Acnodes RP30173 User Manual

1u military rackmount monitor drawer 17.3" 1920 x 1080 full hd lcd monitor mil-std-810g military testing compliance

RP30173

User Manual

For latest product information, please visit Acnodes' website at www.acnodes.com.

14628 Central Ave. Chino, CA 91710

1U Military Rackmount Monitor Drawer

17.3" 1920 x 1080 Full HD LCD Monitor

MIL-STD-810G Military Testing Compliance

Tel: 909.597.7588

Fax: 909.597.1939

Table of Contents

Need help?

Do you have a question about the RP30173 and is the answer not in the manual?

Page 1 MIL-STD-810G Military Testing Compliance User Manual All rights reserved. Product description and product specifications are subject to change without notice. For latest product information, please visit Acnodes’ website at www.acnodes.com. 14628 Central Ave. Chino, CA 91710 Tel: 909.597.7588 Fax: 909.597.1939...
Page 2 Contents < Part. 1 > OSD Functions Control Button Input Source Selection Key Operation OSD Context < Part. 2 > Dimensions P.4-5 < Part. 3 > PIN Assignment...
Page 3 < Part 1 > OSD Functions < 1.1 > Control Button a. Function: Auto / Exit 1. Input signal Source Menu (See below 2.) 2. Jump out of Main Menu Call up the Menu list (see below 3.) Menu / Select On/ Off Screen On/Off Increase (+)
Page 4 < 1.3 > Key Operation Press “Menu/Select” button to call the main menu as below, Figure 1 Main Menu *Note: All Button Function In Main Menu 1. Under main menu screen, press “Increase” or “Decrease” button to switch between 4 top menu icons. 2.
Page 5 < 1.4 > OSD Context Picture Press Increase / Decrease to adjust the brightness Brightness : Contrast : Press Increase / Decrease to adjust the contrast Color Temp : Press Increase / Decrease to adjust the color temperature, 9300 inclines to blue, 6500 inclines to sunlight color, 5800 inclines to red color Auto-adjustment Auto :...
Page 6 < Part 2 > Dimensions Rear View Front View Top View...
Page 7 Close View...
Page 8 < Part 3 > PIN Assignment PIN Definition J1 Pin Assignment J2 Pin Assignment...
