IMPORTANT
Keep in store for
future reference!
MANUAL- I/O Q3 SSM RMT
Q3SSM4R,Q3SSM6R,Q3SSM8R,
Q3SSM10R, Q3SSM12R
Operation Manual
Medium Temperature
Remote Cases
Installation &
P/N 3068445_D
September 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q3SSM10R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hussmann Q3SSM10R

Summary of Contents for Hussmann Q3SSM10R

  • Page 1 Q3SSM4R,Q3SSM6R,Q3SSM8R, Q3SSM10R, Q3SSM12R Medium Temperature Remote Cases Installation & Operation Manual IMPORTANT Keep in store for P/N 3068445_D future reference! September 2021 MANUAL- I/O Q3 SSM RMT...
  • Page 2 P/N 3068445 _D IMPORTANT KEEP IN STORE FOR FUTURE REFERENCE Quality that sets industry standards! 12999 St. Charles Rock Road • Bridgeton, MO 63044-2483 U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 www.hussmann.com © 2021 HussmannCorporation...

  • Page 3: Table Of Contents

    Federal / State Regulation ... . . 1-1 Hussmann Product Control ... 1-1 Cleaning Under Fan Plenum ..4-2 Shipping Damage .

  • Page 4: Ansi Z535.5 Definitions

    REVISION HISTORY REVISION D – Added model Q3SSM10R REVISION C – updated load limit pictures * * * * * * * * * * * * * * * * * * * * * * * * * * REVISION B –...

  • Page 5: Installation

    Recommended operating ambient conditioning, electric fans, open doors or temperature is between windows, etc. to create air currents around the 65°F (18°C) to 75°F (23.9°C). merchandiser. Maximum relative humidity is 55%. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

  • Page 6: Unloading

    Do NOT remove shipping crate until the merchandiser is positioned for installation. P/N 3068445 _D U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 7: Merchandiser Leveling

    first using the instructions in step one. 4. Apply masking tape 1/8" in from end of case on inside and outside rear mullion and body work on both cases to bejoined. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

  • Page 8: Serial Plate Location

    BOLT IN HOLE) VERTICAL SLOT) SERIAL PLATE LOCATION The serial plate is located on the inside of the merchandiser’s display area as shown below. Serial plate 8 foot merchandiser shown Model Q3SSM8R U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 9: Start Up Check List

    LEGAL DISCLAIMER: Hussmann shall not be liable for any repair or replacements made without the written consent of Hussmann, or when the product is installed or operated in a manner contrary to the printed instructions covering installation and service which accompanied such product.
  • Page 10 P/N 3068445 _D NOTES: U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 11: Electrical/Refrigeration

    • Do not use long or thin extension cords. Never use adapters. • If in doubt, call an electrician. ALWAYS CHECK THE SERIAL PLATE FOR COMPONENT AMPERES Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

  • Page 12: Wiring Color

    They are not intended nor suitable for large motors or other external NOTE: For installation or maintenance of the P-TRAP, appliances. use only adhesive compatible with ABS fittings. Item # 18s279 U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 13: Start Up / Operation

    Do not allow product to be placed outside of 15 minutes before rechecking the probe tem- the designated load limits in the illustration. perature and making further adjustments. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

  • Page 14: Thermometer

    Q-Series models have a solar thermometer. The thermometer is located at the top interior of the merchandiser. Product will be degraded and may spoil if allowed to sit in a non-refrigerated area. LOAD LIMIT U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 15: Maintenance

    •Do not use high pressure water hoses. Do NOT allow cleaning agent or cloth to contact food product. Product will be degraded and may spoil if allowed to sit in a non-refrigerated area. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

  • Page 16: Removing Scratches From Bumper

    This includes, but is not limited to, such items as doors, lights, fans, heaters, and thermostats. U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 17: Cleaning Stainless Steel Surfaces

    Do not use cleaners containing salts as this may cause pitting and rusting of the stainless steel finish. Do not use bleach. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
  • Page 18 To maintain product integrity, move all product to a cooler until the unit has returned to normal operating temperatures. U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...
  • Page 19 Verify unit doors and lids work and are sealed correctly. Verify that all the panels, shields and covers are in place. Technician Notes: Form HSCW03 Rev-29 OCTOBER13 0525210_C Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
  • Page 20 P/N 3068445 _D NOTES: U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 21: Service

