Every 100 Hours - Takeuchi TB108 Operator's Manual

MAINTENANCE

Every 100 Hours

Cleaning the Fuel Filter
WARNING
¡ ¡ ¡ ¡ ¡ Do not smoke or permit open flames
while handling fuel or working on the
fuel system.
¡ ¡ ¡ ¡ ¡ Stop the engine in a well-ventilated
place and allow it to cool down before
performing maintenance.
¡ ¡ ¡ ¡ ¡ Clean up spilled fuel immediately.
1. Open the engine hood.
2. Close the cock (2).
3. Loosen the ring (3), then remove the case
(4) and element (5) and clean them.
4. Inspect the O-ring, and if there are any
scratches or other irregularities, replace
it.
5. Assemble the case (4) and element (5)
and tighten the ring (3).
6. Open the cock (2) and bleed the air.
Refer to page 129 "Bleeding the Air from
the Fuel System".
Cleaning the Water Separator
¡ ¡ ¡ ¡ ¡ Do not smoke or permit open flames
while handling fuel or working on the
fuel system.
¡ ¡ ¡ ¡ ¡ Stop the engine in a well-ventilated
place and allow it to cool down before
performing maintenance.
¡ ¡ ¡ ¡ ¡ Clean up spilled fuel immediately.
1. Open the engine hood.
2. Close the cock (2).
3. Loosen the ring (3), then remove the case
(4), element (5) and indicator ring (6) and
clean them.
4. Inspect the O-ring, and if there are any
scratches or other irregularities, replace
it.
5. Assemble the indicator ring (6), case (4)
and element (5) and tighten the ring (3).
6. Open the cock (2) and bleed the air.
Refer to page 129 "Bleeding the Air from
the Fuel System".
109
