Frigidaire FRFG1723AV Use & Care Manual

Hide thumbs Also See for FRFG1723AV:
Table of Contents

Advertisement

Quick Links

Introduction .......................................................2
Important Safety information.....................3
Features ..............................................................6
Installation .........................................................7
Door Removal ...................................................9
Door Handle Installation .............................. 11
Water Supply Connection .......................... 12
controls and settings ................................... 14
Frigidaire.com USA 1-800-374-4432
REFRIGERATOR
use
care
&
Ice Maker .......................................................... 17
Storage Features ........................................... 18
Normal Operating Sounds ......................... 21
Filter replacement ........................................ 22
Care and Cleaning ....................................... 24
Troubleshooting .......................................... 26
Limited Warranty ......................................... 29
A21785802 (April 2021)
Frigidaire.ca Canada 1-800-265-8352

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRFG1723AV and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRFG1723AV

Summary of Contents for Frigidaire FRFG1723AV

  • Page 1: Table Of Contents

    Filter replacement ........22 Door Handle Installation ......11 Care and Cleaning ........24 Water Supply Connection ......12 Troubleshooting .......... 26 controls and settings ........14 Limited Warranty ......... 29 A21785802 (April 2021) Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352...

  • Page 2: Introduction

     Installation Checklist Welcome to our Doors Thank you for bringing Frigidaire into ˆ Handles are secure and tight your home! We see your purchase as the beginning of a long relationship together. ˆ Door seals completely to cabinet on...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION WARNING DANGER Please read all instructions before using DANGER Risk of fire or explosion. this appliance. Flammable refrigerant used. Do not use mechanical devices to defrost refrigera- Safety Definitions tor. Do not puncture refrigerant tubing. This is the safety alert symbol. It is DANGER Risk of fire or explosion.
  • Page 4 IMPORTANT SAFETY INFORMATION Safety Instructions WARNING • DO NOT store or use gasoline, or other flammable liquid within or in the These guidelines must be followed to vicinity of this appliance. Read Product ensure that safety mechanisms in this Label for warnings regarding flamma- appliance will operate properly.
  • Page 5 IMPORTANT SAFETY INFORMATION IMPORTANT IMPORTANT CFC/HCFC Disposal To turn off power to your appliance you must unplug the power cord from the Your old appliance may have a cooling electrical outlet. system that used CFCs or HCFCs (chlo- rofluorocarbons or hydrochlorofluoro- Grounding type wall receptacle carbons).

  • Page 6: Features

    Freezer Drawer Adjustable Door Bins Middle Freezer Drawer Flipper Mullion Freezer Basket Water Filter IMPORTANT Accessories are available for your appliance and may be purchased at Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in Canada) or from an authorized seller.

  • Page 7: Installation

    INSTALLATION Tools Necessary: (OR) Phillips Head 8mm Socket Quadrex Head ⅜" Fixed Adjustable Wrench Screwdriver Allen Wrench Wrench Wrench This Use & Care Manual provides general CAUTION installation and operating instructions for this model. We recommend using a ser- vice or kitchen contracting professional to Do Not install the appliance where install the refrigerator.
  • Page 8 INSTALLATION Cabinet Leveling & Door Flipper Mullion Alignment (if necessary) Adjust Flipper Mullion for proper Guidelines for final positioning of appliance: connection with the mullion guide by ensuring the flipper mullion is folded and • All 4 corners of the cabinet must rest perpendicular to the fresh food door.

  • Page 9: Door Removal

    DOOR REMOVAL Getting through narrow spaces CAUTION If refrigerator will not fit through an entrance area, doors can be removed. Be sure doors are set aside in a secure Check first by measuring the entrance. position where they cannot fall and To prepare for removing the doors: cause personal injury, or damage to the doors or handles.
  • Page 10 DOOR REMOVAL Removing Freezer Drawer Reinstalling Freezer Drawer Place drawer with brackets and CAUTION sliders inside the cabinet and click into place. Drawer is heavy. Use caution when lifting. 2. Replace the basket. Open drawer and fully extend.  NOTE 2.

  • Page 11: Door Handle Installation

    DOOR HANDLE INSTALLATION CAUTION Wear gloves and safety goggles. Use extreme CAUTION when installing these handles. Door Handle Mounting Refrigerator Handles Mounting Instructions Remove handles from carton and any other protective packaging. 2. Position fresh food handle end caps over upper and lower pre- installed shoulder bolts (A) that are fastened...

  • Page 12: Water Supply Connection

    ¼ in. plastic. Plastic tubing greatly refrigerator. Depending on local/state increases the potential for water building codes, Frigidaire recommends leaks, and the manufacturer will not you use Smart Choice water line kit ®...
  • Page 13 WATER SUPPLY CONNECTION 4. If using (recommended) stainless Connection to Household Water Supply with 1/4" compression steel braided tubing - the nut and fitting ferrule are already assembled on the Water tubing. Slide compression nut onto inlet water inlet fitting and finger tighten. fitting 5.

