Body Composition Monitor
HBF-702T
Thank you for purchasing the OMRON Body Composition Monitor.
Before using this unit, please be sure to read this Instruction Manual carefully to
understand the safe and proper use.
Please store this Instruction Manual carefully for future reference.
5659713-6A
Issue date: 2020-12-28

Advertisement

Table of Contents
loading

Related Manuals for Omron HBF-702T

Summary of Contents for Omron HBF-702T

  • Page 1 Body Composition Monitor HBF-702T Thank you for purchasing the OMRON Body Composition Monitor. Before using this unit, please be sure to read this Instruction Manual carefully to understand the safe and proper use. Please store this Instruction Manual carefully for future reference.

  • Page 2: Table Of Contents

    HBF-702T Body Composition Monitor This unit can measure and display the following parameters. - Body Weight - Body Fat (in %) - Visceral Fat (up to 30 levels) - Segmental Skeletal Muscle (in %) - Segmental Subcutaneous Fat (in %)

  • Page 3: Before Using The Unit

    Before using the unit Notes on Safety Symbols and definitions are as follows: Danger Improper use may cause danger resulting in death or serious injury. Warning Improper use may result in possible death or serious injury. Caution Improper use may result in injury or property damage. Danger •...
  • Page 4 • During measurement, make sure that no mobile phone or smartphone is near this device. This may result in incorrect operation of the device and/or cause an inaccurate reading. • Use batteries specified for this unit. Do not insert the batteries with the polarities in the wrong direction. •...

  • Page 5: Know Your Unit

    Before using the unit 1. Know Your Unit Grip Electrodes Grip Electrodes Panel Unit Panel Unit Holder Cord Main Unit Foot Electrodes Foot Electrodes Feet (×4) Power Switch  • Press this switch to turn on / turn off the power. Bluetooth Button •...
  • Page 6 Display Personal Number Symbol  Displays when selecting a personal number. Weight Symbol  Displays when only measuring the body weight. Low Battery symbol Blinks when batteries are low.  Depleted Battery symbol Displays when batteries are depleted. SYNC Symbol Blinks or displays when the measurement results need to be transferred ...

  • Page 7: Installing And Replacing The Batteries

    ■ When the batteries are replaced, you need to reset the date and time. ( P7 ) • If you have already paired with the "OMRON connect" app, press the button to communicate with this app, then the date and time and personal data will be set automatically.

  • Page 8: Initial Setting

    • One smart device manages the data of one user. • If an app other than "OMRON connect" is used, data might not be transferred correctly. • Please read the utilization method and usage instruction within the app for details.
  • Page 9 Setting the date and time Press the button to select the year • Setting range of year: 2017 to 2045. Press the button to confirm the year, then the month will blink. Repeat the same steps to select and confirm the Year month, day, hour, and minute.

  • Page 10: Registering The Personal Data

    For the measurement of body composition, it is necessary to register your personal data (birth date, gender, height). The registered data can be stored for up to 4 users. The personal data can be registered from "OMRON connect" app as well. Steps for changing/deleting personal data...
  • Page 11 Set the gender • Press the button to set the gender (MALE) or (FEMALE) and press the button to confirm. Set the height • Press the button to adjust the height and press button to confirm. • After setting "Height", the set "Date of Birth, Age and Height" is displayed, "0.0 kg"...

  • Page 12: How To Take A Measurement Accurately

    Before using the unit 5. How to Take a Measurement Accurately 5.1 Correct postures during the measurement The arms are horizontally raised, and the elbows are extended straight. 90° Stand with your Extend your arms knees and back straight at a 90° angle straight to your body.

  • Page 13: Recommended Measurement Time Period And Users

    5.2 Recommended measurement time period and users Suitable period for measuring: After getting up and 2 hours after taking food After getting up Above 2 hours after taking food For users under 10 years old, the unit displays weight and BMI only. Incorrect measurement might occur to the following users.

  • Page 14: Operating Instructions

    Operating instructions 6. Measuring Weight and Body Composition If you use the automatic recognition for measurement, please register the Personal Data. P7 , P9 ) With the panel unit inside the main unit, Press power switch to turn on the power •...
  • Page 15 After the measurement results are displayed, step off the main unit. Weight Body Fat Percentage Check your Personal Number • This product will infer the personal number automatically from weight and body composition. However, when users of similar body type and body weight are measured, wrong personal number may be displayed. If your personal number If your personal number is correct…...
  • Page 16 Check the Measurement Results • The results display rotates automatically as shown below. • Once you confirm your personal number, you can switch it to a measurement result you want to view with button. WEIGHT SUBCUTANEOUS FAT PERCENTAGE Body Fat Percentage Skeletal Muscle Percentage Subcutaneous Classification...
  • Page 17 Whole Body Arms SUBCUTANEOUS FAT PERCENTAGE Subcutaneous Fat Percentage Classification SKELETAL MUSCLE Skeletal Muscle PERCENTAGE Percentage Classification Legs Trunk Press the power switch to turn off the power • Please insert the panel unit into the main unit. ( P25 ) •...

