Woxcon SM62T User Manual

6x2 4k presentation switcher with matrix outputs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
SM62T
6x2 4K Presentation Switcher with
Matrix Outputs
All Rights Reserved
Version: SM62T_2018V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM62T and is the answer not in the manual?

Questions and answers

Related Manuals for Woxcon SM62T

Summary of Contents for Woxcon SM62T

  • Page 1 User Manual SM62T 6x2 4K Presentation Switcher with Matrix Outputs All Rights Reserved Version: SM62T_2018V1.1...
  • Page 2 6x2 4K Presentation Switcher with Matrix Outputs Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
  • Page 3 6x2 4K Presentation Switcher with Matrix Outputs SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment.

  • Page 4: Table Of Contents

    6x2 4K Presentation Switcher with Matrix Outputs Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ....................... 2 2. Specification ........................ 3 3. Panel Description ......................5 3.1 Front Panel ......................5 3.2 Rear Panel ......................6 4.
  • Page 5 6x2 4K Presentation Switcher with Matrix Outputs 7.2.7 HDCP Compliance ................. 28 7.2.8 Control Far-end Device ................29 8. GUI Control ........................ 30 8.1 Video Switching ....................31 8.2 VGA Scaling Resolution Selection ..............32 8.3 Audio Switching and Volume Adjustment ............33 8.4 EDID Management ...................

  • Page 6: Product Introduction

    6x2 4K Presentation Switcher with Matrix Outputs 1. Product Introduction The SM62T is a 6 input multi-format (3 HDMI, 2 VGA, and 1 DP) 4K presentation switcher that switches video signals to an HDMI and an HDBaseT output. The HDBaseT output supports PoH and can connect to a compatible HDBaseT receiver up to a maximum of 70 meters (230 feet) (HDBaseT receiver sold separately).

  • Page 7: Package List

    Controllable via front panel buttons, IR Remote, RS232 & GUI. Supports online software upgrading. 1.2 Package List 1 x SM62T 6x2 4K Presentation Switcher 2 x Mounting Ears with 6 Screws 4 x Plastic Cushions 1 x IR Receiver (5V with carrier wave)

  • Page 8: Specification

    6x2 4K Presentation Switcher with Matrix Outputs 2. Specification Video Input (3) HDMI; (1) DP; (2) VGA Input (3) Female HDMI; (1) DisplayPort; Input Connector (2) Female VGA (15-pin) Input Video Signal HDMI, DP, VGA HDMI Input Resolution Up to 4Kx2K @30Hz 4:4:4 DP Input Resolution Up to 4Kx2K@30Hz VGA Input Resolution...
  • Page 9 6x2 4K Presentation Switcher with Matrix Outputs (1) 4-pin/5 mm phoenix connector Output Analog Audio Format Output Digital Audio PCM/Dobly/DTS Format Audio Output Impedance 70 Ohms Frequency Response 20 Hz to 20 kHz, ±3dB Common Mode Rejection >70 dB at 20 Hz to 20 kHz Ratio (CMRR) Signal to Noise Ratio 80 dB (Max)

  • Page 10: Panel Description

    6x2 4K Presentation Switcher with Matrix Outputs 3. Panel Description 3.1 Front Panel 9 7 10 MIC + 1-HDMI 2-HDMI 3-HDMI 4-DP 5-VGA 6-VGA AUTO 1-HDMI 2-HDBT 5-VGA 6-VGA MENU/3s VOL - VOL + MENU SOURCE OUTPUT RESOLUTION ENTER MIC - ①...

  • Page 11: Rear Panel

    6x2 4K Presentation Switcher with Matrix Outputs 3.2 Rear Panel AUDIO INPUT AUDIO OUTPUT CONTROL SPDIF 1x40W @ Ω N DIP MONO Default 1 2 3 4 1 2 3 4 STEREO BRIDGE 2x20W@4Ω LINE AUDIO 1 AUDIO 2 AUDIO 3 EDID FIRMWARE IR IN...
  • Page 12 6x2 4K Presentation Switcher with Matrix Outputs HDBaseT receiver. TCP/IP: Ethernet port, connect with PC to control the switcher via GUI. ⑥ AMPLIFIER: 4/8 Ohm speaker outputs. ⑦ AC100V~240V: Power port, connect to an AC 100V~240V power via the included power cord.

