EVO-BR-M5-SV-132 EVO Shiv Carbon Plate SYN-EVO-CL-M5-32.5-15 EVO M5 x 32.5 Threaded Clamp SYN-EVO-TC-M3-00 EVO Clamp Top Cap SYN-EVO-EX-3XX-25-RX Low Rise 3D Extension (R) SYN-EVO-EX-3XX-25-LX Low Rise 3D Extension (L) SYN-EVO-CP-15-14-CB V2 Deep Groove Arm Cup SYN-EVO-PD EVA Foam Pad M5 x 20mm Torx Countersunk Screws...
  • Page 5 EVO Is designed to function with the original base bar and spacers provided with your Shiv Tri Disc. Your Shiv is supplied with a variety of spacers to allow you achieve the perfect fit when combined with the EVO ecosystem. As the EVO Clamp Adapter, Carbon Plate and EVO Extension Clamps are the equivalent of a single 40 mm spacer, this will need to be removed from your central column, in order to achieve the same pad stack setting.
  • Page 6 You have been provided with a Shiv-specific EVO Clamp Adapter. This is designed to replace the OEM upper assembly on your Shiv Tri Disc. Please note, with no stack spacers used, the minimum stud length is 30 mm (Clamp Adapter only). Place the EVO Clamp Adapter on top of your OEM Shiv base bar, and any additional spacers you may require.
  • Page 7 The 10 mm EVO Carbon Plate provides a stable base for the mounting of the EVO Extension Clamps. Ensure that you run your electronic wiring through the grooves in the Clamp Adapter assembly prior to clamping of the EVO Carbon Plate. The assembly requires 4 x 20 mm countersunk screws in the center of the plate and 4 x 14 mm countersunk screws for additional support.
  • Page 8 You have been provided with a set of Specialized Shiv Tri Disc EVO Extension Clamps. Do not attempt to install the Specialized-specific EVO Clamp on a bike other than a Specialized Shiv Tri Disc. We recommend the application of MOTOREX Bike Grease for the clamp bolts.
  • Page 9 WARNING: DO NOT DRILL OR MODIFY extensions for cable entry/exit, Low Rise 3D extensions are designed to work with Shimano SW-R9160 and SRAM eTap CLICS only. Any such modification immediately voids the product warranty. Sync Ergonomics is not liable for product damage and/or personal injury resulting...
  • Page 10 When cut to the correct length and height, secure the extensions in the EVO Extension Clamps with the two grub screws provided (pre- inserted into the clamps). We recommend the application of a light textured assembly paste (carbon paste) between the extension and the inside of the clamp to ensure a secure fit.
  • Page 11 Ensure that you run your electronic wires through the central column of components prior to final fixation with the EVO Extension Clamp. Thanks to the connection at the shifter, you can run the Di2 wires through the ecosystem during assembly, leaving sufficient length to connect the shifters as a final step.
  • Page 12 Sync Ergonomics online store and can be purchased separately when worn out. WARNING: Over torqueing the cup connection screws will lead to permanent damage of the arm cup base plate. Sync Ergonomics is not liable for product...
