Kilews SKD-BN7030L Operation And Maintenance Manual
Hide thumbs
Also See for SKD-BN7030L:
- Operation and maintenance manual (12 pages) ,
- Operation and maintenance manual (12 pages)
Related Manuals for Kilews SKD-BN7030L
Summary of Contents for Kilews SKD-BN7030L
- Page 1 OPERATION AND MAINTENANCE MANUAL SKD-BN7030L SKD-BN7030P SKD-BN7022LF SKD-BN7022PF DC-TYPE Non-Carbon-Brush Electric Screwdrivers KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com Y2F119A-5-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. SAVE THIS INSTRUCTIONS 1) Electrical Safety a) Keep work area clean and well lit. - Page 4 d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Do not let visitors touch the tool or extension cord. All visitors should be kept away from work area. e) Maintain power tools.
-
Page 5: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 6 Operations Cautions 1) Before changing bits from BN7030 Series screwdriver, make certain the Forward / Reverse Switch is in the “ OFF “ position and tool is unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 7: Description Of Operation
Lo for slowest rotation. It's possible that the uncompleted shut-off occurs when the switch is setup to Lo and the presetting torque is more than 50% of torque range. Please refer to the following table. Lo Switch SKD-BN7022LF SKD-BN7022PF SKD-BN7030L SKD-BN7030P 1.5( N.m )↓ 1.1( N.m )↓ 1.1( N.m )↓... -
Page 8: Do Not Attempt To Repair This Electric Screwdriver
All repairs and maintenance of this tool and its word must be performed by an authorized service center. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. Repairs should by made only by authorized, trained personnel. Consult your nearest KILEWS authorized service center. -
Page 9: Specifications
No. 2．． ．．Bit use in dia 3.0~4.0mm screw SKD-BN7030 with BIT 2 Pcs SKD-BN7022F with BIT 1# & 2# 1 Pcs. Each. 2. Suspension rack and Torque fixing ring acceptable for use with the tool are available from KILEWS catalogue. 3. Torque Fixing Ring KC-2 1 Pcs. -
Page 10: Torque Adjustment Operation
1. Please read the operation caution carefully before using our screwdriver, and follow the safety information to use this power supplier. 2. Please choose the applicable must work with KILEWS 6PIN power cord assembly and power controller according to the screwdriver model specifications shown.