  • Page 13: System Connection

    6x2 4K Presentation Switcher with Matrix Outputs 4. System Connection 4.1 Usage Precaution Verify all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets, and power cords should be insulated and safe.

  • Page 14: Speaker Wiring

    6x2 4K Presentation Switcher with Matrix Outputs 4.3 Speaker Wiring 4.3.1 Stereo and Mono Options 4Ω Load with 4Ω Speakers: 4.3.2 Bridged Audio Option 8Ω Load with 8Ω Speakers:...

  • Page 15: Button Control

    6x2 4K Presentation Switcher with Matrix Outputs 5. Button Control The front panel buttons can be used for signal switching, VGA resolution, and volume adjustment. 5.1 Manual Signal Switching First press any one of six inputs button, second press either 1-HDMI or 2-HDBT output button, and finally press ENTER to select.

  • Page 16: Vga Scaling Resolution Selection

    6x2 4K Presentation Switcher with Matrix Outputs will output the signal. If not, the unit will detect all the input signals with priority from 1-HDMI to 6-VGA. When detected the first signal, it will transfer to output. ü Signal removing Once removing the current display signal, the switcher will detect all input signals with priority from 1-HDMI to 6-VGA.

  • Page 17: Embedded Edid Invoking

    6x2 4K Presentation Switcher with Matrix Outputs In Link Info In 01 02 03 04 05 06 Out Link info Connect Y N N N Connect N N In Link Info Out Link info Connect Y N 5.6 Embedded EDID Invoking The rear panel boasts a 4-pin DIP switcher to invoke embedded EDID.

  • Page 18: Ir Remote Control

    6x2 4K Presentation Switcher with Matrix Outputs 6. IR Remote Control Connect IR receiver to IR IN port, the switcher can be controlled by using the including IR Remote. ① Enter/ exit standby mode. ② Source Selector (1~6): Select video source via pressing corresponding button (VGA audio switched following the 3-HDMI...

  • Page 19: Rs232 Control

    6x2 4K Presentation Switcher with Matrix Outputs 7. RS232 Control The switcher can be controlled by sending RS232 commands. As RS232 signal can be transmitted from the switcher to HDBaseT receiver, so it is able to control a far-end third-party device based on RS232 pass-through function. The baud rate can support 2400, 4800, 9600(default), 19200, 38400, 57600 or 115200.
  • Page 20 6x2 4K Presentation Switcher with Matrix Outputs The interface of the control software is shown as below: Parameter Configuration area Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area.

  • Page 21: Rs232 Communication Command

    Data bit: 8 Stop bit: 1 Parity bit: none 7.2.1 System Command Command Example Command Description and Response /*Type; /*Type; Report system model. SM62T /%Lock; /%Lock; Lock front panel buttons. System Locked! /%Unlock; /%Unlock; Unlock front panel buttons. System UnLock! /^Version; /^Version;...

  • Page 22: Signal Switching

    Report the IP address. IP:192.168.0.178 %0911. Factory Default V1.0.1 System UnLock! %0911. Reset to factory default. IP:192.168.0.178 LCD 2: SM62T LCD 1: HDBaseT Matrix 7.2.2 Signal Switching Command Example Command Description and Response Automatically switch input source to HDMI Auto.
  • Page 23 6x2 4K Presentation Switcher with Matrix Outputs Command Example Command Description and Response [x]@. Turn on output [x]. x=1~2. 01 Open. All@. All Open. All@. Turn on all outputs. Out 01 02 04 04 Switch input [x] to output [y]. x=1~6, 1V1.

