NetFlow Version 9 Templates
Table 5 NetFlow Version 9 Template Header and Data Field Support (continued)
DIP
Dest IfIndex
Source IfIndex
Packet Count
Byte Count
Start Time
Last Time
IP Protocol
TOS
L4 Source Port
L4 Dest Port
V9 NetFlow Data Record (Template 259, Next Hop ID with TCP/UDP)
Data Field
SIP
DIP
Dest IfIndex
Source IfIndex
Packet Count
Byte Count
Start Time
Last Time
IP Protocol
TOS
Next Hop Router
February 26, 2008
(Destination) IP address of the destination
device.
MIBII 32-bit ID of the interface on which the
packet was transmitted.
MIBII 32-bit ID of the interface on which the
packet was received.
The number of packets switched through this
flow.
The number of bytes switched through this flow.
sysUptime in msec at which the first packet of
this flow was switched.
sysUptime in msec at which the last packet of
this flow was switched.
IP protocol for this flow.
Type of service field value for this flow.
TCP/UDP source port nunmber (for example,
FTP, Telnet, or equivalent)
TCP/UDP destination port nunmber (for
example, FTP, Telnet, or equivalent)
Support
(Source) IP address of the device that
transmitted the packet.
(Destination) IP address of the destination
device.
MIBII 32- bit ID of the interface on which the
packet was transmitted.
MIBII 32- bit ID of the interface on which the
packet was received.
The number of packets switched through this
flow.
The number of bytes switched through this flow.
sysUptime in msec at which the first packet of
this flow was switched.
sysUptime in msec at which the last packet of
this flow was switched.
IP protocol for this flow.
Type of service field value for this flow.
Specifies the BGP next-hop address.