    12. Reinstall display pans. Bring merchandiser 10. Verify that motor is working and blade is to operating temperature before restocking. turning in the correct direction. Note: Plenum length and number of fans will vary withmodel. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

  • Page 22: Replacement Parts List

    P/N 3068445 _D Replacement Parts List Part Number Q3SSM4R Q3SSM6R Q3SSM8R Q3SSM10R Q3SSM12R Drain Trap 18S279 Cover Drain 0301266 Thermometer (solar) 0517730 Product‐stop 4ft x 6.250in (shelves) 3067833 Product‐stop 4ft x 4.625in (shelves) 3067834 Product stop 6ft x 4.625in (shelves) 3046301 Product stop frnt 6ft x 6.250in (shelves) 3044954 Product‐stop 8ft x 4.625in (shelves) 3061677 Product‐stop frt 8ft x 6.250in (shelves) 3061678 Product‐Stp 10ft x 4.625in (shelves) 3150020 Front‐Product Stp 10ft x 6.250in (shelves) 3150019 Switch led light 1801241 Power supply 1000w 24VDC 3013744 Refrigeration Description Part Number Q3SSM4R Q3SSM6R Q3SSM8R Q3SSM10R Q3SSM12R...
  • Page 23 SELF-SERVICE DELI REVISION DATE 01/31/17 HUSSMANN - Q3-SS (CHINO) REFRIGERATION DATA: CAPACITY *** EST. GLYCOL (20°F GLYCOL (20°F TEMPERATURE (ºF) (BTU/HR/FT) (TOTAL VELOCITY INLET, 6° RISE) INLET, 6° RISE) CASE REFG. CASE LENGTHS/ FOR WEDGES) CASE USAGE (FT/MIN) LENGTHS CHRG.

  • Page 24: Technical Data

    A — T P/N 3068445 _D ppendix echnical Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
  • Page 25 P/N 3068445 _D ESTIMATED SHIPPING WEIGHT Model Case Weight (with shipping crate) Q3SSM4R 551 lb (250 kg) 617 lb (280 kg) Q3SSM6R 794 lb (360 kg) 959 lb (435 kg) Q3SSM8R 1058 lb (480 kg) 1263 lb (573 kg) Q3SSM10R 1323 lb (600 kg) 1598 lb (725 kg) Q3SSM12R 1588 lb (720 kg) 1918 lb (870 kg) Actual weights will vary according to optional kits included. U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...

  • Page 26: Wiring Diagrams

    P/N 3068445 _D Electrical Wiring Diagrams U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...
  • Page 27 Appendix A P/N 3068445 _D Electrical Wiring Diagrams Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
  • Page 28 REPARACIÓN SHELVES CANOPY ELECTRIC SPECS LEDS LEDS MODEL: Q3SSM10R VOLTAGE: 120V FRECUENCY: 60 HZ NOTE FOR GFCI PROTECTION: IF MORE THAN ONE SINGLE YELLOW RECEPTACLE IS USED IN CONJUNCTION WITH A GFCI DUPLEX RECEPTACLE "DOWNSTREAM" ON THE LOAD SIDE, THE SUM OF...
  • Page 29 P/N 3068445 _D Electrical Wiring Diagrams U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...
  • Page 30 Appendix A P/N 3068445 _D Electrical Wiring Diagrams Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
  • Page 31 To obtain warranty information or other support, contact your Hussmann representative. Please include the model and serial number of the product. Hussmann Corporation, Corporate Headquarters: Bridgeton, Missouri, U.S.A. 63044-2483 01 October 2012...

  • Page 32: Bumper Installation

    Slowly (when it gets cold). apply pressure by rolling the bumper into the track.Boston Series 2000 P/N 3068445 _D U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...
  • Page 33 Adding the additional materials will compensate for ● Over cut the flexible vinyl and compression fit. stretching which occurs during installation. Adding the additional materials will compensate for stretching which occurs during installation. Q3 Remote Merchandisers HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
  • Page 34 Roll vinyl top over full length of base, then tap with rubber mallet to ensure vinyl is securely locked into the base. P/N 3068445 _D U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com...
  • Page 35 Hussmann Corporation 12999 St. Charles Rock Road Bridgeton, MO 63044-2483 www.hussmann.com...
