Terms and Definitions

Table 2 Default NetFlow Settings for the Matrix X Core Router (continued)
Parameter
Export Interval
Export AS
Number of Entries
Port state
Terms and Definitions
Table 3 lists terms and definitions used in this NetFlow configuration discussion.
Table 3 NetFlow Configuration Terms and Definitions
Term
Active Flow Timer
Flow
Flow Record
Inactive Flow Timer
NetFlow Cache
NetFlow Collector
NetFlow Export
NetFlow Export
Packet
NetFlow
Management
Application
NetFlow Version
February 26, 2008
Description
The time out interval when the NetFlow cache is
flushed and the data is exported, if the maximum
number of entries has not been reached.
Whether the BGP AS addresses are origin or peer.
BGP AS addresses are not supported by Version 1.
The maximum number of flows saved into the
cache.
Whether NetFlow is enabled or disabled on a port.
Definition
A timer which specifies the maximum amount of time a flow may stay active. The
ongoing flow continues to be tracked as a separate flow. It is the management
application's responsibility to join these flows for analysis/reporting purposes.
A stream of IP packets that has not yet met an expiration criteria, in which the value
of a set of key fields is the same for each packet in the stream.
A capture of information pertaining to a single flow within the NetFlow Cache based
upon data type values supported by the NetFlow version format/template.
A timer that determines how long a flow for which no packets are being received
remains active.
Contains the flow records for all currently active flows.
A location where a condensed and detailed history of flow information that entered
each NetFlow-enabled switch or router is archived for use by the NetFlow
management application.
A transport mechanism that periodically (based upon a timer or the number of flows
accumulated in the cache) sends NetFlow data from the cache to a NetFlow collector
for data analysis.
A packet of flow records or version 9 templates (or both) that is periodically sent to
the NetFlow collector based upon an export criteria.
A Dragon Security Command Console (DSCC) or third-party software application(s)
installed on the NetFlow collector, with client or browser access from a PC, capable
of data reduction, monitoring, analysis, and/or troubleshooting specific to the
purpose you are using NetFlow.
Primarily determines the data types supported and whether the format is fixed or in
an extensible template.
Default Value
30 minutes
peer AS
84 KB
Disabled
Page 13 of 19