  • Page 24: Preset Setting

    6x2 4K Presentation Switcher with Matrix Outputs 7.2.3 Preset Setting Command Example Command Description and Response Store the current switching status to Save3. Save[y]. present [y]. y=0~ 9. Save To F3 Recall9. Recall[y]. Recall present [y]. y=0~ 9. Recall From F9 Clear9.

  • Page 25: Audio Setting

    6x2 4K Presentation Switcher with Matrix Outputs 7.2.4 Audio Setting Command Example Command Description and Response Set line audio volume to xxx SetLineVol:95. SetLineVol:xxx. (0~100). Volume of LINE : 95. LineVolume+. LineVolume+. Line audio volume +1. Volume of LINE : 96. LineVolume-.
  • Page 26 6x2 4K Presentation Switcher with Matrix Outputs Command Example Command Description and Response Out2Volume+. Out2Volume+. The volume of audio output 2 +1. Volume of Out2 :71. Out2Volume-. Out2Volume-. The volume of audio output 2 -1. Volume of Out2 :69. Out2Mute. Mute the volume of audio output 2.
  • Page 27 6x2 4K Presentation Switcher with Matrix Outputs Command Example Command Description and Response BtOutVolume-. BtOutVolume-. HDBT audio output volume -1. Volume of BtOut : 79. BtOutMute. Mute HDBT audio output volume. BtOut Mute. BtOutUnmute. Unmute HDBT audio output volume. BtOut Unmute. Set the delay time [y] for audio DelayTime/[x]:[y].
  • Page 28 6x2 4K Presentation Switcher with Matrix Outputs Command Example Command Description and Response Out3 Unmute. Amp Unmute. HdOut Unmute. BtOut Unmute. Volume of MIC : 48. Volume of LINE : 61. Volume of MASTER : Volume of Out1 : 50. Volume of Out2 : 50.
  • Page 29 6x2 4K Presentation Switcher with Matrix Outputs Command Example Command Description and Response Out2 Mute. Out2 Unmute. %9926. %9926. Get audio output 3 mute status. Out3 Mute. Out3 Unmute. %9927. %9927. Get amplifier mute status. Amp Mute. Amp Unmute. %9928. %9928.

  • Page 30: Vga Scaling Resolution Setting

    6x2 4K Presentation Switcher with Matrix Outputs 7.2.5 VGA Scaling Resolution Setting The default output resolution for VGA is 1920x1080. Below is a list of the output resolutions the built-in scaler can output. Command Example Command Description and Response x=5/6 is the number of the VGA input port;...

  • Page 31: Edid Configuration

    6x2 4K Presentation Switcher with Matrix Outputs 7.2.6 EDID Configuration The 4-pin DIP switcher on rear panel must be set as “1111” to enable EDID RS232 control mode, and then send the below commands to manage EDID. Command Example Command Description and Response Set the EDID data of output [x] to...
  • Page 32 6x2 4K Presentation Switcher with Matrix Outputs Command Example Command Description and Response The input [x] invoke embedded EDID [y]. EDID The source device obtains its EDID from HDBT output. EDIDIN/1/0. The source device EDIDIN/[x]/[y]. EDIDIN/1/0 obtains its EDID from HDMI output.

  • Page 33: Hdcp Compliance

    6x2 4K Presentation Switcher with Matrix Outputs 7.2.7 HDCP Compliance Command Example Command Description and Response %0801. %0801. Auto HDCP management mode. HDCP AUTO. %9973. 01 02 03 04 %9973. Get the HDCP status of input ports. HDCP Y Y Y N 05 06 HDCP N N %9974.

  • Page 34: Control Far-End Device

    6x2 4K Presentation Switcher with Matrix Outputs 7.2.8 Control Far-end Device Command Example Command Description and Response Send ASCII command to control far- end device from switcher to receiver based on RS232 pass-through function. ① x = 1~7 is for baud rate. Baud Rate 2400 /+1/[3]:123456.

