  • Page 2 Maintaining your privacy is our long-standing policy at Lifetime. And you can rest assured that Lifetime will not sell or provide your personal data to other third parties, or allow them to use your personal data for their own purposes.
  • Page 3 POLE SECTION IDENTIFICATION Identify the pole sections before beginning assembly. Failure to assemble the pole sections correctly may result in severe personal injury or property damage as described on Page Two. ONCE THE POLE SECTIONS HAVE BEEN SEATED, THEY CANNOT BE SEPARATED. Note: Tapers and flares are exaggerated in the illustrations.

  • Page 4: Parts List

    PARTS LIST Part # Description 1018718 Right Backboard Bracket 1018717 Left Backboard Bracket 502005 502027H Adjustment Handle 502049G Trigger CA00899 Zip Tie HA00800 Gas Spring 1018837 Rear Lifter Arm ZA10199 Bellows 1025107 Backboard CB08999 Corner Frame Pad 1000841 Center Frame Pad DA01500D Pole Pad Pole Joint Hardware (1005748)
  • Page 5 HARDWARE IS ACTUAL SIZE (Unless otherwise indicated) (Not actual size) **A MINIMUM OF TWO ADULTS ARE REQUIRED FOR ASSEMBLY** TOOLS AND MATERIALS REQUIRED FOR ASSEMBLY (Not Included) Water Supply Pencil or Marker 13. Tape Measure Ladder Shovel 15. Phillips Screwdriver 17.

  • Page 6: Before Beginning Assembly

    PARTS LIST Part # Description Main Hardware (1039829) 300043 Cotter Pin 500081 Grease Packet Handle Hardware (1017923) 300101 Release Pin Frame Pad Hardware (HH00700) (Not actual size) (Not actual size) Before Beginning Assembly the hardware bags and their contents separate. If any parts are missing, call our Customer Service Department.
  • Page 8 For a nonpermanent installation of your basketball system, a Ground Sleeve provides an alternative to cementing the pole into the ground. See Page 22 for more information. diameter. The edge of the hole should be flush with the edge of the playing surface. up from the dimpled end of the Bottom 18”...
  • Page 9 inside the Bottom Pole (BP). Check the pole several times within the first Rebar hour to make sure that all sides are vertical and that the pole does not sink into the with the playing surface. Allow 1-4 hours for the concrete to set.
  • Page 10 1005748 Required For This Page: Screwdriver 1039829 Apply the Height Sticker (AU) so it wraps around the opposite side of the pole as the Spring Bracket (AL). AL MH Large holes Small holes Tighten all hardware securely. The small notch in the Sticker fits around the hole in the pole.
  • Page 11 Required For This Page: Screwdriver 1005748 This step cannot be reversed. In order to seat the poles, strike each end of the pole very This must be done even if the poles cover the slots before seating. If the Top Pole does not completely cover the slot on the Middle Pole after seating, DO NOT COMPLETE ASSEMBLY.
  • Page 12 1039829 Required For This Page: ME (1) 1017923 Pliers (Not actual size) 6 1/2” (Not actual length) Line up the Rear Lifter Arms (AP) with the Gas Spring (AM). Tighten the Nut until it is flush with the Bolt. Use pliers to bend the Cotter Pin (MD) as shown above.
  • Page 13 1039829 Required For This Page: TA (1) 1017923 6 1/2” TB (2) (Not actual length) Tighten the Nut until it is flush with the Bolt. Tighten the Nut until it is The Release Pin (TA) should fit flush with the Bolt. into the channels in the Trigger (AD).
  • Page 14 Required For This Page: MQ (2) 1039829 1012253 Hold the Backboard Make sure the U-Bolt (RF) is in Brackets (LB & RB) the notches. together. Completely tighten the Nuts (MA). Tighten the T-Nuts (RA) The Tap Bolts (RE) only until the Rubber should be at the Washers (RD) begin to outer edge of the...
  • Page 15 Required For This Page: RG (4) (Not actual size) 1012253 1039829 Slide a Spacer (MK) over each Tap Bolt (RE) between the Backboard and the Backboard Brackets. Only hand tighten the Nylock Flange Nuts (RG). Place the Plastic Guard (AF) on the back of the Rim.
  • Page 16 HH00700 Required For This Page: Electric Drill 1039829 Slide a Carriage Bolt (MI) into the crimped slot in each Backboard channel. Bend the Backboard Brackets (LB & RB) out. Completely tighten all Rim hardware. Do not overtighten the Nuts (RG). The lower holes should go over the Carriage Bolts.
  • Page 17 Required For This Page: 1039829 7 1/8” (Not actual length) Tighten the Nut until it is flush with the Bolt. Attach this end of Arms (AO) to the Backboard Brackets Tighten the Nut until it is flush with the Bolt. The Backboard and Rim must rest on cardboard to prevent scratching.
  • Page 18 Required For This Page: 1039829 7 1/8” (Not actual length) Lifter Arms (AP). The Rear Lifter Arms must be on the inside Only finger tighten the Nut. Only finger tighten the Nut.
  • Page 19 Required For This Page: 1039829 7 1/8” (Not actual length) Completely tighten the Nuts from steps 29 through 31. Apply Grease (MO) to Attach the Net (AB). these areas. Please call our Customer Service Department at the number on Page Two to obtain replacement Nets.
  • Page 20 CAUTION: When compressing the Gas Spring, use extreme caution to prevent the pole from extending. Slowly lift the pole and rotate the Backboard assembly upside down again. Grasp the Handle and Trigger as shown. Squeeze the Trigger and push down on the pole to compress the Gas Spring.
  • Page 21 Required For This Page: Screwdriver Hammer/Mallet 1005748 **AT LEAST 2 ADULTS REQUIRED FOR THIS STEP** Make sure the Backboard faces the playing surface and align the small hole in the Middle Pole (MP) with the correct slot in the Bottom Pole (BP). Slide the Middle Pole over the Bottom Pole. Middle Pole and into the Bottom Pole.
  • Page 22 Attach the Pole Pad (XX) to the Pole with the top strap above the handle as shown.
  • Page 23 POLE CARE AND SYSTEM MAINTENANCE pole failure, which may cause property damage or personal injury. corrosion. For safety reasons, and to prolong the life of your basketball system, you must take the following preventive measures. a. Check all Nuts and Bolts. If any are loose, tighten them. worn or damaged through usage.
  • Page 24 NOTES:...
  • Page 25 NOTES:...
  • Page 26 NOTES:...
  • Page 27 à l’anneau, au panneau ni aux leviers sous peine d’endommager l’équipement et d’annuler la garantie. www.lifetime.com #FS16500 10/12/2004...
  • Page 28 CLAIMS IF PARTS ARE UNAVAILABLE OR OBSOLETE. 1. Lifetime basketball systems are warranted to the original purchaser to be free from defects in material or workmanship for a period of five years from the date of original retail purchase. The from misuse, abuse or negligence will void this warranty.
