PRODUCT NO.
BASE MODEL NO.
FRS26R2AQ2
FRS26R2A
FRS26R2AQ3
FRS26R2A
FRS26R2AW2
FRS26R2A
FRS26R2AW3
FRS26R2A
MARKET
North America
WIRING DIAGRAM - 2 = # 240389604/ 3 = # 240389607
OWNER'S GUIDE - # 240389304
SERVICE DATA SHEET - 2 = # 240389604/ 3 = # 240389607
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995367439
020305
-EN/SERVICE /ECL
357
PARTS CATALO
VOLTS
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26R2A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS26R2A
Summary of Contents for Frigidaire FRS26R2A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26R2AQ2 FRS26R2A R134a bisque FRS26R2AQ3 FRS26R2A R134a bisque FRS26R2AW2 FRS26R2A R134a white FRS26R2AW3 FRS26R2A R134a white MARKET North America WIRING DIAGRAM - 2 = # 240389604/ 3 = # 240389607 OWNER’S GUIDE - # 240389304 SERVICE DATA SHEET - 2 = # 240389604/ 3 = # 240389607 SIDE BY SIDE...
-
Page 2: Freezer Door
Publication No. FRS26R2A 5995367439 FREEZER DOOR 03/02... - Page 3 FRS26R2A Publication No. 5995367439 FREEZER DOOR A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 240390602 A B C D Gasket-frzr door,white ,magnetic 240334201 A B C D Bin-door,frzr-upper 240351601 A B C D...
-
Page 4: Refrigerator Door
Publication No. FRS26R2A 5995367439 REFRIGERATOR DOOR 03/02... - Page 5 FRS26R2A Publication No. 5995367439 REFRIGERATOR DOOR A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 240390601 A B C D Gasket-refr door,white ,magnetic 240323001 A B C D Bin-door,pseudo ,bottom 240326203 A B C D...
- Page 6 Publication No. FRS26R2A 5995367439 CABINET 03/02...
- Page 7 FRS26R2A Publication No. 5995367439 CABINET A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 240435902 A B C D Cover-air duct 240475902 A B C D Cover-evap coil,lower 5303208309 A B C D Plug-hole,factory test...
- Page 8 Publication No. FRS26R2A 5995367439 SHELVES 03/02...
- Page 9 FRS26R2A Publication No. 5995367439 SHELVES A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 240434602 A - C - Trim-basket 240434604 - B - D Trim-basket 240338802 A B C D Shelf-freezer,flip-up 240338702 A B C D...
- Page 10 Publication No. FRS26R2A 5995367439 CONTROLS 03/02...
- Page 11 FRS26R2A Publication No. 5995367439 CONTROLS A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 5308000010 A B C D Fan Blade,red ,evaporator fan 5300157666 A B C D Bushing-motor mtg,(2) 5303292396 A B C D...
- Page 12 Publication No. FRS26R2A 5995367439 SYSTEM 03/02...
- Page 13 FRS26R2A Publication No. 5995367439 SYSTEM A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil,styrofoam ,(2) 218944001 A B C D Drier-filter,R134a System...
- Page 14 Publication No. FRS26R2A 5995367439 DISPENSER 03/02...
- Page 15 FRS26R2A Publication No. 5995367439 DISPENSER A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 218976410 A - C - Tube-water inlet 218976409 - B - D Tube-water 218976901 A B C D Tube-water inlet,inlet valve ,to ice maker 218976904...
-
Page 16: Ice Container
Publication No. FRS26R2A 5995367439 ICE CONTAINER 03/02... - Page 17 FRS26R2A Publication No. 5995367439 ICE CONTAINER A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 5304404344 A B C D Auger-ice 5304404343 A B C D Cam-drive 218815300 A B C D Container-ice,bucket only 5304404346...
-
Page 18: Ice Maker
Publication No. FRS26R2A 5995367439 ICE MAKER 03/02... - Page 19 FRS26R2A Publication No. 5995367439 ICE MAKER A = FRS26R2A (FRS26R2AW2) B = FRS26R2A (FRS26R2AW3) C = FRS26R2A (FRS26R2AQ2) D = FRS26R2A (FRS26R2AQ3) POS. NO PART NO DESCRIPTION 218976410 A - C - Tube-water inlet 218976409 - B - D Tube-water 218976901 A B C D Tube-water inlet,inlet valve ,to ice maker...
-
Page 20: Wiring Schematic
Publication No. FRS26R2AQ2 & FRS26R2AW2 5995367439 WIRING SCHEMATIC 03/02... - Page 21 FRS26R2AQ3 & FRS26R2AW3 Publication No. 5995367439 WIRING SCHEMATIC # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
-
Page 22: Wiring Diagram
Publication No. FRS26R2AQ2 & FRS26R2AW2 5995367439 WIRING DIAGRAM 03/02... - Page 23 FRS26R2AQ3 & FRS26R2AW3 Publication No. 5995367439 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