  • Page 35: Gui Control

    6x2 4K Presentation Switcher with Matrix Outputs 8. GUI Control In addition to control the switcher via front panel button, IR remote and RS232 communication software. The switcher can be controlled via GUI. It allows users to interact with the switcher through graphical icons and visual indicators. Type 192.168.0.178 in your browser, it will enter the log-in webpage shown as below:...

  • Page 36: Video Switching

    6x2 4K Presentation Switcher with Matrix Outputs 8.1 Video Switching Type the user name and password (both of them are “admin”), and then click Login to enter the section for video switching. HDMI OUTPUT: Switch 1-HDMI, 2-HDMI, 3-HDMI, 4-DP, 5-VGA or 6-VGA input to HDMI output.

  • Page 37: Vga Scaling Resolution Selection

    6x2 4K Presentation Switcher with Matrix Outputs 8.2 VGA Scaling Resolution Selection Click Resolution to enter the section for selecting VGA resolution. 1024x768, 1280x720, 1280x800, 1360x768, 1920x1080, or 1920x1200 can be selected for port 5-VGA and port 6-VGA.

  • Page 38: Audio Switching And Volume Adjustment

    6x2 4K Presentation Switcher with Matrix Outputs 8.3 Audio Switching and Volume Adjustment Click Audio to enter the section for audio matrix switching and volume adjustment. LINE/MIC: Volume control for line or microphone input. MASTER Volume: Volume control for all audio outputs. MIX: Audio matrix for switching de-embedded HDMI audio, de-embedded HDBT audio, LINE or MIC audio to audio outputs.

  • Page 39: Edid Management

    6x2 4K Presentation Switcher with Matrix Outputs 8.4 EDID Management Click EDID to enter the section for invoking embedded EDID to HDMI and DP inputs. 8.5 Input Tag Setting Click Tags to enter the section for renaming input ports.

  • Page 40: Rs232 Control

    6x2 4K Presentation Switcher with Matrix Outputs 8.6 RS232 Control Click RS232 Control to enter the section to send commands to control the switcher or far-end third-party device. Port: Local refers to the RS232 port of the switcher, and HDBT refers to the RS232 port of HDBaseT receiver.

  • Page 41: Network Setting

    6x2 4K Presentation Switcher with Matrix Outputs 8.7 Network Setting Click Network to enter the section for network setting. The IP address, subnet mask and gateway can be reset on the static mode. 8.8 Password Setting Click Password to enter the section to reset password and lock or unlock front panel buttons.

  • Page 42: Gui Update

    6x2 4K Presentation Switcher with Matrix Outputs 8.9 GUI Update GUI for the switcher supports online update in http://192.168.0.178:100. Type the username and password (the same as the GUI log-in settings, modified password will be available only after rebooting) to log in the configuration interface. After that, click Administration at the source menu to get to Upload Program as shown below: Select the update file and click Apply button, it will start upgrading then.

  • Page 43: Panel Drawing

    6x2 4K Presentation Switcher with Matrix Outputs 9. Panel Drawing MIC + 1-HDMI 2-HDMI 3-HDMI 4-DP 5-VGA 6-VGA AUTO 1-HDMI 2-HDBT 5-VGA 6-VGA MENU/3s VOL - VOL + MENU SOURCE OUTPUT RESOLUTION ENTER MIC - 436 mm AUDIO INPUT AUDIO OUTPUT CONTROL SPDIF 1x40W...

  • Page 44: Troubleshooting & Maintenance

    6x2 4K Presentation Switcher with Matrix Outputs 10. Troubleshooting & Maintenance Problems Potential Causes Solutions Bad quality of the Try another high-quality connecting cable. cable. Output image with snowflake. Make sure the connection Fail or loose connection. is good. Check with oscilloscope No signal at the input / or multimeter if there is output end.

  • Page 45: Customer Service

    6x2 4K Presentation Switcher with Matrix Outputs 11. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