  • Page 18: Using The Memory Function

    Using the Memory Function 7. Viewing the Measurement Results on the unit This unit automatically stores up to 30 measurement results per user. With the panel unit inside the main unit, Press power switch to turn on the power • After the display of date, it will display "0.0 kg", current...

  • Page 19: View The Measurement Results On Your Smart Device

    Using the Memory Function 8. View the Measurement Results on Your Smart Device Follow the instructions from the "OMRON connect" app to view your measurement results. Then you can confirm the variation of your weight and body composition parameters on your smart device.

  • Page 20: When Necessary

    When necessary 9. Selecting Your Personal Number and Taking a Measurement If your personal number is not recognized frequently, you can select your personal number and take the measurement as follows. With the panel unit inside the main unit, Press power switch to turn on the power •...

  • Page 21: Using The Guest Mode (Unrecorded Mode)

    When necessary 10. Using the Guest Mode (Unrecorded Mode) Users who does not register personal data in advance can measure weight and body composition by temporarily inputting "date of birth, gender and height". When this mode is used, your measurement results will not be recorded. With the panel unit inside the main unit, Press power switch to turn on the power •...
  • Page 22 Set the gender • Press the button to set the gender (MALE) or (FEMALE) and press the button to confirm. Set the height • Press the button to adjust the height and press button to confirm. • After setting "Height", the set "Date of Birth, Age and Height" is displayed, "0.0 kg"...

  • Page 23: Measuring Weight Only

    When necessary 11. Measuring Weight Only When this mode is used, personal number cannot be inferred automatically. When this mode is used, your measurement result will not be recorded. When the power of the unit is off, take a measurement directly without taking the panel unit from the holder.

  • Page 24: Changing/Deleting Personal Data

    When necessary 12. Changing/Deleting Personal Data With the panel unit inside the main unit, Press power switch to turn on the power • After the display of date, it will display. "0.0 kg", current " " and " " will blink. Select the personal number button to select the personal number you want to change / delete ( Press the...

  • Page 25: Deleting The Communication Setting

    When necessary 13. Deleting the Communication Setting If you want to stop the use of the "OMRON connect" app or delete the communication settings from your smart device, please operate as follows. All the communication settings recorded in the unit will be deleted.

  • Page 26: Maintenance And Storage

    Do not wash the unit and the panel with water. • Do not carry out repairs of any kind by yourself. This product is calibrated at the time of manufacture. If at any time you question the accuracy of measurements, please contact your authorized OMRON distributor.

  • Page 27: Troubleshooting

    Body weight of 135 kg or over is out of the measuring range of this unit. Confirm the display of your smart device and follow the Communication failure. instructions in "OMRON connect" app. Refer to "Help" from "OMRON connect" app. Recommend to replace the batteries with new ones ahead Batteries are low.
  • Page 28 Problem Possible Cause Correction Batteries are not inserted. Or Insert the batteries in correct the polarities of batteries are not • Nothing is displayed when alignment. P6 ) aligned correctly. the power is turned on. Replace all four batteries with The batteries are worn out.
  • Page 29 Refer to "Help" in "OMRON connect" app. NOTES • If measuring cannot be performed normally after the above has been done. Please consult OMRON service representative. • Although it is seldom seen, human physique difference might lead to incapability of measuring.

  • Page 30: Technical Data

    When necessary 16. Technical Data Product Description OMRON Body Composition Monitor Model HBF-702T Display* Body Weight: 3.0 to 100.0 kg with an increment of 0.1 kg 100.0 to 135.0 kg with an increment of 0.2 kg BMI: 2.5 to 90.0 with an increment of 0.1 BMI Classification: –...
  • Page 31 ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by OMRON HEALTHCARE Co., Ltd. is under license. Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.

  • Page 32: Information On Body Composition

    BMI uses the following simple formula to indicate the ratio between weight and height of a person. BMI = weight (kg) / height (m) / height (m) The OMRON HBF-702T uses the height information stored in your personal number or when entering information in the Guest Mode to calculate your BMI classification.
  • Page 33 Body fat percentage (%) = {Body fat weight (kg) / Body weight (kg)} × 100 HBF-702T uses the BI method to estimate your body fat percentage. Mention body fat and a bad impression is always given. However, in fact, body fat plays roles in energy storage and viscera protection, etc.

  • Page 34: Measurement Results Interpretation Diagrams

    0 (Normal) 15.0 - 30.0 ++ (Very High) 25 - 29.9 + (Overweight) 30.0 - 90.0 ++ (Obese) According to OMRON HEALTHCARE figures Interpreting the Skeletal Muscle Percentage Result Gender – (Low) 0 (Normal) + (High) ++ (Very High) Female 5.0-25.8%...
  • Page 36 53, Kunotsubo, Terado-cho, Muko, KYOTO, 617-0002 JAPAN KRELL PRECISION (YANGZHOU) CO., LTD. PRODUCTION No. 28, Xingyang Road Economic Development ZoneYangzhou, FACILITY Jiangsu 225009, China OMRON HEALTHCARE SINGAPORE PTE LTD. 438A Alexandra Road, #05-05/08, Alexandra Technopark, Asia Pacific HQ Singapore 119967 www.omronhealthcare-ap.com MADE IN CHINA...
