NOTE: Carefully read entire instructions thoroughly before attempting to install this part.
Parts Included
Storage Bag
Shade Cover
Cover Hold Down Strap
Note: The Trail Shade is a universally fitting product that can be mounted on roof racks, baskets, roll
cages, spare tires, ect. Use these instructions as a guide to install on the previously mentioned
accessories. The Trail shade is completely portable and can be carried like a traditional back pack
or mounted on some accessories. (Fig A, B)
(Fig A)
Step 1: To attach storage bag on spare tire simply disconnect the two vertical buckles on the back
of the bag and slide the strap through the spokes of the wheel and then connect to the opposite
side on top of the tire. (Fig C)
Step 2: Remove the contents for the bag. Including poles, cord, steak, straps, and shade cover. (Fig D-F)
(Fig D)
For Technical Support/Warranty Information please call 310-762-9944
Qty
1
1
3
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
Trail Shade
Part #5662424
Parts Included
Collapsible Pole
Shock Cord
Shock Cord Stake
(Fig B)
(Fig E)
Qty
2
2
2
(Fig C)
(Fig F)