  • Page 14: Controls And Settings

    CONTROLS AND SETTINGS Prior to grocery shopping, we recommend you activate Freeze Boost to freeze your food faster It will remain active for up to 24 hours before automatically deactivating or you manually exit. Press Freeze Boost to turn the function off. This will reset the freezer to the previous temperature setting.
  • Page 15 CONTROLS AND SETTINGS Alarms  NOTE High Temperature The recommended settings for a prod- If the temperature uct installed in a kitchen is 37˚F for the increases, the HIGH fresh food compartment and 0˚F for TEMP alarm will sound the freezer. every 10 seconds until you press any key to mute it.
  • Page 16 CONTROLS AND SETTINGS Sabbath Mode The Sabbath Mode is a feature that disables portions of the refrigerator and its controls in accordance with observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community. In the Sabbath Mode, the High Temp alarm is active for health reasons.

  • Page 17: Ice Maker

    ICE MAKER Cleaning the ice maker IMPORTANT Clean the ice maker and ice bin at On occasion, unusually small ice cubes regular intervals, especially prior to may be noticed in the bucket. This could vacation or moving. occur in normal operation of the ice Turn off the ice maker.

  • Page 18: Storage Features

    STORAGE FEATURES CrispSeal Drawer CAUTION The refrigerator includes a crisper designed for storing fruits, vegetables, To avoid personal injury or property and other fresh produce. damage, handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change.
  • Page 19 STORAGE FEATURES Doors Freezer Features Storage bins The doors to the fresh food compartment use a system of modular storage bins. All of these bins are removable for easy cleaning. Adjust bins as needed. Door bins are ideal for storing jars, bottles, cans, and large drink containers.

  • Page 20: Storing Food And Saving Energy

    STORING FOOD AND SAVING ENERGY Ideas for storing foods • Activating Freeze Boost will help the freezer more efficiently maintain the Fresh food storage selected temperature after placing new purchases with pre-existing • Keep the fresh food compartment frozen foods. between 34°F and 44°F with an opti- mum temperature of 37°F.

  • Page 21: Normal Operating Sounds

    NORMAL OPERATING SOUNDS Understanding the sounds Motorized damper May produce a light humming during operation. coming from the refrigerator  High-efficiency refrigerators may NOTE introduce unfamiliar sounds. These sounds normally indicate the refrigerator Energy efficient foam in the refrigerator is operating correctly. Some surfaces on is not a sound insulator.

  • Page 22: Filter Replacement

    Ordering Replacement Water Filters Order replacement filters online at Frigidaire.com, by calling 1-800-374- 4432 (Frigidaire.ca or 1-800-265-8352 in Canada) or through the dealer from which the refrigerator was purchased. Frigidaire recommends replacing filters at least once every 6 months.
  • Page 23 NSF/ (Instructional video of procedure can be ANSI Standards 43, 53 and found on Frigidaire.com.) 401 for the reduction of claims Turn off Ice Maker on the appliance specified on the performance control display.

  • Page 24: Care And Cleaning

    CARE AND CLEANING Care & Cleaning Tips Keeping the refrigerator clean maintains its appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year.  NOTE Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on plastic parts, interior doors, gaskets, or cabinet liners.
  • Page 25 CARE AND CLEANING Vacation and moving tips Occasion Tips Short • Leave the refrigerator operating during vacations of 3 weeks or less. Vacations • Use all perishable items from refrigerator compartment. • Turn the automatic ice maker off and empty the ice bucket, even if only away a few days.

  • Page 26: Troubleshooting

    If you need us, visit our website, chat with an agent, or call us. We may be able to help you avoid a service visit. If you do need service, we can get that started for you! 1-800-265-8352 (Canada) 1-800-374-4432 (United States) Frigidaire.ca Frigidaire.com Concern Potential Cause...
  • Page 27 TROUBLESHOOTING Concern Potential Cause Common Solution Opening/Closing Of Doors/Drawers Door(s) will • Door was closed too • Close both doors gently. not close. hard, causing other door to open slightly. • Refrigerator is not level. • Ensure floor is level and solid, It rocks on the floor and can adequately support the when moved slightly.
  • Page 28 TROUBLESHOOTING Concern Potential Cause Common Solution Water/Moisture/Frost Inside Refrigerator Moisture • Weather is hot and humid. • The rate of frost buildup and collects on internal sweating increases. inside of • Flipper mullion • Adjust flipper mullion. (See “Flipper refrigerator Mullion”...

  • Page 29: Limited Warranty

    Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.265.8352 1-800-374-4432 Electrolux Canada Corp. Frigidaire 5855 Terry Fox Way 10200 David Taylor Drive Mississauga, Ontario, Canada Charlotte, NC 28262 L5V 3E4...
  • Page 30 Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your regristration card for more information.) Frigidaire.com 1-800-374-4432 Frigidaire.ca 1-800-265-8352...
