Parts Lists And Diagrams - Avanti AV-HVLP-5S Owner's Manual & Safety Instructions

Clean the Spray Gun Body and Cup IMMEDIATELY after EVERY use and when it will be idle for
more than 30 minutes. Delayed or inadequate cleaning will permanently clog the Spray Gun.
PLEASE READ THE FOLLOWING CAREFuLLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Parts Lists and Diagrams

Spray Gun Parts List
Part Description
1 Gun Body
2 Fluid Nozzle
3 Spring (58149 only)
4 Air Valve
5 Air Cap
6 Gasket
7 Lock Ring
8 Vent Screw
9 Plug
10 Fluid Inlet
11 Handle
12 Handle Tube
13 Handle Cover
14 Air Inlet
15 Trigger Pin
16 Trigger
17 Fluid Control Knob
18 Fluid Needle Spring
19 Fluid Needle Assembly
20 Fluid Needle Adjustment Seat
21 Fluid Needle Sealing Gasket
22 Air Valve Spring
Page 20
NOTICE
Paint hardens quickly and permanently inside Spray Gun.
Qty
For technical questions, please call 1-888-866-5797.
Part
1 23 Fluid Needle Sleeve
1 24 Air Valve
1 25 Fluid Needle Compression Ring
1 26 Needle Plug Sleeve Sealing Gasket1
1 27 Fluid Needle Protective Sleeve
1 28 Fluid Needle Sealing Screw
1 29 Fluid Needle Sealing Spring
2 30 Fluid Needle Plug Seal
1
31 Screw
1
32 Air Control Knob
1
33 Gasket 14*17*0.4mm
1
34 Airflow Adjustment Seat
1
35 O-Ring 7.5*1.8
1
36 Airflow Adjustment Valve
1
37 Washer
1
38 C-Clip
1
39 Cup Cover Assembly
1
40 Air Tube
1
41 Check Valve
1
42 Sealing Gasket
1
43 Cup Assembly
1
Description
Item 58479 58149
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
