Configuring NetFlow on the Matrix X Core Router
clear netflow port port-string
When you disable NetFlow on a port, NetFlow will stop sampling and the current flow data will
be exported when the export time out interval expires.
To disable NetFlow globally, use either of the following commands:
set netflow cache disable
clear netflow all
When you execute the clear netflow all command, all NetFlow settings are returned to their
default condition. In the case of the global NetFlow cache setting, the default is disabled.
Displaying NetFlow Information
To display the current NetFlow configuration settings:
show netflow config
To display NetFlow statistics on a per‐port basis:
show netflow statistics port-string
To display flow counters for the current cached NetFlow information, on a system‐wide or
IOM‐specific basis:
show netflow cache-flow [slot-id]
Default NetFlow Settings for the Matrix X Core Router
Table 2 provides a listing of the default NetFlow settings for the Matrix X Core Router.
Table 2 Default NetFlow Settings for the Matrix X Core Router
Parameter
Cache Status
Sampling Rate
Engine ID
Engine Type
Administrative Interface
Destination IP
Destination UDP port
Export Version
February 26, 2008
Description
Whether NetFlow caching is globally enabled or
disabled.
The rate at which packets are captured, or sampled.
100 indicates that 1 in 100 packets is captured.
The ID number of the flow switching engine. This ID
is required by NetFlow export version 5 format.
The type of flow switching engine. This value is
required by NetFlow export version 5 format.
This is the interface used for the source IP address
of the exported NetFlow UDP datagrams.
The IP address of the NetFlow collector which is the
destination of the NetFlow UDP packets.
The UDP port on the NetFlow collector.
The NetFlow flow record format used when
exporting NetFlow packets. Version can be either 1
or 5.
Default Value
Disabled globally
100
0
0
eth0
None
2055
Version 5
