Summary of Contents for Sync Ergonomics Project 0.2 Evo

  • Page 2 Improper assembly of any of the components of EVO could cause damage to the product(s) and/or bicycle, may lead to loss of control of the bicycle, and may lead to personal injury, or in severe cases ev en death. Sync Ergonomics assumes no responsibility for improper assembly and installation of the product(s).
  • Page 3 WARNING: Do not attempt to modify your Sync components, outside of what is described within this setup guide as appropriate for assembly. Modification may impact the structural integrity of a components and could result in component failure, or failure of the complete system. Sync Ergonomics is not liable...
  • Page 4 SYN-EVO-CL-M5-SL-15 EVO Slotted Clamp EVO 2018 Speedmax Clamp SYN-EVO-CA-M5-27 Adapter SYN-EVO-BR-M5-27-140 EVO 2018 Speedmax Brace SYN-EVO-TC-M3-00 EVO Clamp Top Cap SYN-EVO-EX-3XX-25-RX Low Rise Extension (R) SYN-EVO-EX-3XX-25-LX Low Rise Extension (L) SYN-EVO-CP-15-14-CB Deep Groove Arm Cup SYN-EVO-PD EVA Foam Pad Clamp Grub Screws EVO Clamp Top Cap Screws Arm Cup Screws...
  • Page 5 EVO Is designed to function with the original base bar and spacers provided with your 2018 Canyon Speedmax CF SLX TT. Your Canyon Speedmax is supplied with a variety of spacers to allow you achieve the perfect fit when combined with the EVO ecosystem. As the EVO clamps sit high on the assembly, you may find you need to reduce the height of your spacer stack to achieve optimal fit.
  • Page 6 You have been provided with a Canyon-specific Clamp Adapter assembly. This is designed to replace the OEM clamp assembly on your 2018 Speedmax. Place the EVO Clamp Adapter on top of your OEM Canyon spacers, ensuring that the pieces key fit together correctly.
  • Page 7 WARNING: DO NOT DRILL OR MODIFY extensions for cable entry/exit, Low Rise 3D extensions are designed to work with Shimano SW-R9160 and SRAM eTap CLICS only. Any such modification immediately voids the product warranty. Sync Ergonomics is not liable for product damage and/or personal injury resulting...
  • Page 8 When cut to the correct length and height, secure the extensions in the extension clamps with the two grub screws provided (pre-inserted into the clamps). We recommend the application of a light textured carbon paste between the extension and the inside of the clamp to ensure a secure fit.
  • Page 9 Ensure that you run your electronic wires out the back of the clamp and down your spacer stack without pinching. Thanks to the connection at the shifter, you can run the Di2 wires up the back of the spacer stack and into the clamp during assembly, leaving sufficient length to connect the shifters as a final step.
  • Page 10 Sync Ergonomics online store and can be purchased separately when worn out. WARNING: Over torqueing the cup connection screws will lead to permanent damage of the arm cup base plate. Sync Ergonomics is not liable for product...
  • Page 11 For riders seeking a UCI-compliant position, Low Rise 3D Extensions can be trimmed to achieve the desired length and height. Low Rise 3D extensions are designed to be capable of providing 100 mm of height gain, measured from the centre of the arm cup pad, to the top edge of the shifter body.
  • Page 12 Saddle offset 0-50 mm behind the bottom bracket Saddle offset 50 mm (or more) behind the bottom bracket Athlete height of 190 cm or taller, with a saddle offset of 50 mm (or more) behind the bottom bracket The clamp end of the extension must be trimmed in order to achieve UCI compliance for length.
