Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
NOTICE
CLEAN IMMEDIATELY
Clean the Spray Gun
IMMEDIATELY after EVERY
use and when it will be idle
for more than 30 minutes.
Delayed or inadequate
cleaning will permanently
clog the Spray Gun.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2018 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
19a

Advertisement

loading
Need help?

Need help?

Do you have a question about the 64934 and is the answer not in the manual?

Questions and answers

Related Manuals for Avanti 64934

Summary of Contents for Avanti 64934

  • Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.

  • Page 2: Table Of Contents

    3. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the tool in unexpected situations. Page 2 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 3 5. Risk of injection – Do not point spray gun at any 10. Avoid unintentional starting. Prepare to person or any part of the body. In case of skin begin work before turning on the tool. injection, seek medical attention immediately. Item 64934 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4 • Properly maintain and inspect to avoid electrical shock. • Properly ground power cord. Ground Fault Circuit Interrupter (GFCI) should also be implemented – it prevents sustained electrical shock. SAVE THESE INSTRuCTIONS. Page 4 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 5 Risk of Electric Shock. WARNING marking concerning Risk of Eye Injury. Properly connect power cord Wear ANSI-approved eye protection. to appropriate outlet. WARNING marking concerning Risk of Respiratory Injury. Wear NIOSH-approved respirator. Item 64934 For technical questions, please call 1-888-866-5797. Page 5...
  • Page 6 5. If you are using one extension cord for more than one tool, add the nameplate amperes and use the sum to determine the required minimum cord size. (See Table A.) Page 6 For technical questions, please call 1-888-866-5797. Item 64934...

  • Page 7: Specifications

    * Based on limiting the line voltage drop to five volts at 150% of the rated amperes. Specifications Electrical Rating 120  V AC / 60  H z / 4  A Cup Capacity 48 fl. oz. Tip Size 2.5mm HOuSEHOLD uSE ONLY. Item 64934 For technical questions, please call 1-888-866-5797. Page 7...

  • Page 8: Setup

    Read the ENTIRE IMpORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Components Compressor Spray Lock Ring Body Fluid Control Trigger Knob Page 8 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 9 3. Push Clip forward until it clicks to attach Compressor Air Compress and Spray Gun Body together. Body Clip Suction Tube position Normal Spraying - Suction Tube angled forward. Upward Spraying - Suction Tube angled backward. Suction Tube Item 64934 For technical questions, please call 1-888-866-5797. Page 9...

  • Page 10: Operation

    6. Check viscosity. Thin and check until proper viscosity is achieved. 7. Fill the Cup no higher than 48 oz. mark. 8. Replace the Cup. Page 10 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 11 2. Spray on piece of scrap material in short bursts, then check consistency. 3. Adjust the Fluid Control Knob until proper flow is achieved. Too Coarse Correct Too Fine (Close (Open Knob) Knob) Fluid Control Knob Item 64934 For technical questions, please call 1-888-866-5797. Page 11...
  • Page 12 EVERY use and when it will be idle for more than 30 minutes. Delayed or inadequate 4. Keep the distance from the workpiece cleaning will permanently clog the Spray Gun. between 2" and 12". Page 12 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 13 NOTICE: Do not use any kind of lubricant. The lubricant will mix with paint, causing poor results. Spent Solvent Disposal After cleaning, dispose of spent solvent according to the solvent manufacturer’s directions and local hazardous waste standards. Item 64934 For technical questions, please call 1-888-866-5797. Page 13...

  • Page 14: Maintenance

    • misalignment or binding of moving parts, • any other condition that may affect its safe operation. • clogged nozzle or fluid tip, Storage Store in a dry, secure area out of reach of children. Page 14 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 15 3. Wash filter in warm water and mild detergents several times. Rinse. Squeeze out excess 2. Remove housing and Air Filter. water and allow it to dry completely. 4. Install cleaned filter and replace housing and screws. Item 64934 For technical questions, please call 1-888-866-5797. Page 15...
  • Page 16 3. Cup and/or Lid loose. 3. Tighten Cup and/or Lid. 4. Clogged Check Valve. 4. Clean Check Valve. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect air supply before service. Page 16 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 17 3. Airflow too high. 3. Reduce Airflow. 4. Clogged Check Valve. 4. Clean Check Valve. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect air supply before service. Item 64934 For technical questions, please call 1-888-866-5797. Page 17...

  • Page 18: Parts List And Diagram

    Motor Trigger Adjusting Knob Damping Washer Trigger Adjusting Knob Spring Motor Holder Trigger Push Rod Spring Gasket Push Rod Suction Tube Clip Cup 48 oz Clip Pin Power Cord Clamp Page 18 For technical questions, please call 1-888-866-5797. Item 64934...
  • Page 19 Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 64934 For technical questions, please call 1-888-866-5797. Page 19...

  • Page 20: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
